TRENDnet TEW-211BRP User manual

TEW-211BRP AP Router
Quick Install Guide
Version 1.1 - April 2001
1

General Wireless AP System Connection
The general function of Wireless AP is defined as an “AP + Router”, and the connection is as follow
diagram.
Step 1
Plug in the power supply. The power LED will turn on to indicate power operation.
User may connect the WAN port to Cable / DSL modem. The WAN LED will indicate connection.
Connect the LAN port to a hub or switch.
2

Step 2
Open the web browser, and type 192.168.2.1 into to the URL address box. Then hit Enter.
Click on “ Start the Setup Wizard ”
When the login screen appears, type “ admin ” in the User Name box, and leave the Password field
blank. Click OK.
3

The default IP address of the LAN port is set to 192.168.2.1.
Click Next to accept the default settings.
By default, the WAN port is set to automatically obtain an IP address from your ISP, if ISP provides
DHCP server function.
To assign static IP for the WAN port, place a checkmark and enter the settings.
Click Next
4

DSL users:
If you are using a PPPoE client to connect to your DSL provider, then place a checkmark on the
first box, and enter the user name and password in the appropriate box.
Cable modem users:
If you are using a cable modem, then place a checkmark on the second box and enter the host and
domain name given by your cable provider.
Click Next.
The Router default wireless settings.
5

Click Next to accept the default settings.
If you are using a dial-up modem with the wireless router, place a checkmark in the box and enter
the settings for the dial-up connection.
Click Next.
6

Click “ Save and Restart, ” to finish the Setup Wizard.
After the Router has restarted, the installation is complete.
Step 3
To check the connection, open the web browser and go to your favorite website.
If you are unable to browse, please refer to the troubleshooting section in the user’s manual.
TEW-211BRP AP Default Settings
By default settings, the TEW-211BRP AP is regarded as an “AP Router”. The default settings are
shown following.
Note:
In WEB mode setup system, only one user allows to access setup program at one time i.e.
setup system will decline when other users to connect setup system.
User Name admin
Password
AP Router Name Wireless AP SOHO Wireless LAN
AP Router IP Address 192.168.2.1
AP Router Subnet Mask 255.255.255.0
10/100 Ethernet LAN IP 192.168.2.1
LAN MAC Address
10 Mbps Ethernet WAN IP Obtain from ISP via DHCP Can be manually configure
WAN MAC Address
WAN DHCP Client Enabled After 20 sec. Go to blank
RF ESSID Wireless
RF Channel 6
RF Roaming Disabled
Encryption Disabled
DHCP Server Enabled
NAT Routing Enabled
7
