TRENDnet TU2-H5PI User manual

TU2-H5PI
Quick Installation Guide

Table of Contents
Table of Contents
Version 11.20.2007
English ..................................................................................................... 1
1
2
4
1. Before You Start
2. How to Install .....................................................................................
................................................................................
Troubleshooting ........................................................................................

System Requirements
Application
?TU2-H5PI
?Driver CD-ROM
?Quick Installation Guide
Package Contents
1. Before You Start
English
1
USB Printer
5-Port USB 2.0
Host PCI Adapter
(TU2-H5PI)
USB Camera USB Mouse
USB Scanner
USB 2.0 Hard Drive
480Mbps USB 2.0
12Mbps USB 1.1 * * Backwards compatible with USB 1.1 at 12Mbps
?
?
?
?
?
32-bit PCI 2.2 slot
CD-ROM
CPU: 300MHz or above (Windows 2003 Server/XP/2000/ME/98SE)/
800MHz or above (Windows Vista)
Memory: 256MB RAM or above (Windows XP/2000/ME/98SE, Mac OS X
10.1~10.4)/ 512MB RAM or above (Windows Vista)
Windows 98SE/ME/2000/XP/2003 Server/Vista, Mac OS X 10.1~10.4

2. How to Install
English
2
Important! DO NOT install the PCI adapter in the computer until instructed to
do so.
1. Insert the Driver CD-ROM into
your computer's CD-ROM Drive
and then click Install Driver.
3. When prompted to reboot, select
No and then click Close.
2. A warning message will appear.
Click Continue Anyway.
(Windows XP only).
For Windows Users
Note: Please refer to your computer's user manual regarding hardware
installation.

English
3
7. After your computer reboots,
Windows will automatically
complete installation of your new
hardware.
6. Insert PC Card firmly into free PC
Card slot of desktop PC, and then
powerup computer.
8. Connect USB devices to the USB
ports.
Your installation is now complete.
4. Shutdown your computer.
5. Open your computer's case.
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.trendnet.com/register
Thank you for choosing TRENDnet

Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
Can I connect or disconnect the USB cable while the computer is on?
Yes, you can connect or disconnect the USB cable, or any external USB
device while the computer is on because the USB interface is Plug-and-Play and
hot-pluggable.
I have a USB 1.1 cable. Can it work with USB 2.0 devices?
Yes, it works but it may cause problems when connecting high-speed USB 2.0
external peripherals. Therefore it is recommended that you use a certified USB 2.0
cable.
After successfully installing the TU2-H5PI USB 2.0 PCI Adapter, I connected
my external USB device to the USB port, but it doesn't seem to work. What should
I do?
If you have an external AC power adapter that came with the external USB
device, connect the AC power adapter to the device and power on the device.
Also make sure that you have installed the correct driver for your external USB
device.
How do I install the TU2-H5PI on my Windows 98SE computer?
Follow the instructions below:
1. Follow steps 1-7 in Section 2 How to Install.
2. When the computer boots up, the Found New Hardware wizard appears.
Click Next.
3. When the Insert Disk window appears, insert your Windows 98SE CD into
your CD-ROM drive and then click OK.
4. Click Finish.
5. Repeat steps 1-4.
6. Connect USB devices to the USB ports.
If you still encounter problems or have any questions regarding the TU2-H5PI, please
contact TRENDnet's Technical Support Department.
