TREX ToneBug Series User manual

ToneBug
User manual
Chorus + Flanger

CONGRATULATIONS
on your purchase of Chorus + Flanger, part of our ToneBug series
of eect pedals that combine great-sounding T-Rex tone, premium
retro design, and aordable pricing.
Chorus + Flanger gives you two must-have eects in one: a cool 80s-
sounding chorus and a freaked-out anger. You’ll recognise both of
these classic eects right away, as you bask in the amazing vingtage
tone that’s made T-Rex the rst choice for some of the world’s great-
est guitar heros.
Using Chorus + Flanger couldn’t be easier. Just turn the page to get
started.

5 STEPS TO WORLD OF EFFECTS
Using your ToneBug Chorus + Flanger
Insert a 9V alkaline battery or connect to an electrical outlet using the
T-Rex Fuel Tank power supply (not included).
Plug your guitar into the INPUT jack, and run a lead from the OUTPUT
jack into your amp.
Use the Chorus/Flanger switch to choose which eect you want.
Use the RATE knob to set the speed of your modulation, and the
DEPTH knob to choose how “heavy” you want the chorused or
anged eect to be.
Then use the LEVEL knob to set your overall output volume – and go!
TECHNICAL SPECIFICATIONS:
Input Impedance @ 1KHz Higher than 1 M Ohm
Output Impedance @ 1KHz Lower than 1 K Ohm
Power supply 9V DC
Minimum Power supply Voltage 8V DC
Maximum Power supply Voltage 12,5V DC
Current Draw @ 9V DC 75 mA
Maximum input signal Vp/p 2,5 Vp/p
Battery Type 9V battery 6F22 Alkaline
Battery Life 0,5 to 1 Hours
External connectors Input Jack. Output Jack, 9V DC Jack (center
pin negative)
Controls On/O, Rate, Flanger, Depth, Chorus
Depth 120 mm
Width 78 mm
Height 60 mm
Weight (excl. battery) 0,404 Kg

SAMPLE SETTINGS:
80S ELECTRIC
MODE: Chorus
RATE: 3 o’clock
DEPTH: 2 o’clock
ACOUSTIC DREAM
MODE: Chorus
RATE: 11 o’clock
DEPTH: 5 o’clock
SLOW FLANGE
MODE: Flanger
RATE: 8 o’clock
DEPTH: 2 o’clock
CYCLONE
MODE: Flanger
RATE: 2 o’clock
DEPTH: 5 o’clock
