Tribest Solostar4 SS-420 User manual

Operation Manual / Mode d’emploi /
Bedienungsanleitung / Manual de uso
SS-4200
with BPA-Free Components / avec des composants sans BPA /
mit BPA-freien Komponenten / con componentes sin BPA
SAVE THIS MANUAL-KEEP IT HANDY FOR QUICK REFERENCE / CONSERVEZ CE MODE D’EMPLOI
GARDEZ-LE À PORTÉE DE MAIN POUR POUVOIR Y FAIRE RÉFÉRENCE / BEWAHREN SIE DIESE AN-
LEITUNG AUF – HALTEN SIE SIE ZUM SCHNELLEN NACHSCHLAGEN GRIFFBEREIT / GUARDE ESTE
MANUAL EN UN LUGAR ACCESIBLE POR SI NECESITA CONSULTARLO
READ INSTRUCTIONS BEFORE USING / LISEZ LES INSTRUCTIONS AVANT UTILISATION / LESEN SIE VOR GEBRAUCH DIE
ANWEISUNGEN DURCH / ANTES DE USAR EL PRODUCTO, LEA LAS INSTRUCCIONES

3
EN
FR
LANGUAGES
• English............................................................................................................................................5
• Français.........................................................................................................................................27
• Deutsch..........................................................................................................................................49
• Español..........................................................................................................................................71

4

5
EN
WELCOME
Congratulations and welcome to the Tribest family! Your purchase of the Tribest®
Solostar®4 represents a decision that you made to live a healthier lifestyle. As with
every Tribest product, the Solostar 4’s sleek design and rich features are the result
of smart choices that were made to achieve one thing: Making Healthy Living Easy.
Due to its smart design, the Solostar 4 produces up to 33% more torque while using
up to 20% less electricity. More torque means less jamming and less electricity
means savings on your monthly utility bill all while reducing your carbon footprint.
The sleek, modern design takes up less space while looking beautiful on your
kitchen countertop. The optional Vegetable Slicer and Spiralizer attachments add the
versatility you need to reduce the clutter you get from having too many machines.
The Solostar 4 is compatible with the ZStar Manual Conversion Kit, so you are free to
take your juicer with you when you are on the go. And, like every Tribest product, all
food contact parts are made from BPA- and BPS-free materials.
The Solostar 4’s single auger cold press juicing system operates as slow as 47 RPM
to ensure the gentlest juice extraction process possible. The slow and gentle process
preserves more nutrients and enzymes, resulting in healthier juice. The Dual-Stage
Extraction Process crushes and presses produce for maximum juice yields. The Ultem
auger is 8x stronger than other types of plastic, which allows for an aggressive auger
design that makes it easy to feed your produce into the juicer. So, you get better
juice, more of it, and it is easier to use.
Please carefully unpack your Solostar 4 and check to see that all the parts were
included. Take the time to assemble and disassemble you Solostar 4 a few times
to become familiar with the process and wash the juicing parts before using it for
the first time. Please take the time to read through the entire operation manual for
proper use and care instructions. If you have any questions, comments, or need
any tips, please do not hesitate to contact us at 1-888-254-7336, or via email at
[email protected].
We graciously ask that you rate the Solostar 4 at www.tribestlife.com. We appreciate
your feedback.

6

7
EN
TABLE OF CONTENTS
• Welcome...................................................................................................................5
• Important Safety Instructions......................................................................................8
• Juicer Part Description...............................................................................................9
• Solostar 4 Assembly and Operation......................................................,...................10
• Disassembling the Solostar 4...................................................................................13
• Cleaning the Solostar 4...........................................................................................13
• Troubleshooting.......................................................................................................15
• When You Need Service...........................................................................................16
• Warranty.................................................................................................................17
• Recipe Index...........................................................................................................19
• Product Specifications..............................................................................................26

8
IMPORTANT SAFETY INSTRUCTIONS
1. Please read all instructions carefully.
2. Do not submerge Main Body in water or other liquids to protect against the risk of
electric shock.
3. Do not touch the electric plug or outlet with wet hands to avoid electric shock.
4. While the Solostar 4 is in operation, avoid contact with its moving parts.
5. Unplug the Solostar 4 from the electrical outlet and be sure to switch the Solostar 4
off before assembling or disassembling and when not in use.
6. Do not operate any appliance with a damaged cord or plug, or if the Solostar 4
malfunctions, is dropped, or is damaged in any manner. Return the Solostar 4 to the
nearest authorized service center for examination and possible repair to prevent injury.
7. Close supervision is necessary when any appliances are used by or near children.
8. Use only included accessories. Do not put any articles such as spoons, forks or knives
into the Feeding Chute.
9. It is very dangerous to place fingers into the Feeding Chute while the Solostar 4
is in operation. Make sure to always use the provided Plastic Plunger to push down
ingredients.
10.Use of attachments not recommended or sold by the manufacturer may cause fire,
electrical shock, or injury.
11.Do not let the cord hang over the edge of a table or counter.
12.Do not let the cord contact any hot surface, such as the stove.
13.Please refer to “When You Need Service” in case your juicer is functioning abnormally.
14.Do not disassemble any parts other than those necessary for normal operation or
cleaning of your Solostar 4.
15.Continuous operation of the Solostar 4 (more than 30 min. of straight use) may
cause the motor to overheat. The motor will automatically shut down when over-heated
or overloaded. When this occurs, turn the machine off and let the motor cool off for
about 30 min before resuming operation.
16.Do not use hot or boiling water (above 104°F or 40°C) to clean the unit and parts.
Deformation or other damage may result.
17.Do not use any bleach or harsh chemicals.
18.Do not use outdoors.
19.This machine is made for household use only.
20.Please refer to the “Assembly and Operation” before operation.
21.Your Solostar 4 Juice Extractor should be grounded electrically for proper and safe
operation. Use only the 3-prong plug provided, the proper plug or the adapter complying
with the electrical safety code in your country.
22.Do not use the appliance for any other than its intended use.
SAVE THESE INSTRUCTIONS

9
EN
JUICER PART DESCRIPTION
1. Screen Locking Cap
2. Juicing Screen
3. Auger
4. Auger Housing/Feeding Chute
5. Funnel
6. Auger Housing Retaining Ring
7. Main Body
8. Homogenizing Screen
9. Juice Container
10. Pulp Container
12
1
13
2
14
3
15
5
4
7
6
8
11
9
10
16 17
18 19
20
11. Juice Container Strainer
12. Hand-held Strainer
13. Power Cord
14. Fettuccini Nozzle
15. Spagetti Nozzle
16. Juicing Nozzle
17. Homogenizing Nozzle
18. Plastic Plunger
19. Cleaning Brush
20. Funnel Lid

10
1. Insert the Auger into the Auger Housing and
attach to the front of the Main Body.
2. While holding the Auger Housing stable, turn
the Auger Housing Retaining Ring clockwise
(right) to lock the Auger Housing in place.
3. Pick the desired screen according to the
foods being used. Do not turn the screen.
Assemble as follows:
A. Juicing Screen: for juicing leafy greens,
vegetables and fruits.
(1) Place the Juicing Screen into the front end
of the Auger Housing. Make sure that the
side labeled ‘UPPER’ is facing upwards when
inserted.
(2) Put the Screen Locking Cap over the screen
and turn it counter-clockwise (left) to lock in
position.
(3) Attach the Juicing Nozzle to the Screen
Locking Cap by turning it counter-clockwise.
1
2
3
UPPER
A
JUICING SCREEN HOMOGENIZING SCREEN
1
3
SOLOSTAR 4 ASSEMBLY AND OPERATION

11
EN
B. Homogenizing Screen: for making rice cake/
breadstick, grinding (tomato, garlic, coffee
beans, etc.), pasta noodles (spaghetti or
fettuccini), or tofu.
(1) Attach the Homogenizing Screen into the Auger
Housing. Fasten and turn the Screen Locking
Cap counter-clockwise to lock in position.
(2) Place the desired nozzle into the Screen
Locking Cap and
(3) turn it counter- clockwise.
• Use the Homogenizing Nozzle for homogenizing
and grinding fresh garlic, onion, ginger or peppers.
• Do not use the Homogenizing Nozzle for dried
pepper, coffee beans, etc.
4. Place the Funnel over the Feeding Chute of Auger
Housing. Place the Juice Container underneath the
specified Juice Outlet and the Pulp Container
underneath the Nozzle. Attach the Power Cord to the
rear of the machine and plug the other end into an
electrical outlet.
5. Turn the Solostar 4 on and feed fruits and vegetables
in small amounts, into the Funnel. Use the Plastic
Plunger for assistance in pushing the food down.
• Food needs to be cut into smaller lengthwise
pieces before juicing.
• There may be some squeaking noises while
operating, this is normal.
6. If any hard or foreign objects are put into the
Solostar 4 and results in the motor stopping, use
the Reverse Switch 2-3 times for about 2 to 3
seconds.
• When you need to use the Reverse Switch
during normal operation, press the Stop
Switch first then the Reverse Switch.
B
4
5
2
On Switch
Stop Switch
Reverse Switch
6

12
NOTE:
• Fibrous vegetables or fruits with seeds can be juiced by using the Homogenizing Nozzle
instead of Juicing Nozzle.
• Small amounts of pulp can be in juices depending on the produce used.

13
EN
1. (1) Unlock the Auger Housing Retaining Ring
by turning it counter-clockwise and (2) pull the
Auger Housing to separate from the Main Body.
2. For easier cleaning, take the Auger Housing
to your sink and disassemble the parts under
running water.
3. (1) Separate the Screen Locking Cap and (2)
Nozzle from the Solostar 4 by turning clockwise.
4. Pull to remove the Screen and wash thoroughly
using the included Cleaning Brush.
5. Remove Auger from the Auger Housing.
6. Use lukewarm water with mild detergent to
wash all parts.
1
2
3
4
5
6
1
2
1 2
DISASSEMBLING AND CLEANING THE SOLOSTAR 4

14
NOTE:
• For easier disassembly, run the Reverse Switch on for 2-3 seconds, then turn off and
unplug the Solostar 4 before disassembly.
• Be sure to clean and properly store the parts of the Solostar 4 after every use. When
the Screens are not cleaned after use, the residue can dry, blocking the holes from
filtering and juicing.
• Do not use hot water or any harsh chemicals such as bleach to clean the Solostar 4. It
can result in the deformation of parts.
• To remove colored stains, soak parts in 70% White Wine Vinegar and 30% Water.

15
EN
TROUBLESHOOTING
SYMPTOM
There is no power.
Loud Noise
Difculty in feeding foods into the
machine
The motor has stopped
The Auger Housing is stuck or hard
to take out.
The Auger Housing does not t
onto the Main Body
Juice leaks from the back of the
Auger Housing
• Make sure the electrical cord is properly put into
the outlet.
• Make sure the Solostar 4 is leveled on a flat surface.
• Make sure that the unit corresponds to the voltage
in your country.
• Produce needs to be cut into smaller
lengthwise pieces.
• The Solostar 4 may be operating in reverse.
• You may have overloaded the Solostar 4; reduce
the volume of produce in half.
• Foreign substances may have been inserted.
• The Auger Housing Retaining Ring is not moving
or is too tight.
• Try pressing the reverse switch 2 –3 times.
• There may be foreign materials inside.
• You may have overloaded the unit; reduce the
amount of produce being put in.
SOLUTION

16
WHEN YOU NEED SERVICE
In the unlikely event that you do need service on your Solostar 4 Juice Extractor, or if it
fails to function properly while within the warranty period (normal household operation
only) - contact the nearest authorized Solostar 4 Service Center. PLEASE FOLLOW THE
INSTRUCTIONS BELOW:
If You Need Service:
• Call to obtain a Return Authorization Number to send your Solostar 4 or part back to
the service center. Explain the problem you are experiencing.
• Pack your Solostar 4 or part securely in the original shipping box. Make sure all
necessary parts are enclosed. Fill out the Service Request Form and enclose it in the
shipping box.
• Securely seal the shipping box.
• Address the box to the service center. Be sure to put your return address and the Return
Authorization Number on the outside of the package.
• It is always wise to insure the package against possible damages or loss in transit.
Ship prepaid.

17
EN
WARRANTY
We warrant to you, the end-user customer who has properly registered after purchasing
the Solostar 4 Juice Extractor with BPA Free components for valuable consideration, that
the plastic parts and motor will be free from defects in materials and workmanship for a
period of 15 years from the date of purchase. All other parts, including but not limited to
the Juice and Pulp Containers, Plastic Plunger are not subject to any warranty. Warranty does
NOT cover normal wear and tear of any plastic parts including the Auger and Juicing Screen.
In order for you to receive the benefits of this warranty, you are required to complete and
mail the Warranty Registration Card, containing all the requested information, to us within
ten (10) days following the purchase of your Solostar 4.
1. No warranty will be provided until after we have received the enclosed Warranty
Registration Card, containing all the requested information, within ten (10)
days of the date of original purchase. The warranty is only good for the original
purchaser for value. This warranty is non-transferable.
2. If the Solostar 4 exhibits defects while in normal household use, we, upon our actual
receipt of a written notice of such defects from you during the warranty period, we
will, at our option, either repair or replace the Solostar 4 which proves to be defective.
However, we have no such obligation to repair or replace until after you have, by
insured mail and in protective packaging*, delivered the Solostar 4 to the location of
your service center as set forth. Replacement Solostar 4 may be either new or
like new. Solostar 4 may contain re-manufactured or re-conditioned parts, which are
equivalent to new in performance or may have been subject to incidental use.
3. We do not warrant that the operation of the Solostar 4 will be uninterrupted or error
free. In no event shall our liability exceed the retail value of the Solostar 4.
4. All warranty and repair services must be performed at a warranty service center, which
is located within the country where the machine was originally purchased. However, in
the event that: [i] the machine must be serviced at a service center, which is not
located within the country where the machine was purchased; or [ii] there is no
service center within the country where the machine is located and must be shipped
to a service center in another country, then those service centers are responsible for
the parts and service only, and any and all costs relating to the shipping, delivery and
handling of the machine to and from those service center shall be the sole
responsibility of the owner.
This warranty does not cover defects resulting from: [a] failure to operate the Solostar 4 in
accordance with the instructions; [b] use of parts or supplies not provided or authorized by
us; [c] negligent, improper or inadequate maintenance; [d] service performed or attempted
by unauthorized service person; [e] damages, accidental or otherwise to the Solostar 4,
which are not directly caused by us or the manufacturer; or [f] damages resulting from abuse,
tampering, misuse, commercial use, or unauthorized modification of the Solostar 4.

18
WE MAKE NO OTHER EXPRESS OR IMPLIED WARRANTY OR CONDITION WHETHER
WRITTEN OR ORAL TO THE EXTENT ALLOWED BY LOCAL LAW, ANY IMPLIED WARRANTY
OF FITNESS FOR A PARTICULAR PURPOSE OR IMPLIED WARRANTY OR CONDITION OF
MERCHANTABILITY IS LIMITED TO ONE (1) YEAR. In the event that such limitation or
exclusion on the duration of an implied warranty is not allowed in the state or county
wherein you reside, the above limitation or exclusion will not apply. This warranty gives
you specific legal rights and protection, and you might also have other rights that vary
from state to state, or country to country.
TO THE EXTENT ALLOWED BY LOCAL LAW, THE REMEDIES IN THIS WARRANTY
STATEMENT ARE YOUR SOLE AND EXCLUSIVE REMEDIES. EXCEPT AS INDICATED
ABOVE, IN NO EVENT WILL WE BE LIABLE FOR DIRECT, SPECIAL, INCIDENTAL,
CONSEQUENTIAL (INCLUDING LOST PROFIT, OR OTHER DAMAGE, WHETHER BASED IN
CONTRACT, TORT, OR OTHERWISE. Some states or counties may not allow the exclusion
or limitation of incidental or consequential damages. If you reside in such a state or
county, the above limitation or exclusion may not be applicable.
Do not send your Solostar 4 back to the service center without a Return Authorization No.
*Save Original Shipping Box

19
EN
RECIPE INDEX
JUICE AND DRINKS
Citrus Blend................................................................................................................ 20
Apple Lemonade..........................................................................................................20
Wheatgrass Delight......................................................................................................20
Watermelon Quench.....................................................................................................20
Ambrosia Nectar..........................................................................................................21
Mellow Melon Punch................................................................................................... 21
Snappy Apple..............................................................................................................21
Dr. Walker’s Choice (#61)............................................................................................22
Green Tang.................................................................................................................22
Oriental Express...........................................................................................................22
RYE BREAD STICKS AND MOCHI (RICE CAKE)
Rye Raw Breadstick......................................................................................................23
Mochi (Rice Cake)....................................................................................................... 23
PASTA AND NOODLES................................................................................................23
PÂTÉ AND CROQUETTE
Cashew-Curry Croquettes.............................................................................................24
Pecan Pleasers............................................................................................................24
DESSERT
Cashew Poppy............................................................................................................ 25
Banana-Blueberry Ice Cream Pie (Uncooked).................................................................25

20
JUICE AND DRINKS
Citrus Blend
2 small grapefruit (peeled and cut into 4 to 6 pieces)
3 medium sized oranges (peeled and cut into 4 pieces)
½ small lemon (peeled and cut into 2 pieces)
½ small lime (peeled and cut into 2 pieces)
NOTE: 1) For sweeter taste use less lemon and lime.
2) It is not necessary to peel the lemon or lime.
Method: Juice all together and enjoy.
Apple Lemonade
3 farm apples (Yellow Delicious, Pippin, or Granny Smith)
3 medium sized oranges (peeled and cut into 4 pieces)
½ lemon (peel is optional for sweeter flavor)
Method: Juice all together and enjoy.
Wheatgrass Delight
4 handfuls Wheatgrass
4 carrots (cut in 2 to 4 pieces)
1 firm apple (cut into 6 pieces)
Thin slice Ginger
Method: Juice all together and enjoy.
Watermelon Quench
1 Watermelon (with seeds, if organically grown, add rind also)
Method:
1. Slice watermelon into pieces that fit easily into the feeding chute of the juicer.
2. Juice and enjoy on a hot summer day.
