TRENDnet TPL-307E2K User manual

FEATURES
• Includes two TPL-307E adapters
• Compliant with IEEE1901 and HomePlug AV standards
• High speed building-wide networking over an existing electrical system
• 1 x 10/100Mbps Auto-MDIX Fast Ethernet port
• 1 x electrical power socket
• 1 x One-touch Sync button to change the default encryption key
• Three LED indicators: Power (on/off), Powerline Connection (green (best), amber (better), red (good), off(no connection)),
Ethernet Connection (solid (connection), blinking (transfer activity), off (no connection))
• Advanced electrical noise fi lter boosts performance
• Share data intensive fi les, play games, download music, and more at fast data transfer rates
• Advanced 128-bit AES encryption to ensure total network security
• Power Saving mode reduces electrical consumption by 80%
• Neighbor network support for up to 4 overlapping networks
• Network signal transmits up to 300 meters (984ft.)
• Compatible with all operating systems
• Optional management utility compatible with Windows 7 (32/64-bit), Vista (32/64-bit), and XP (32/64-bit) operating systems
• 3-year limited warranty
* Maximum of 6 adapters (nodes) for streaming video across your network.
** 200Mbps is the maximum theoretical Powerline data rate. Actual throughput will vary depending on environment.
*** Networked Powerline devices need to be plugged into power outlets that are on the same electrical system.
**** GFCI outlets and AFCI circuit breakers may degrade Powerline network signals.
TPL-307E2K
rev: 10.13.2011
200Mbps Powerline AV Adapter Kit with Bonus
Outlet
TPL-307E2K (V1.0R)
TRENDnet’s 200Mbps Powerline AV Adapter Kit with Bonus Outlet,
model TPL-307E2K, comes with everything you need to build an HD
Powerline network from any electrical outlet. Connect the fi rst adapter to
your network and plug the second adapter into any outlet on your electri-
cal system for instant high speed network access.
Never lose an electrical outlet with the built in outlet on the front of the
adapters. The compact housing does not block adjacent electrical outlets.
A noise fi lter maintains optimum connection speeds when household
devices create electrical background noise.
The adapters will automatically connect with no installation required—
TRENDnet recommends pressing the ‘Sync’ button to automatically
change default encryption keys. Use up to 6 adapters to network devices
in different rooms without running new cabling. Power Save mode reduc-
es power consumption by up to 80%. Quality of Service technology prior-
itizes video, audio, and online gaming. Advanced AES encryption secures
your network. This adapter is ideal for use in buildings that interfere with
wireless networking signals.

200Mbps Powerline AV Adapter Kit with Bonus Outlet
TPL-307E2K (V1.0R)
SPECIFICATIONS
HARDWARE
Standards • IEEE 1901, HomePlug® AV, IEEE 802.3, IEEE 802.3x, IEEE 802.3u
Interface • 1 x 10/100Mbps Auto-MDIX RJ-45 Port
• 1 x electrical power socket with noise fi ltering (12A max. load)
• Power prong:
• A: North America Type B (NEMA 5–15)
• EU: Euro Type C (CEE 7/16)
• FR: French Type E (CEE 7/5)
• UK : United Kingdom Type G (BS 1363)
Frequency Band • 2 ~ 28 MHz
Modulation • OFDM Symbol modulation on link synchronization, 1024/256/64/8 - QAM, QPSK, BPSK, ROBO carrier
Protocols • TDMA and CSMA/CA
Speed • Powerline: up to 200Mbps**
• Ethernet: up to 200Mbps with Full Duplex mode
Utility OS Compatibility • Windows 7 (32/64-bit), Vista (32/64-bit), XP (32/64-bit)
Nodes • Up to 6 (max.)
Overlapping Powerline
Networks Supported
• Up to 4 (per electrical system)
Coverage • Up to 300 m (984 ft.)
Security • 128-Bit AES (Advanced Encryption Standard)
LED • Power (PWR)
• Powerline (PL) Connection
• Best (Green)
• Better (Amber)
• Good (Red)
• No connection (Off)
• Ethernet (ETH) Connection
• Solid
• Blinking
• Off
Buttons • Sync, Reset
Dimension (L x W X H) • A: 122 x 55 x 60 mm (4.8 x 2.2 x 2.4 in.) per unit
• EU/FR: 122 x 55 x 78 mm (4.8 x 2.2 x 3.1 in.) per unit
• UK: 122 x 55 x 72 mm (4.8 x 2.2 x 2.8 in.) per unit
Weight • A: Total Weight: 294 g (10.4 oz) / Per Unit Weight: 147 g (5.2 oz)
• EU: Total Weight: 336 g ( 11.8 oz) / Per Unit Weight: 168 g (5.9 oz)
• FR: Total Weight: 338 g (12 oz) / Per Unit Weight: 169 g (6.0 oz)
• UK: Total Weight: 350 g (12.4 oz) / Per Unit Weight: 175 g (6.2 oz)
Power Source • 100~240V AC, 50~60Hz
Consumption • Active mode: 3 Watts (max.)
• Standby mode: 0.6 Watts (max.)
Temperature • Operating: 0° ~ 40°C (32° ~ 104°F)
• Storage: -20° ~ 70°C (-4° ~ 158°F)
Humidity • Max. 90% (non-condensing)
Certifi cations • CE, FCC, HomePlug® AV
TPL-307E2K
rev: 10.13.2011

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time,
without notice. For the most recent product information please visit http://www.trendnet.com Copyright ©TRENDnet.All Rights Reserved.
NETWORKING SOLUTIONS
200Mbps Powerline AV Adapter Kit with Bonus Outlet
TPL-307E2K (V1.0R)
CONTACT INFORMATION
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web: www.trendnet.com
Email: [email protected]
1-888-326-6061
PACKAGE CONTENTS
2 x TPL-307E
Multi-Language Quick Installation Guide
CD-ROM (Utility & User’s Guide)
2 x network cables (1.5 m / 5 ft.)
