TRENDnet TEW-652BRP User manual

The Wireless N Home Router delivers the highest level of security with 12x
the speed and 4x the range of wireless g products. Quickly install the router
and use it with TRENDnet wireless n adapters to receive the full benefits of
wireless n speed and coverage.
The latest in wireless encryption and a secure firewall provide the ultimate
in wired and wireless security. Advanced Multiple Input Multiple Output
(MIMO) antenna technology delivers expansive coverage and eliminates
dead spots. A quick and intuitive installation process, one touch wireless
connection using Wi-Fi Protected Setup and advanced management
capabilities make this product well suited for your most demanding home
networking needs.
TEW-652BRP(V1.0R)
Wireless N Home Router
TEW-652BRP
rev:07.30.2008
• Wi-Fi compliant with IEEE 802.11n and IEEE 802.11b/g standards
• 4 x 10/100Mbps Auto-MDIX LAN port and 1 x 10/100Mbps WAN port (Internet)
• Supports Cable/DSL modems with Dynamic IP, Static IP, PPPoE, PPTP, L2TP & BigPond connection types
• High-speed up to 300Mbps data rate using IEEE 802.11n connection
• 2 external antennas support high speed performance and great coverage with MIMO technology
• Firewall features Network Address Translation (NAT), and Stateful Packet Inspection (SPI) protects against DoS attacks
• Support Wi-Fi Protected Setup (WPS) for easy connection
• Universal Plug and Play (UPnP) and Application Level Gateway support for internet applications such as email, FTP, gaming,
remote desktop, Net Meeting, telnet and more
• Provides additional security of enable/disable wireless SSID, Internet Access Control (MAC Address, Domain & IP Filtering)
• Easy management via web browser and remote management
• Supports 64/128-bit WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK
• Works with Windows 95/98/NT/2000/XP/2003 Server/Vista, Linux and Mac OS
• Coverage up to 100 meters (330ft.) indoor;(depends on the environment)*
• Coverage up to 300 meters (980ft.) outdoor;(depends on the environment)*
• 3-Year Warranty
FEATURES
wireless

WPS Button
Connection Type
Logging
Media Access Protocol
• 1 x 10/100Mbps Auto-MDIX port (Internet)
• WEP(HEX/ASCII): 64/128-bit
• Dynamic IP, Static (Fixed) IP, PPPoE, PPTP, L2TP, BigPond
• 802.11n: up to 300Mbps
• 802.11b: -85dBm (typical) @ 11Mpbs
• Max. 90% (non-condensing)
• UPnP IGD 1.0 compliant
• 245g (8.6 oz)
• Operation: 0~ 40C (32F~ 104F); Storage: -10~ 70C (14F~158 F)
• 2412~2484MHz ISM band
• CSMA/CA with ACK
• 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps
Antenna
Wireless
Standards
Hardware
SPECIFICATIONS
• Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX)
LAN
• Enable Wi-Fi Protected Setup function
• 2 x 2dBi detachable dipole antennas
• 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps
Data Rate
Humidity
Certifications
Frequency
• CE, FCC
• Wireless: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n (draft 2.0)
• 4 x 10/100Mbps Auto-MDIX port
WAN
LED Indicator
• 5 types of event logging; email report
• 5V DC, 2.5A external power adapter
• 7watts (max.)
• Power, LAN1~LAN4, WAN, WLAN
UPnP
DMZ
Weight
• 802.11g: -68dBm (typical) @ 54Mbps
• 1~ 11 (FCC), 1~13 (ETSI)
• 150 x 110 x 30 mm (5.9 x 4.3 x 1.1 inches)
Power Adapter
TEW-652BRP(V1.0R)
Wireless N Home Router
DNS
Internet Access Control
• DMZ host & Virtual Servers
• Static or WAN assigned DNS servers; 3 verified services for DDNS
• MAC Address Filter, Domain/URL Filter, Protocol/IP Filter
Security
Output Power
Receiving Sensitivity
Channels
• WPA(AES/TKIP): WPA/WPA2, WPA-PSK/WPA2-PSK
• Enable/Disable broadcast SSID
• 802.11b: 17dBm (typical)
• 802.11g: 13dBm (typical)
• 802.11n: 13dBm (typical)
• 802.11n: -62dBm (typical) @ 300Mbps
Power Consumption
Dimension (L x W x H)
Temperature
TEW-652BRP
rev:07.30.2008
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on
interference, network traffic, building materials and other conditions.

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
RELATED PRODUCTS
PACKAGE CONTENTS
• Power adapter (5V DC, 2.5A)
• TEW-652BRP
• Multi-Language Quick Installation Guide
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
NETWORKING SOLUTIONS
TEW-642EC
TEW-643PI
TEW-641PC Wireless N PC Card
300Mbps Wireless N Express Card
Wireless N PCI Adapter
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
• Cat. 5 Ethernet cable (1.5m/5ft.)
TEW-652BRP(V1.0R)
Wireless N Home Router
TEW-644UB Wireless N USB Adapter
300Mbps, share multimedia throughout the house
Wireless N Home Router
(TEW-652BRP)
Notebook with
Wireless N PC Card
(TEW-641PC)
Cable/DSL
Modem
Workstation with
Wireless N PCI Adapter
(TEW-643PI)
Internet
Workstation with
Wireless N USB Adapter
(TEW-644UB)
• CD-ROM (User’s Guide)
