TRENDnet TFC-110S20D5i User manual

TFC-110S20D5i
rev: 11.21.2012
Intelligent 100Base-TX to 100Base-FX Dual
Wavelength Single Mode SC Fiber Converter
(20 km / 12.4 miles)
TFC-110S20D5i (v1.0R)
The TFC-110S20D5i intelligent fi ber converter works with the
TFC-1600 chassis system or as a standalone unit. This converter is
a Dual Wavelength Single Mode SC-Type fi ber converter that spans
distances up to 20 km (12.4 miles). This module must be used with the
TFC-110S20D3i module. Ports include 1 x 10/100Base-TX (RJ-45) port
and 1 x 100Base-FX (SC Simplex Type) port.
FEATURES
• Must use with TFC-110S20D3i
• Compliant with IEEE 802.3u 100Base-TX and 100Base-FX standards
• 1 x 10/100Base-TX RJ-45 port
• 1 x 100Base-FX single-mode bi-directional simplex-SC type fi ber port
• Port level SNMP management support
• Monitor and confi gure Ethernet or Fiber’s duplex mode, LLR, port on / off and receive link down information via management
module TFC-1600MM and chassis TFC-1600
• Dip switch controls: Fiber (Full / Half-Duplex), UTP (Auto negotiation / Manual), Speed (10 Mbps / 100 Mbps),
Copper (Full / Half-Duplex), LLR (Enable / Disable), and LLCF (Enabled / Disable)
• Link Loss Carry Forward (LLCF) support
• Link Loss Return (LLR) support
• Status LED indicators for Power and Link / Activity
• Removable metal enclosure
• Wall mountable
• Functions as a standalone converter or with the TFC-1600 fi ber chassis
• 3-year limited warranty
PRODUCT OVERVIEW
• Must use with TFC-110S20D3i
• Port level SNMP management support
• SC-type dual-wavelength single-mode fi ber port
• 10/100Base-TX RJ-45 port
• Spans distances up to 20 km (12.4 miles)
• Functions as a standalone converter or with the TFC-1600 fi ber chassis

TFC-110S20D5i
rev: 11.21.2012
Intelligent 100Base-TX to 100Base-FX Dual Wavelength Single
Mode SC Fiber Converter (20 km / 12.4 miles)
TFC-110S20D5i (v1.0R)
SPECIFICATIONS
HARDWARE
Standard • IEEE 802.3 10Base-T
• IEEE 802.3u 100Base-TX/FX
Network Media • 100Base-TX: Cat. 5 EIA/TIA-568 100-ohm UPT/STP, up to 100 m
• 100Base-FX: Single-mode fi ber optic cable 9/125 µm or 10/125 µm, up to 20 km
Protocol • CSMA / CD
Ports • 1 x 10/100Base-TX
• 1 x 100Base-FX (simplex SC-type)
Dip Switch • Fiber (full / half duplex)
• UTP (auto negotiation / manual)
• Speed (10 Mbps / 100 Mbps)
• Copper (full / half duplex)
• LLR (enable / disable)
• LLCF (enable / disable)
Transfer Rate • 100 Mbps (half duplex) / 200 Mbps (full duplex)
Diagnostic LEDs • Per Unit: power
• Per Port (TX): Link / Activity, FDX / HDX, Link Fail, Speed
• Per Port (FX): Link / Activity, FDX / HDX, Link Fail
Power Adapter • Input: 100~240 V 50/60Hz, 0.2 A
• Output: 5 V DC, 1 A
Power Consumption • 2 watts (max)
Dimensions • 120 x 88 x 25 mm (4.7 x 3.46 x 0.98 in.)
Weight • 354 g (12.5 oz)
Temperature • Operating: 0° ~ 40°C (32° ~ 104°F)
• Storage: -25° ~ 70°C (-13 ° ~ 158°F)
Humidity • Max 90% (non-condensing)
Certifi cations • CE, FCC
MODEL NAME MEDIA WAVELENGTH OPTICAL OUTPUT POWER
(DBM)
OPTICAL INPUT POWER
(DBM)
POWER BUDGET DISTANCE
TFC-110S20D5i SMF TX: 1310 nm
RX: 1550 nm
Min. Max. Min.
(Sensitivity) Max.
17 20 km
-14 -8 -31 0

TFC-110S20D5i
rev: 11.21.2012
Intelligent 100Base-TX to 100Base-FX Dual Wavelength Single
Mode SC Fiber Converter (20 km / 12.4 miles)
TFC-110S20D5i (v1.0R)
CONTACT INFORMATION
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web: www.trendnet.com
Email: [email protected]
1-888-326-6061
PACKAGE CONTENTS
TFC-110S20D5i
Multi-Language Quick Installation Guide
Power adapter (5 V DC, 1 A)
RELATED PRODUCTS
TFC-110S20D3i Intelligent 100Base-TX to 100Base-FX Dual
Wavelength Single Mode SC Fiber Converter
(20 km / 12.4 miles)
TFC-1600MM SNMP Management Module
TFC-1600 16-Bay Fiber Converter Chassis System
