TRENDnet TEG-S081Fi User manual

The 8-Port 100Base-FX Layer 2 Managed Switch provides
exceptional performance, ease of use and flexibility for expanding
network operations. Utilizing a robust 3.8Gbps backplane, the
switch can easily accommodate multiple networks at 2km or more
with an optional GBIC SX or LX module. Advanced management
features include SNMP, VLAN, IGMP, and Port Security.
TEG-S081Fi
8-Port 100Base-FX Layer 2 Managed Switch
with GBIC Slot
TEG-S081Fi
rev:11.30.2005
• 8 x 100Base-FX SC type Multi-Mode Fiber Port
• 1 x 1000Base GBIC Slot for optional GBIC module
• Supports switch Fabric up to 3.8GBps
• Layer 2 Management Switch with Full Software Support
• IGMP Snooping with Query Mode Support for Multi-Media Application
• Supports Broadcast Storm Filtering
• Supports Port Status Control (Status, Auto-Negotiation, Speed, Duplex and Flow Control)
• Supports Port Trunking with Flexible Load Distribution Control and Fail-Over Functions
• Supports Port-Based VLAN and IEEE 802.1Q Tag-Based VLAN
• Supports IP Multicast, Port Mirroring, Spanning Tree, SNMP and RMON
• Supports Port Security and IEEE 802.1p Class of Services
• Store-and-Forward Switching Architecture with Non-Blocking Wire-Speed Performance
• Configuration via RS-232 Console Port, Telnet, and Web Browser (HTTP)
• TFTP Firmware Upgrade via Browser
• Configuration Save and Restore Feature Support
• 19” (1U) Rack Mount Design (kit included)
• 5-Year Warranty
FEATURESFEATURES

LED Display
Interface
Packet Forwarding and Filtering Rate
Cabling
Console Port
Protocol/Topology
Buffer Memory
Power
Power Consumption
Weight
Humidity
Safety Emissions
Dimensions
Temperature
• IEEE 802.3u 100Base-FX; IEEE 802.3z Gigabit Fiber/IEEE 802.3ab 1000Base-T
• Up to 3.8Gbps
• IEEE 802.3x Flow Control; IEEE 802.1D Spanning Tree
• Power, Link/Activity, Full Duplex/Collision
• 440 x 160 x 44mm (17.3 x 6.3 x 1.7 inch) (W x H x D)
• Operating: 0° ~ 45° C (32° ~ 113° F)
• 8 x 100Base-FX SC type Multi-Mode Fiber Port
• Gigabit: 1,488,000 packets per second per port
• Multi-Mode: (50/125um, 62.5/125um), 2km max
• RS-232, female 9-Pin Serial Port (M-M serial cable included)
• Input: 100~240VAC, 50/60Hz Internal Power Supply
• (CSMA/CD) / Star
• 2Mbits Data Buffer
• 8K MAC Address Entries
• 2.2 Kg. (4.85lb.)
• 17 watts
• 10% ~ 90% non-condensing
• FCC, CE
Filtering Address Table
Bandwidth
Standards
Hardware
SPECIFICATIONSSPECIFICATIONS
• IEEE 802.1q Tag-based VLAN; IEEE 802.1p Class of Service
• IEEE 802.3ad Link Aggregation; IEEE 802.1ad Port Trunk
• 100M Ethernet: 148,800 packets per second per port
• Storage: -40° ~ 70° C (-40° ~ 158° F)
• 1 x 1000Base GBIC slot for optional GBIC module (3.3V DC power)
• Single-Mode: (8/125um, 10/125um)
Management
Trunk
Class of Service
QoS
VLAN
IP Multicast
Filter Database
Port Mirror
Broadcast Control
Spanning Tree
RFC Standard
• Web Management, RS-232 Console Management, Telnet
• IEEE 802.3ad Trunk with LACP. Max 4 Groups ( up to 4 Ports per group)
• Supports High and Low Priority
• Supports 8 Levels of Priority and Mapping to High/Low Priority Queue for Class of Service
• Up to 256 VLAN groups and up to 4094 VLAN ID
• IGMP Snooping up to 256 groups
• Port Static MAC address lock, MAC filter and Port Security
• Up to 8 ports
• None, 5%, 10%, 15%, 20%, 25%
• IEEE 802.1d Support
• RFC 1157 SNMP, RFC 1213 MIB II, Bridge MIB, RFC 1643 Ethernet Like, RFC 1493 Bridge MIB, RFC 1757 RMON1,
RFC 1215 Trap
Wireless
• 2 Types of Query Mode: Enable/Disable or Auto Query
8-Port 100Base-FX Layer 2 Managed Switch with GBIC Slot
TEG-S081Fi

8-Port 100Base-FX Layer 2 Managed Switch with GBIC Slot
TEG-S081Fi
RELATED PRODUCTSRELATED PRODUCTS
PACKAGE CONTENTSPACKAGE CONTENTS
TE100-S810Fi
TE100-S800i 8-Port 10/100Mbps Layer 2 Managed Switch
• Power Cord
• RS-232 Cable
• Rack Mount Kit
8-Port 10/100Mbps Layer 2 Managed Switch
with 100Base-FX Port
• TEG-S081Fi
• User's Guide
ORDERING INFORMATIONORDERING INFORMATION
To Order Please Call:
1-888-326-6061
3135 Kashiwa Street,Torrance, CA 90505 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
