Trinabess Trinahome-t series User manual

Version 2.0

Installation Manual

Solar Battery Hybrid System

–T Series (N6052T)

Prelude

All information in this documentation has been compiled

and checked with most care. Despite of this, faults or

deviations cannot be completely excluded. We assume no

liability therefore.

The relevant up-to-date version can be obtained from

http://www.trinaenergystorage.com/

The details of this documentation are the property of

Trinabess.

Using and publicizing this documentation, even if only in

parts require the written consent of Trinabess.

Trina Energy Storage Solutions (Jiangsu) Co., Ltd. (Trinabess)

NO. 2 Tianhe Road, Trina PV Park, New District, Changzhou, Jiangsu,

P.R.China.

Tel: +86 519 8517 6686

[email protected]

Legal Disclaimer

Published by

N6052T Solar Battery Hybrid System Installation Manual

Contents

1. Safety

1.1 How To Use This Manual

1.2 Safety Rules

1.3 Warning Notices Affixed To The Device

1.4 Important Safety Information

1.5 Disposal

1.6 Exclusion of Liability

2. Description

2.1 General System Description

2.2 System Connection

3. System Installation

3.1 Unpacking The Device

3.1.1 Before Unpacking

3.1.2 Mounting

3.1.3 Packing List

3.2 Mounting

3.2.1 Mounting Inverter

3.2.2 Mounting Battery Packs

3.2.3 Mounting Smart Meter

3.2.4 Mounting Distribution Box

3.3 System Connection

3.3.1 Battery Packs Connection

3.3.2 System cable connection

3.4 Technical Service

Read this installation manual before you start

Thank you for purchasing our highly reliable and efficient hybrid solution . This N6052T

hybrid system is rated IP65 inverter and IP21 battery packs, which is rated for dusty or

humid environments and is only suitable for indoor installation.

If you are reading the electronic version of the manual, please note that you can

click the content to find information you want quickly. All underlined characters are

clickable. A phrase named ‘Back to Top’ at the bottom of each chapter can help

you go back to the first page quickly.

Before using this device, please ensure that you have read this manual including

installation and safety operation carefully.

If you have any difficulty during installation or operation, please refer to this manual or

send email to [email protected], we will help to solve your problems as soon

as possible.
