Tribit XSound Go TS-BTS20 User manual

USER MANUAL
Portable Wireless Speaker
XSound Go
深圳市千岸科技有限公司
TS-BTS20 蓝牙音箱
2020-05-29
产品名称
公司名称
确认/打样时间
说明书尺寸: 60*80mm (单页尺寸)
说明书材质: 封面95g铜版纸 内页80g书纸
说明书工艺: 册子
打样信息备注: 无问题/XXX
TS-BTS20
Find more about Declaration of Confirmity, please click the below link
to download:
Http://files.tribit.com/BTS20-DOC-EN.pdf
Um mehr über die Konformitätserklärung zu erfahren, klicken Sie bitte
auf den folgenden Link: Http://files.tribit.com/BTS20-DOC-DE.pdf

Avoid dropping.
Do not disassemble.
Avoid extrame temperatures.
Do not use the device outdoors during
thunderstorms.
Do not use any corrosive cleaner/oil to clean.
Safety instructions
Bluetooth version: V5.0
Support: A2DP, AVRCP, HFP, HSP
Output power: 2 x 8W
Battery: 3.7V, 4400mAh
Battery charge time: 5 hour
Input: DC5V/1A
Dimension: 175 x 59 x 56 (mm)
Weight: 380g
Specification
English User Manual
取扱説明書
Benutzerhandbuch
Manuale Utente
Guide Utilisateur
Manual de Usuario
Contents:
-1-
.............................
............................................
.............................
...................................
.............................
1
13
21
30
39
............................. 48

What’s in the box Overview buttons & Indicators
Lanyard
USB-C Cable
XSound Go
User Manual
Power on/off
Bluetooth
Play/Pause
Volume -
Volume +
Indicator
Microphone
-3--2-
USER MANUAL
Portable Wireless Speaker
XSound Go
TS-BTS20

XSound Go
AUX DC 5V
Bluetooth connectionConnections
Bluetooth ON
1
2
Tribit XSound Go
3
AUX in Charging
-5--4-

Stereo Mode
-7--6-
1. Make sure both speakers are on. 2. Press on one of the speakers to enter
pairing state.
3. Press on the other speaker for 5s,
then release the button to enter Stereo
pairing when you hear the “Stereo mode”.
When you hear “Left chanel” on the left
speaker and “Right chanel” on the right
speaker, the “Stereo mode” is on.

Buttons
Indicator
Indicator Status
Blue indicator flashes slowly Reconnection mode
Blue indicator flashes quickly Bluetooth pairing mode
Blue indicator keeps on Pairing has been successful
Red indicator flashes slowly Low battery power (<15%),
charge the speaker as
required
Red indicator flashes quickly Low battery power (<2%)
and will automatically
power off after 5s.charge
the speaker immediately
Reset
If this speaker has some problem, you can try to
press and hold “Volume +” and “Volume –” button
simultaneously for 5 seconds to reset，and then
pairing again (delete the old pairing in your device).
Changes or modifications not expressly
approved by the party responsible for
compliancecouldvoidtheuser'sauthorityto
operate the equipment.This equipment has
been tested and found to comply with the
limitsforaClassBdigitaldevice,pursuantto
Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection
against harmful interference in a residential
installation.
FCC Statement
Button Operation & Function
Power on/off Press to turn on/off
Bluetooth Press to enter pairing mode
Volume + Press to increase the volume level
Volume - Press to decrease the volume level
Play/Pause Press to play/pause Music and
answer/end call
Long press to reject a call
Press twice to skip to next track
Press triple to skip to Previous track
-9--8-

--Reorientorrelocatethereceivingantenna.
-- Increase the separation between the
equipmentandreceiver.
--Connecttheequipmentintoanoutletona
circuit different from that to which the
receiverisconnected.
-- Consult the dealer or an experienced
radio/TVtechnicianforhelp
Thisdevicecomplieswithpart15oftheFCC
rules. Operation is subject to the following
twoconditions(1)thisdevicemaynotcause
harmful interference, and (2) this device
must accept any interference received,
including interference that may cause
undesiredoperation.
Customer service
18-month limited warranty
For FAQS and more information, please
Email to:
support@tribitaudio,com
This equipment generates uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions,maycauseharmful interference
to radio communications. However, there is
noguaranteethatinterferencewillnotoccur
in a particular installation.If this equipment
does cause harmful interference to radio or
t e l e v i s i o n  r e c e p t i o n ,  w h i c h  c a n  b e
determinedbyturningtheequipmentoffand
on, the user is encouraged to try to correct
the interference by one or more of the
followingmeasures:
-11-
-10-
*RFwarningforMobiledevice:
This equipment complies with FCC radiation
exposurelimitsset forth for an uncontrolled
environment. This equipment should be
installed and operated with minimum
distance 20cm between the radiator & your
body.
