TEG-S16R
rev:04.23.2008
FEATURES
gigabit
• Boost office efficiency with this high performance 16-port Gigabit switch
• 16 x 10/100/1000Mbps RJ-45 Auto-MDIX Gigabit ports
• Enjoy 500Kbytes data buffering RAM and non-blocking architecture
• Provides a robust 32Gbps switching capacity
• Supports Jumbo Frame packet transfer (Max size up to 12.2Kbytes)
• Supports up to 8Kbytes MAC address entries
• Includes 802.3x Flow Control, Broadcast Storm protection and Store-and-Forward switching
• Windows, Linux, and Mac operating system ready
• Diagnostic LEDs and Plug & Play installation for quick troubleshooting and setup
• Rack mount or desktop ready
• Compact 11” wide, 1U design with rack mount kit included
• 5-Year Warranty
TEG-S16R (v1.0R)
16-Port Compact Gigabit Switch
The16-Port Gigabit Switch provides high bandwidth performance, ease of
use and reliability in a compact form factor.
Boost office efficiency with Gigabit speeds to the desktop. Move large
bandwidth intensive files faster and increase network backbone server
speeds.
The 11” wide metal chassis switch easily fits on a desk and comes with a
19“ rack mount kit. Store-and-forward switching, broadcast storm
protection, a 32Gbps switching capacity and an 8kbytes MAC Address
table provides an optimum network experience. 802.3x Flow Control for
full-duplex mode and back pressure Flow Control for half-duplex mode
ensures seamless data transmission.

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
NETWORKING SOLUTIONS
TEG-S16R (v1.0R)
16-Port Compact Gigabit Switch
Interface
Network Media
Data Transfer Rate
Data RAM Buffering
MAC Table
Transmission Method
Power
Temperature
Diagnostic LED
Humidity
• IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX • IEEE 802.3ab 1000Base-T
• 16 10/100/1000Mbps Auto-MDIX RJ-45 Ports
• Ethernet:UTP/ STP Cat.3, 4, 5, 5e
• 500KBytes Per Device
• 100-240VAC,50/60Hz,Internal Power Supply
• Power, Link/ACT, 10/100Mbps, 1000Mbps
• Operating: 0° ~ 40° C (32° ~ 104° F) Storage: -20° ~ 70° C (-4° ~ 158° F)
• Operating: 10%~90% (Non-Condensing) Storage: 5%~90% (Non-Condensign)
• 8Kbytes or 4096 Entries Per Device
• Store-And-Forward
Power Consumption
Standards
Hardware
SPECIFICATIONS
Protocol • CSMA / CD
• 280 x 180 x 45mm (11 x 7.09 x1.77 in.)
Dimensions (W x H x D)
Switch Fabric
• Gigabit: UTP/ STP Cat 5e, 6
• Fast Ethernet: UTP/STP Cat., 5e, 6
• Gigabit:2000Mbps (Full Duplex)
• 14 Watts(m)
Weight • 1.7 Kg. (3.75lb.)
• 32Gbps Forwarding Capacity
• CE, FCC
Certification
• Ethernet: 10Mbps/20Mbps (Half/Full Duplex) • Fast Ethernet: 100Mbps/200Mbps (Half/Full Duplex)
RELATED PRODUCTS
TEW-633GR 300Mbps Wireless N Gigabit Router
24-Port Gigabit Web Smart Switch
Gigabit PCI Adapter
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
PACKAGE CONTENTS
• TEG-S16R
• Multi-Language Quick Installation Guide
• Power cord
• Rack mounting kit
TEG-240WS
TEG-PCITXR
10/100/1000Mbps
16-Port Compact Gigabit Switch
(TEG-S16R)
Printers
Workstations with PCI Adapter
(TEG-PCITXR)
Laptop with Gigabit PC Card
(TEG-PCBUSR)
Server with Gigabit PCI Adapter
(TEG-PCITXR)
10/100Mbps Multi-Port
Print Server
(TE100-P21)
300Mbps Wireless N
Gigabit Router
(TEW-633GR)
Cable /DSL Modem
Internet
Gigabit PC Card
TEG-PCBUSR
