TRENDnet TPL-302E User manual

TPL-302E
Quick Installation Guide

Table of Contents
Table of Contents
Version 02.18.2009
English .....................................................................................................
Troubleshooting ........................................................................................
1
1
2
5
1. Before You Start
2. ....................................................................................
................................................................................
How to Install

System Requirements
Application
?TPL-302E
?Utility CD-ROM
?Quick Installation Guide
Package Contents
1. Before You Start
English
1
?
?A Desktop or Laptop PC with Network Adapter Installed
?CPU: 300MHz or above / 800MHz or above (Windows Vista)
?
?Existing Powerline AV network
?Existing 10/100Mbps wired network when TPL-302E is used as a bridge
device
C
Memory: 256MB RAM or above / 512MB RAM or above (Windows Vista)
D-ROM drive
Outlet
200Mbps Powerline AV
Fast Ethernet Adapter
(TPL-302E)
Workstation with
Fast Ethernet PCI Adapter
(TE100-PCIWN)
4-Port Cable/DSL
Broadband Router
(TW100-S4W1CA)
Internet
Cable/DSL
Modem Outlet
10/100Mbps Powerline

2. How to Install
English
2
Important! DO NOT install the TPL-302E until instructed to do so
Note:
1. DO NOT plug the TPL-302E into a power strip or surge protector.
2. In order for the TPL-302E to see each other, each unit must be on the same
circuit breaker.
3. A maximum of 16 TPL-302E can be networked.
1. Insert the Utility CD-ROM into
your computer's CD-ROM Drive
and then click Install Utility.
3. On the back of the unit, copy down
the 12 digit device password.
For Windows Users
2. Follow the InstallShield Wizard
instructions and then click Finish.

Outlet
Outlet
English
3
6. Plug a second TPL-302E into an
outlet where your remote PC,
wireless access point or other
device with a built in Ethernet port
is located.
5. Connect a CAT-5 cable from the
TPL-302E to your router (e.g.
TEW-633GR). Then connect a
CAT-5 cable from your router to
your computer.
4. Plug the TPL-302E into an
available power outlet.
Note: The default network name is TRENDnet. If the network ID of your
existing Powerline network is NOT TRENDnet, you must change this in the
utility.
7. Double-click the TRENDnet
Powerline AV Utility on your
desktop.

English
4
10. Repeat step 8-9 for the second
TPL-302E.
8. Select Local or Remote device,
then click Security.
Note: Configure the Remote
device first.
9. If you would like to change the
Network ID, enter the desired ID.
If you are configuring a remote
device, you must enter the device
password (see step 3). Then click
Save Changes.
11. Connect a CAT-5 cable from the
TPL-302E into your remote PC,
Wireless Access Point (e.g. TEW-
630APB) or other device with
built-in Ethernet port.
Your installation is now complete.
For detailed information regarding the TPL-302E configuration and advanced
settings, please refer to the User's Guide included on the Utility CD-ROM or
TRENDnet's website at www.trendnet.com
Outlet

Q1:
A1:
Q2:
A2:
Q3:
A3:
I inserted the TPL-302E CD-ROM into my computer's CD-ROM Drive and the
installation menu does not appear automatically. What should I do?
If the installation menu does not appear automatically, click Start, click Run,
and type D:\Autorun.exe where "D" in "D:\Autorun.exe" is the letter assigned to
your computer's CD-ROM Drive. And then click OK to start the installation.
I have verified that my Powerline device is connected to my workstation, but I
cannot detect other Powerline devices. What should I do?
First, verify that you are using Cat-5e Ethernet cables. Second, open up the
Powerline AV Utility and click scan. Third, verify the network name of your
Powerline network. Then click on the security link in the TRENDnet Powerline
Utility, type in the network name and click Save changes. Fourth, verify that the
power outlet the TPL-302E is plugged into is on the same electrical power
distribution and/or circuit breaker.
I can detect my Powerline devices on my Powerline network, but I cannot
connect to the Internet. What should I do?
First, make sure you are not connecting the device into a power strip or surge
protector. Second, make sure that your Router is connected to the internet. Third,
verify that the TCP/IP settings are set to Obtain an IP address automatically.
5
Troubleshooting
1. Go into the Control Panel and double-click the
Network Connections icon, and then right-click the
Local Area Connection icon and then click
Properties.
2. Click Internet Protocol (TCP/IP) and then click
Properties. Click on Obtain an IP automatically and
then click OK.

Q4:
A4:
Q5:
A5:
When I try to configure a remote device, an error message appears. What
should I do?
First, make sure you copy down the 12 digit device password. Second, enter
the 12 digit device password in the utility. You need to enter dashes. For
example: XXXX-XXXX-XXXX-XXXX.
I have a HomePlug 1.0 or HomePlug turbo network. Can I use this with my
network?
The TPL-302E is not backwards compatible with HomePlug 1.0 or HomePlug
turbo.
If you still encounter problems or have any questions regarding the TPL-302E, please
refer to the User's Guide included on the Utility CD-ROM or contact TRENDnet's
Technical Support Department.
