TRENDnet TE-T2 User manual

The TE-T2 Ethernet transceiver is IEEE 802.3 standard
Attachment Unit Interfaces (AUI) that provides quick and easy
attachment from a host to any Ethernet media types, including
thin coax, 10Base-T unshielded twisted-pair and optic fiber.
The transceiver is attached to the host via a DB-15 AUI
connector.
Using VLSI transceiver chips for high hardware reliability, the
TE-T2 transceiver also provides heartbeat, jabber and
isolation voltage. To enhance installation compatibility, a SQE
jumper is added for selection of the Heartbeat function as well
as diagnostic LEDs as standard features.
TE-T2
AUI-to-BNC Transceiver
Comply with IEEE 802.3 and Ethernet 1.0/2.0
specifications
Selectable SQE (heartbeat) enable/disable
Isolation voltage between network cable and transceiver
cable
Directly attach to host's AUI connector without transceiver
cable
10Mbps transfer rate
5 Year Warranty
FEATURES PRODUCT INFORMATION
TE-T2: AUI-to-BNC Transceiver
TE-TT: AUI-to-RJ-45 Transceiver
TE-TF: AUI-to-ST Transceiver
TE-TFT: UTP to ST Transceiver
for Fiber Optic Cable
TE-TC: BNC-to-UTP Transceiver
To Order Please Call:
1-888-326-6061
ORDERING INFORMATIONORDERING INFORMATION
SPECIFICATIONS
Standards:
IEEE 802.3 10Base-2 and 10Base-5
Connectors:
4 BNC and 4 AUI
Dimensions:
441mm x 123mm x 45mm
•
•
•
TE-T2 (11-17-2002)
