TRENDnet TFC-1000S10D3 User manual

TFC-1000S10D3/D5
1000Mbps TX to 1000Base-FX Single-Mode
Fiber Converter
TEW-503PI (07-28-2005) TFC-1000S10D3/D5
rev:12.27.2005
FEATURESFEATURES
TFC-1000S10D3 or TFC-1000S10D5 Bi-Directional Single-Fiber
Media Converter transforms 1000Base-TX UTP/STP media to
1000Base-FX media and vice versa. It provides DIP switch for
duplex mode, auto negotiation or speed management control. This
converter will give your Switch/Hub the ability to interface with fiber
connection over a distance up to 10 km.
• Compliant with IEEE 802.3ab 1000Base-T and IEEE 802.3z 1000Base-LX Standards
• Provides Dip Switch for Fiber (Auto/Manual), LLR (Enable/Disable)
• Support LLCF (Link Loss Carry Forward, Link Pass Through)
• Supports LLR (Link Loss Return) for FX Port
• Supports Full-Duplex and Auto-Negotiation Mode for Fiber Port
• Hot Pluggable & Wall-Mountable
• Optional 19” System Chassis (TFC-1600) holds up to 16 Media Converters
• 5-Year Warranty

Network Media
Weight
Protocol
Ports
Dip Switch
Transfer Rate
Diagnostic LED
Power Adapter
Temperature
Humidity
Safty Emissions
• IEEE 802.3ab 1000Base-T • IEEE 802.3z 100Base-TX, 1000Base-FX
• 7.5V DC, 1.5A External Power Adapter
• 1000Base-TX: UTP Cat. 5, EIA/TIA-568 100-ohm STP, up to 100meters
• 5.5 watts (max)
• 120 x 88 x 25mm (4.7 x 3.46 x 0.98 inches)
• 5% ~ 90% RH
• 100Base-LX: 10/125μm Single-Fiber Optic Cable, up to 10km
• CSMA/CD
• 1 x 1000ase-T RJ-45 Port • 1 x 1000Base-FX Single-Fiber Bi-Directional Port SC Connector
• TX: Duplex Mode, Auto Negotiation or Manual, Speed, LLCF (enable/disable)
• 354g (12.5oz)
• FX: Duplex Mode, LLR (enable/disable), LLCF
• 1000Base-T : 2000Mbps (Full Duplex)
• Per Unit : Power • Per Port : Link/Activity
• FCC,CE
• Operating : 0° ~ 40° C (32° ~ 104° F) • Storage : -25° ~ 70° C (-13° ~ 158° F)
Power Consumption
Dimensions
Standard
Hardware
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
1000Mbps TX to 1000Base-FX Single-Mode Fiber Converter
TFC-1000S10D3/D5
RELATED PRODUCTSRELATED PRODUCTS
PACKAGE CONTENTSPACKAGE CONTENTS
TFC-110S40D3/D5
TFC-110S20D3/D5 10/100Mbps TX to 100Base-FX Dual-Wavelength
Single-Mode Fiber Converter
• User’s Guide
10/100Mbps TX to 100Base-FX Dual-Wavelength
Single-Mode Fiber Converter
• TFC-1000S10D3/D5
• Power Adapter
ORDERING INFORMATIONORDERING INFORMATION
To Order Please Call:
1-888-326-6061
3135 Kashiwa Street,Torrance, CA 90505 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
SPECIFICATIONSSPECIFICATIONS
Model Name
TFC-1000S10D3 -9dBm -21dB 12dBm
TFC-1000S10D5 -9dBm -21dB 12dBm
Sensitivity Power
TX: 1550nm; RX: 1310nm
Wavelength Pout
TX: 1310nm; RX: 1550nm
