JBL®Studio 220
2-way 4" Bookshelf Loudspeakers
Legendary sound. Flexible placement.
For those who know what they’re looking for when it comes to a loudspeaker system – and who want
it flexible besides – we give you the new JBL Studio 220 2-way bookshelf loudspeakers.
As part of the groundbreaking 9-piece JBL Studio 2 loudspeaker series, the Studio 220 propels
you into a world where legacy sound-craft and advanced technology go hand-in-hand in shaping a
listening experience like none before. The Studio 220’s 4" PolyPlas midrange driver is designed to
bring you pitch-perfect vocal clarity and tight, accurate bass. Add to that the built-in High Definition
Imaging (HDI) waveguide design and the 1" CMMD Lite high-frequency driver, and you’ve got a loud-
speaker that takes its cues from JBL’s own legendary M2 Master Reference Monitor. Combine this
with the sleek, urbane design of the loudspeaker itself – both inside and out – and you’re dealing with
a rare breed of sonic horsepower and brainpower ready to define its era.
1" CMMD®Lite high-frequency driver for crisp, clean, powerful
highs with low-distortion and wide dynamics
High Definition Imaging (HDI) waveguide design for astounding
imaging, natural balance, and remarkable high-frequency detail at
any position in the room
4" PolyPlas driver enhances vocal clarity and delivers tight,
extended bass response
Solid cabinet construction with soft-rounded edges and no visible
fasteners
Gloss black top panel adds a touch of elegance to the sleek
cabinet design
Soft-touch paint covers driver trim ring for a clean, timeless look
Rear-firing Slipstream bass port eliminates bass turbulence
and audible distortion
Available in two attractive finishes: Black and Espresso Woodgrain

JBL®Studio 220
2-way 4" Bookshelf Loudspeakers
Features
4" PolyPlas driver delivers unrivaled purity and power
We have years of JBL acoustic testing under our belt to back our sound up. With its 4" PolyPlas driver
delivering unrivaled midrange accuracy and power, we’ll let a masterpiece speak for itself.
1" CMMD®Lite high-frequency driver and High Definition Imaging (HDI) waveguide
bring cinema-grade sound to your listening experience
The consummation of 67 years of pioneering sound research at our JBL labs, the Studio 220 in-
corporates bold technologies like a High Definition Imaging (HDI) waveguide and a 1" CMMD Lite
high-frequency driver into its design. Together, these advances let you experience your sound
cinematically – in all its precision imaging, high-frequency detail, natural balance, and full spectrum
mastery.
Visually striking 21st century design features that can’t fail to seduce
The JBL way is to make it look as good as it sounds. And with the Studio 220, we’ve made no
exception. With 21st century elegance that incorporates soft-rounded edges, black gloss paneling,
and soft-touch paint, we’ve built something that seduces the eye as much as it commands the ear.
What’s in the box:
JBL®Studio 220 2-way 4" Bookshelf Loudspeaker x 2
Owner’s Manual
Rubber Cushion Pads x 8
Product specifications:
Type: 2-way 4" Bookshelf Loudspeakers
100mm (4") PolyPlas low-frequency transducer
High Definition Imaging (HDI) horn design
- 25mm (1") CMMD®Lite high frequency dome
Recommended amplifier power: 20 – 125W
Frequency response: 60Hz – 22kHz
Sensitivity: 86dB
Impedance: 8 Ohms
Slipstream rear-firing bass port
Gold-plated binding-post speaker terminals
Dimensions (H x W x D): 260mm x 168mm x 180mm
(10-1/4" x 6-5/8" x 7-3/32")
Weight: 3.7 kg (8.2 lb)
