TRENDnet TFC-15MS100 - DATA SHEETS User manual

TRENDnet's TFC-100 series Fiber Media Converter transforms
100Base-TX UTP/STP media to 100Base-FX media and vice versa.
The 100Base-TX port auto-negotiates half-/full-duplex connection
and it has a slide-switch for selecting MDI-X / MDI-II media type. The
fiber connection can be multi-mode SC, MT-RJ, or single-mode SC
connector and supports half-duplex and full-duplex modes. This
converter will give your Switch/Hub the ability to interface with fiber
connections over a distance up to 75 km. With the optional 16-slot
EIA-19" rack-mount chassis, the TFC series converters are the
perfect solutions for various fiber media conversions for your
network
TFC-15MS100
100Base-FX Multi-Mode Fiber to 100Base-FX
Single-Mode Fiber Converter (15Km) with
SC-Type Connector
TFC-15MS100
rev:08.01.2006
• Compliant with IEEE 100Base-FX standards
• One 100Mbps fiber port with Multi-mode SC-Type Connector
• One 100Mbps fiber port with Single-Mode SC-Type Connector
• Half / Full-Duplex mode selector on Fiber ports
• Status LED indicators for Power, Link/Activity, Full-Duplex, and Speed
• Wall-Mountable
• Optional 19” system chassis with redundant power supply (TFC-1600), holds up to 16 TFC series Media Converters
• 5-year Warranty
FEATURES

Network Media
Protocol
Ports
Diagnostic LEDs
• IEEE802.3 10Base-T, IEEE 802.3u 100Base-TX and 100Base-FX
• 100Base-FX: Multi-Mode fiber optic cable 50/62.5, up to 2Km
• 1300nm
• CSMA/CD
• 2 x 100Base-FX
• Operating: 10% ~ 90%
• 100Mbps (Half-Duplex), 200Mbps (Full-Duplex)
• Power, Link/Activity, Full-Duplex, and Speed
• 7.5VDC, 1.5A (7.2 watts max.)
• Storage: 5% ~ 90% (non-condensing)
Power Adapter
Standards
Hardware
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
100Base-FX Multi-Mode Fiber to 100Base-FX Single-
Mode Fiber Converter (15Km) with SC-Type Connector
TFC-15MS100
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
3135 Kashiwa Street,Torrance, CA 90505 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
SPECIFICATIONS
Wavelength
Data Transfer Rate
RELATED PRODUCTS
TFC-1600
TFC-15MS100
16-Slot Chassis System for TFC series Fiber Converter
100Base-FX Multi-Mode Fiber to 100Base-FX Single-
Mode Fiber Converter (15Km) with SC-Type Connector
Humidity
• Operating: 0°~ 40°C (32°~ 104°F)
• Storage: -25°~ 70°C (-13°~ 158°F)
Temperature
• 100Base-FX: Single-Mode fiber optic cable 9/10, up to 15 Km
