TRENDnet TEW-USB User manual

USB Wireless Network
Adapter
User’s Manual
Rev 1.1

USB Wireless Network Adapter User’s Manual
2
Regulatory compliance
FCC Warning
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
ŸReorient or relocate the receiving antenna.
ŸIncrease the separation between the equipment and receiver.
ŸConnect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
ŸConsult the dealer or an experienced radio/TV technician for help.
You are cautioned that changes or modifications not expressly approved by the party
responsible for compliance could void your authority to operate the equipment.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
CE Mark Warning
This is a Class B product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.

USB Wireless Network Adapter User’s Manual
3
About this manual
This User’s Manual describes how to install and operate your USB Wireless
Network Adapter. Please read this manual before you install the product.
This manual includes the following topics:
ØProduct description and features.
ØHardware installation procedure.
ØSoftware installation procedure.
ØFAQ

USB Wireless Network Adapter User’s Manual
4
Table of Contents
Regulatory compliance
About this manual
Chapter 1- Introduction 6
Features 6
What is Wireless LAN? 7
Wireless LAN Modes 7
Notes on Wireless LAN Configuration 8
Chapter 2 - Hardware Installation 9
Package Contents 9
System Requirements for the Adapter 9
Connecting the USB Adapter 9
LEDs Indicators 10
Disconnecting the USB Adapter 11
Chapter 3 - Installation Procedures
Under Windows 98 12
What You Will Need 12
Installing the Driver Under Windows 98 12
Uninstall Procedure Under Windows 98 15
Chapter 4 - Installation Procedures
Under Windows 2000 16
What You Will Need 16
Installing the Driver Under Windows 2000 16
How to Unplug the Device Under Windows 2000 20
Uninstall Procedure Under Windows 2000 21
Chapter 5 - Installation Procedures
Under Windows ME 22
What You Will Need 22
Installing the Driver Under Windows ME 22
Uninstall Procedure Under Windows ME 24
Chapter 6 - Install and Use Configuration Utility 25
How to Install the Configuration Utility 25
Using the Configuration Utility 27
Appendix A –FAQ 33
Appendix B –Specifications 35

USB Wireless Network Adapter User’s Manual
5

USB Wireless Network Adapter User’s Manual
6
Chapter 1 - Introduction
Thank you for purchasing the USB Wireless Network Adapter. This high-speed
USB Wireless Network Adapter provides you with an innovative wireless
networking solution. The Adapter is easy to set up and use. With this innovative
wireless technology, you can share files and printers on the network—without
inconvenient wires! Now you can carry the LAN in your pocket!
The Adapter is a network adapter with a rate of 1, 2, 5.5, and 11 Mbps operating
in the ISM band using Direct Sequence Spread Spectrum (DSSS) transmission
implementing the IEEE 802.11b standard. This adapter provides Device Drivers
for Windows 98, Windows 2000 and Windows ME. It also provides tools for the
configuration of the adapter. The tool, as well as the installation steps of the
plug-and-play procedure for the Microsoft Windows 98, Windows ME and
Windows 2000 operating systems, is described in this document.
Features
The USB Wireless Network Adapter offerscompliance with the IEEE 802.11b
specification. This feature allows them to communicate with other wireless
devices that support the standard. Features of the adapter are:
lUses 2.4GHz frequency band, which complies with worldwide
requirement
lWireless interface following the IEEE 802.11b standard
lUsing Universal Serial Bus (USB) interface
lEnciphering/deciphering of wireless data by the implementation of the
WEP algorithm
lWire-free access to networked resources from anywhere beyond the
desktop
lAllows users move between Access Points without resetting their
connection reconfiguration
lDelivers data rate up to 11 Mbps
lSupports 11, 5.5, 2, and 1 Mbps rates
lProvide USB Wireless Network Adapter Configuration utility
lAntenna is built in to the Adapter with LEDs indicating Power and Link
lSupports most popular operating systems: Window 98/2000 &
Windows ME

USB Wireless Network Adapter User’s Manual
7
What is Wireless LAN?
Wireless Local Area Network (WLAN) systems offer a great number of
advantages over traditional wired systems. WLAN is flexible and easy to setup
and manage. They are also more economical than wired LAN systems.
Using radio frequency (RF) technology, WLAN transmit and receive data
through the air. WLAN combine data connectivity with user mobility. For example,
users can roam from a conference room to their office without being
disconnected from the LAN.
Using WLAN, users can conveniently access-shared information, and network
administrators can configure and augment networks without installing or moving
network cables.
WLAN technology provides users with many convenient and cost saving
features:
•Mobility: WLAN provide LAN users with access to real-time information
anywhere in their organization, providing service opportunities that are
impossible with wired networks.
•Ease of Installation: Installing is easy for novice and expert users alike,
eliminating the need to install network cables in walls and ceilings.
•Scalability: WLAN can be configured in a variety of topologies to adapt to
specific applications and installations. Configurations are easily changed
and range from peer-to-peer networks suitable for a small number of users
to full infrastructure networks of thousands of users roaming over a broad
area.
Wireless LAN Modes
Wireless LANs can be configured in one of two ways:
Ad-hoc
Networking Also known as a peer-to-peer network, an ad-hoc
network is one that allows all workstations and
computers in the network to act as servers to all other
users on the network. Users on the network can share
files, print to a shared printer, and access the Internet
with a shared modem. However, with ad-hoc
networking, users can only communicate with other
wireless LAN computers that are in the wireless LAN
workgroup, and are within range.
Infrastructure
Networking Infrastructure networking differs from ad-hoc networking
in that it includes an access point. Unlike the ad-hoc
structure where users on the LAN contend the shared
bandwidth, on an infrastructure network the access

USB Wireless Network Adapter User’s Manual
8
point can manage the bandwidth to maximize
bandwidth utilization.
Additionally, the access point enables users on a
wireless LAN to access an existing wired network,
allowing wireless users to take advantage of the wired
networks resources, such as Internet, email, file
transfer, and printer sharing.
Infrastructure networking has the following advantages
over ad-hoc networking:
•Extended range: each wireless LAN computer
within the range of the access point can
communicate with other wireless LAN computers
within range of the access point.
•Roaming: the access point enables a wireless LAN
computer to move through a building and still be
connected to the LAN.
•Wired to wireless LAN connectivity: the access
point bridges the gap between wireless LANs and
their wired counterparts.
Notes on Wireless LAN Configuration
When configuring a wireless LAN (WLAN), be sure to note the following points:
•Optimize the performance of the WLAN by ensuring that the distance
between access points is not too far. In most buildings, WLAN cards
operate within a range of 100 ~ 300 feet, depending on the thickness and
structure of the walls.
•Radio waves can pass through walls and glass but not metal. If there is
interference in transmitting through a wall, it may be that the wall has
reinforcing metal in its structure. Install another access point to circumvent
this problem.
•Floors usually have metal girders and metal reinforcing struts that interfere
with WLAN transmission.
This concludes the first chapter. The next chapter deals with the hardware
installation of the Adapter.

USB Wireless Network Adapter User’s Manual
9
Chapter 2 - Hardware Installation
This chapter covers connecting your USB Wireless Network Adapter to USB
port of desktop / notebook PC.
Package Contents
Please make sure that items below are included on package.
üOne USB Wireless Network Adapter
üOne USB cables
üOne Driver / Utility CD-ROM (this use’s manual included)
üOne Quick Installation Guide
System Requirements for the Adapter
ØOperating System: MS Windows 98, Windows 2000, Windows ME
ØDesktop PC or notebook PC with CD-ROM drive
ØOne free USB port
ØPentium-Class 90MHz or higher
Connecting the USB Adapter
NOTE: These instructions apply to most desktop/notebook computers. For
detailed information on inserting USB adaptersinto your desktop/notebook PC,
consult the desktop/notebook PC User’s Manual.
The Adapter’s USB port is located on the back of the Adapter.
And your Adapter comes with a USB cable that has two different types of
connectors –type A & type B. Type A connector of the USB cable plugs into
your notebook/desktop PC’s USB port. And type B connector of the USB cable
connects to the USB port of your USB Wireless Network Adapter.

USB Wireless Network Adapter User’s Manual
10
USB Type A USB Type B
LED Indicators
POWER LINK
The following table describes the meaning of LED indicators:
LED MEANING
POWERIndicates that the Adapter is powered on when the LED
lights up.
LINK Indicates link status. The LED lights up while the wireless
connection is linked. If the light is blinking, it means there is
data sending or receiving via wireless.

USB Wireless Network Adapter User’s Manual
11
Disconnecting the USB Adapter
In Win 98/ME operating systems, you do not have to power down your
notebook/desktop PC to remove the Adapter. The Adapter is hot swappable—
you can remove the Adapter when your notebook/desktop PC is powered on.
However, Microsoft recommends that you stop the Adapter before removing the
Adapter. Refer to your Win 98/ME online help for information on stopping the USB
Adapter.
WARNING: Do not remove the USB Wireless Network Adapter when a data
transmission is taking place. Exit your communications program normally, stop
the Adapter if necessary, and then remove the adapter.

USB Wireless Network Adapter User’s Manual
12
Chapter 3 - Installation Procedures Under
Windows 98
Use the procedures described in this chapter to install and configure the USB
Wireless Network Adapter under Windows 98.
Throughout this chapter it is assumed that you have a basic working knowledge
of Windows 98 and of how to install new network adapters on them. However, in
this paragraph, some specific features of Windows 98 are briefly explained.
What You Will Need
During the installation, you may be prompted to load operating system files from
the Windows installation disc. Please have this disc handy.
You will also need the Drivers/Utility CD provided with your package.
Installing the Driver Under Windows 98
1. Connecting the Adapter to the USB port of a notebook or desktop PC. (Refer
to Connecting the USB Adapter at Chapter 2)
2. The Add New Hardware Wizard will indicate that Windows have
recognized a new device that has not been used before.

USB Wireless Network Adapter User’s Manual
13
3. Click Next to continue the installation. A screen appears prompting you to
select an installation method:
4. Select Search for the best driver for your device. (Recommended) and
click Next. The following screen appears:
5. Ensure that the CD-ROM drive box is checked.
6. Insert the driver/utility disc into your CD-ROM drive and click Next.The
following screen appears:

USB Wireless Network Adapter User’s Manual
14
7. Click Next to continue. Windows 98 copies files to your hard disk drive, and
you see the following screen:
8. Click Finish to complete the installation.
9. Go to “Chapter 6 –Install and Use Configuration Utility”to install the
Configuration Utility.

USB Wireless Network Adapter User’s Manual
15
Uninstall Procedures Under Windows 98
In order to uninstall the Adapter from Windows 98, you must double click on the
“Network”icon in the “Control Panel”(Start -> Settings -> Control Panel).
Select the “USB Wireless Network Adapter”from the list and press the
“Remove”button. The system will prompt you to re-boot. Press "Yes" to re-boot.

USB Wireless Network Adapter User’s Manual
16
Chapter 4- Installation Procedures Under
Windows 2000
Use the procedures described in this chapter to install and configure the USB
Wireless Network Adapter under MS Windows 2000.
Throughout this Chapter it is assumed that you have a basic working knowledge
of Windows 2000 and of how to install new network adapters on them. However,
in this paragraph, some specific features of Windows 2000 are briefly explained.
What You Will Need
During the installation, you may be prompted to load operating system files from
the Windows installation disc. Please have this disc handy.
You will also need the Drivers/Utility CD provided with your package.
Note: In order to be able to install the Adapter on to your notebook/desktop PC
running under Windows 2000, you will need to log on as “Administrator”.
Installing the Driver Under Windows 2000
1. Connecting the Adapter to the USB port of a notebook or desktop PC. (Refer
to Connecting the USB Adapter at Chapter 2)
2. The Found New Hardware Wizard will indicate that Windows have
recognized a new device that has not been used before.

USB Wireless Network Adapter User’s Manual
17
3. Click Next to continue the installation. A screen appears prompting you to
select an installation method:
4. Select Search for a suitable driver for my device (recommended) and
click Next. The following screen appears:

USB Wireless Network Adapter User’s Manual
18
5. Ensure that the CD-ROM drives box is checked and insert the driver/utility
disc into CD-ROM drive. Click Next to continue. The following screen
appears:
6. Click Next to continue.

USB Wireless Network Adapter User’s Manual
19
7. Windows may display the message “Digital Signature Not Found”. Ignore
it by pressing “Yes”.Windows will start copying the files and then the
following screen appears:
8. Click Finish to complete the installation.
9. Go to “Chapter 6 –Install and Use Configuration Utility”to install the
Configuration Utility.

USB Wireless Network Adapter User’s Manual
20
How to Unplug the Device Under Windows 2000
After the successful installation of the Adapter, you will see an icon
corresponding to the device in the Windows taskbar for as long as the device is
connected to the PC.
If you want to unplug the device,double click on this icon. The dialog of Unplug
or Eject Hardware will appear.
Select USB Wireless Network Adapter and press “Stop”. Now it is safe to
unplug the device from the PC.
In case you unplug the device without having followed the above procedure,the
dialog Unsafe Removal of Device will appear reminding you the problems this
action may have caused. Press “OK”. It is recommended not to unplug the
device unless you have followed first the above procedure to stop the Adapter.
