TREX PolySwitch User manual

PolySwitch
USER MANUAL

A TRUE HARDWIRE STEREO A-B SWITCH
Congratulations on your purchase of PolySwitch AB, our exceptionally
versatile stereo switch for any musician who needs high-quality stereo
switching.
PolySwitch AB lets you send your mono or stereo signal from your in-
strument to two separate stereo amplifiers or other output destinations.
Or, you can go the other way – sending two stereo signals to a single
input destination.
PolySwitch AB might look like a very simple tool, but in fact it offers
more power and versatility than you might think. Turn the page to learn
how to make the most it!

JUST SWITCH IT!
In and outs
PolySwitch AB features 1 set of stereo in-
puts (input L, input R) and 2 sets of stereo
outputs (output A-L, output A-R, output
B-L, output B-R). To use PolySwitch AB to
send your instrument signal to 2 separate
amplires (for example), just plug your
instrument into the input jack(s) and
run lines from the output jacks to your 2
ampliers. Use the footswitch on the top
of the unit to switch between the A and
B outputs.
Mixed signals
Your PolySwitch AB can also work
“backwards”, letting you send signals
from 2 dierent instruments into a single
amplier, mixer or other unit. To use
PolySwitch AB in this way, simply plug
your instruments into the output jacks,
and use a line from your input jack(s) to
your amplifier or other destination.
Buffer switch
On the back of your PolySwitch AB,
you’ll find the buffer on/buffer off
switch. In the on position, this switch
will boost your input signal to com-
pensate for signal loss due to extra
long cables or other factors. Note
that the buffer function only works
when sending an instrument signal
to amplifiers – not “backwards” as
described under Mixed signals on
the previous page.
Warning: Do not attempt to connect
PolySwitch AB between an amplifier
and speakers, as this can permanent-
ly damage the unit. DC IN
BUFFER
AMP 2
AMP 1
SWITCHING BETWEEN TWO AMPS

DC IN
BUFFER
AMP
CLEAN
2 CHANNEL AMP
LEAD
SWITCHING BETWEEN TWO GUITARS SWITCHING BETWEEN TWO CHANNELS

KEYBOARD 1 KEYBOARD 2
MIXER
SWITCHING BETWEEN TWO KEYBOARDS TECHNICAL SPECIFICATIONS
Input Impedance @ 1KHz with buer OFF 3,5MOhm
Input Impedance @ 1KHz with buer ON 862KOhm
Output Impedance @ 1KHz with buer OFF >10MOhm
Output Impedance @ 1KHz with buer ON 120Ohm
Power supply 9V DC (T-Rex FuelTank)
Minimum Power supply Voltage 8V DC
Maximum Power supply Voltage 12, 5V DC
Current Draw @ 9V DC 19mA
Maximum input signal Vp/p with buer OFF Input = Output. No limit
Maximum input signal Vp/p with buer ON 4Vp/p
Battery Type 9V battery 6F22
Battery Life 5 to 8 hours
External connectors Input left, Input right, Out(A) left /right
Out(B) left/right
Controls On/O - buer
Pedal size incl. knobs (W x H x D) 100 x 55 x 120 mm / 3,9 x 2,2 x 4,7 inch
Weight
(excl. battery and packaging) 0,335 kg / 11.8 oz

RoHS
REACh
T-REX WARRANTY CONDITIONS
T-Rex oers a 2-year warranty on all our products. In the unlikely event of a
malfunction, please contact our technical support at info@t-rex-eects.com
before sending us the product for repair. When the product has been sent to
us at sender’s cost, we will repair or replace your product and send it back to
you - free of charge and usually within 3 weeks (shipping not included). The
product needs to be accompanied by a copy of your receipt, serial number,
return address, phone number, e-mail address and a brief explanation of
the problem. Please note that we cannot replace a product until we have
received it here in Denmark.
The warranty is lost if the product has been damaged by alteration, misuse,
accident, or neglect; or if the product has been repaired or serviced by
persons not authorized by T-Rex. Read more about warranty conditions at
www.t-rex-eects.com.
ABOUT T-REX
Based in Vejle, Denmark, T-Rex Engineering makes classic and sig-
nature eects pedals for the world’s best musicians. Our approach
blends hi-tech innovation with old-world craftsmanship – always
in the service of killer tone.
EU REGULATIONS • ENVIRONMENT PROTECTION
T-Rex accepts and follows the regulations and directives issued
by the EU. We nd these environment protecting regulations very
good, and we are happy to follow them.

Steen Meldgaard Laursen
Managing Director
ISSUED IN VEJLE, 2008
Lars Dahl-Jørgensen
Development Director
Sebastian Jensen
Production Director
T-Rex Engineering ApS
www.t-rex-eects.com
