BDM-300X2-240A(-D) & BDM-300X2-208A(-D)
BDM-300X2-AU(-D) & BDM-300X2-EU(-D)
Installan and Operan Manual

COMPANY PROFILE
1. INTRODUCTION
1.1 Prex
1.2 Grid-ed PV System
1.3 How to Use This Manual
1.4 Label
2. SAFETY INSTRUCTION
3. FCC COMPLIANCE
4. INSTALLATION
Parts Included
Other Parts and Tools Required
Lightning Surge Suppression
Installaon Procedure
Step 1 - Install the AC Branch Circuit Juncon Box
Step 2 - Aach the BDM-300X2 to the Racking
Step 3 - Connect the BDM-300X2 Wiring Harnesses
Step 4- Ground the System
Step 5 - Complete the connecon map and
connect the PV Modules
5. COMMISSIONING
6. OPERATING INSTRUCTIONS
7. TROUBLRSHOOTING MAINTENANCE
8. SPECIFICATION
9. WARRANTY AND PRODUCTION INFORMATION
CONTENTS
01
02
02
02
02
02
03
03
04
04
04
04
04
05
06
07
08
09
10
11
12
14
16

COMPANY PROFILE
Northern Electric & Power Inc. (NEP) was founded in the United States and has
manufacturing and R&D facilies in China. The mission of the company is to
develop cung-edge clean energy technologies and provide state-of-the-art solar
inverter products to its customers. The rst round of investment to the company
was US$20 Million, with a planned total investment of US$50 Million. The company
is headquartered in the city of Tsingtao, a major industrial center and trading port
in the northeastern China. The company campus occupies more than 18 acres in
the Tsingtao Export Processing Zone, and has more than 650,000 square feet
building space. The campus is planned to be connected through a micro smart grid
demo community and powered by electricity from solar, wind and micro turbines.
Outside China, the company has operaon oces in Chicago, U.S. and Vancouver,
Canada.
The technology founders of the company are well-known experts in the elds of
power electronics, automac control, signal processing, and communicaons.
Each of the founders has mulple U.S. and world patents in their specialty areas.
They received Ph.D. degrees from top universies in North America, and each has
more than 10 years engineering and management experiences in leading U.S.
companies.
NEP has a complete product line of grid-ed solar inverters, including 180W~500W
micro inverters, 1.5kW~5kW single phase solar inverters, and 10kW~500kW three-
phase solar inverters. Field deployment results demonstrated high system
eciency and reliability of NEP solar inverters.
NEP is commied to develop Clean, Reliable, Affordable and Efficient (CARE)
products for worldwide customers.
01
0 1

1. INTRODUCTION
1.1 Prex
Dear customer, thank you for choosing the BDM-300X2 micro inverter from NEP.
We hope you will nd our products meet your need for renewable energy.
Meanme, we appreciate your feedback regarding our products.
1.2 Grid-ed PV System
Grid-ed PV system consists of PV panels, grid-ed inverter and juncon boxes.
The DC output from the PV panels is converted into AC energy and feedback to the
grid through the BDM-300X2. BDM-300X2 PV micro inverter contains isolaon
transformer with basic insulaon between PV input and AC grid output.
1.3 Hw tUse This Manual
This manual provides detailed product informaon and installaon instrucons
for the BDM-300X2 micro solar inverter. Please read through this manual before
installaon and operaon.
WARNING: This indicates a situaon where failure to follow instrucons
may be a safety hazard or cause equipment malfuncon. Use extreme
cauon and follow instrucons carefully.
1.4 Label
Label is located on the side of the inverter. The informaon on the label includes
technical data as well as type and serial number of the device. Safety instrucons
are listed and explained below:
Danger!
The term “danger” describes an issue which, if ignored can cause
personal injury.
Aenon!
With the term “aenon” a circumstance is listed which may cause
property damage if disregarded.
Instrucons for use!
Under “Instrucons for Use“, it is pointed out that installaon and
operang instrucons are to be read and understood before
installaon or repair.
Cauon, hot surface!
Under “Cauon, hot surface”, it should be noted that surfaces of
equipment may be hot and create a burn hazard.
Special disposal instrucons!
With “Note Separate Disposal”, it is pointed out that this product
may not be disposed of with normal garbage. An improperly
conducted disposal can lead to damage to the environment.
CE mark
The product complies with essenal requirements of relevant
direces of EU
2. SAFETY INSTRUCTION
WARNING:
PLEASE READ THIS MANUAL BEFORE INSTALLATION. ANY DAMAGE TO THE PRODUCT DUE TO NOT
FOLLOWING THIS MANUAL IS NOT COVERED BY THE WARRANTEE.
ALL THE INSTALLATION SHOULD BE DONE BY CERTIFIED ELECTRICIAN.
BESIDES THE CABLE CONNECTORS, NOTHING INSIDE THE INVERTER SHOULD BE MODIFIED.
ALL INSTALLATION SHOULD FOLLOW THE LOCAL ELECTRIC CODES. FURTHER PROTECTION ON THE
AC WIRING FROM THE INVERTERS SHOULD BE PROVIDED AND MAY BE REQUIRED BY LOCAL AND
NATIONAL WIRING REGULATIONS. THIS PROTECTION IS LIKELY TO INCLUDE RESIDUAL CURRENT
DEVICES, EARTH FAULT MONITORS AND CIRCUIT BREAKERS. THIS PRODUCT MAY CAUSE AC
CURRENT WITH A DC COMPONENT. IF A RESIDUAL CURRENT-OPERATED PROTECTIVE DEVICE
(RCD) OR A MONITORING DEVICE (RCM) IS USED FOR PROTECTION IN CASE OF DIRECT OR INDIRECT
CONTACT, ONLY AN RCD OR RCM OF TYPE B IS ALLOWED ON THE AC SIDE OF THIS PRODUCT.
NEVER DISCONNECT PV MODULE FROM THE MICRO-INVERTER WITHOUT FIRST ISOLATING THE AC
MAINS. ALL PV CONNECTORS AND AC CONNECTORS ARE FORBIDDEN TO BE DISCONNECTED
UNDER LOAD BEFORE SWITCHING OFF THE CIRCUIT BREAKER ON THE AC BRANCH.
PLEASE CONTACT AUTHORIZED SERVICE AGENTS FOR ANY SERVICE WORK.
BDM-300X2 IS A GRID-TIED SOLAR INVERTER. IT MAY REQUIRE APPROVAL FROM LOCAL UTILITY
COMPANY TO CONNECT IT TO THE POWER GRID.
BDM-300X2 DOES NOT INCLUDE COMPONENTS THAT CAN BE SERVED BY CUSTOMERS.
WARNING:
WHEN THE PHOTOVOLTAIC ARRAY IS EXPOSED TO LIGHT, IT SUPPLIES A DC VOLTAGE TO THE MICRO-
INVERTER.
3. FCC COMPLIANCE
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protecon against harmful interference in a residenal
installaon. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instrucons, may cause
harmful interference to radio communicaons. However, there is no guarantee
that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television recepon, which can be
determined by turning the equipment oand on, the user is encouraged to try to
correct the interference by one or more of the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separaon between the equipment and the receiver.
●Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
●Consult the dealer or an experienced radio/TV technician for help.
Changes or modicaons not expressly approved by the party responsible for
compliance may void the user’s authority to operate the equipment.
02
03
0 2
03

4. INSTALLATION
WARNING: BE AWARE THAT INSTALLATION OF THIS EQUIPMENT INCLUDES RISK OF
ELECTRIC SHOCK. NORMALLY GROUNDED CONDUCTORS MAY BE UNGROUNDED AND
ENERGIZED WHEN A GROUND FAULT IS INDICATED.
Parts Included
In addion to the micro inverters, PV modules, racking, and associated hardware,
you’ll need the BDM-300X2 installaon kit. This kit includes the following items:
●Protece end cap
●Mounng Bracket (adapter plate)
●AC trunk cable, 6 feet length (opon)
Other Parts and Tls Required
In addion to your PV array and its associated hardware, you will need the
following parts:
●Juncon box
●Sockets, wrenches for mounng hardware
Lightning Surge Suppressin
Lightning does not actually need to strike the equipment or building where PV
system is installed to cause damage. Oen, a strike nearby will induce voltage
spikes in the electrical grid that can damage equipment. BDM-300X2 has
integrated surge protecon, greater than most string inverters. However, if the
surge has sucient energy, the protecon built into the BDM-300X2 can be
exceeded, and the equipment can be damaged.
Since the NEP Limited Warranty does not cover “acts of God” such as lightning
strikes, and since lightning strikes can occur anywhere, it is best pracce to install
surge protecon as part of any solar installaon. Installaon of surge protecon
devices should follow vendor instrucons.
Installan Prcedure
WARNING: DO NOT CONNECT BDM-300X2 TO THE UTILITY GRID OR ENERGIZE THE AC
CIRCUIT(S) UNTIL YOU HAVE COMPLETED ALL OF THE INSTALLATION PROCEDURES AS
DESCRIBED IN THE FOLLOWING SECTIONS.
Installing the BDM-300X2 Micro inverter System involves several key steps:
1. Measuring service and installing the AC branch circuit juncon box.
WARNING: ONLY USE ELECTRICAL SYSTEM COMPONENTS APPROVED FOR WET
LOCATIONS.
2. Aaching the BDM-300X2 Micro inverter to the racking.
3. Connecng the BDM-300X2 Micro inverter wiring harnesses.
4. Grounding the system (oponal)1.
5. Compleng the BDM-300X2 Micro inverter installaon map and connecng
the PV modules.
The nished system should be similar as in the diagram. Detailed installaon steps
are listed in the following secon.
Step 1 - Install the AC Branch Circuit Juncn Bx
1. Measure service entrance conductors to conrm AC service at the site.
Acceptable ranges are shown in the table below:
●BDM-300X2-240A & BDM-300X2-208A (North America)
240 Volt AC Single Phase 208 Volt AC Three Phase
L1 to L2
240 Vac
L1 toL2
208 Vac
●BDM-300X2-AU (Australia and New Zealand)
L1 to L2
230 Vac
1DC circuits of BDM-300X2 are isolated and insulated from ground. An
integrated ground protecon circuit is included in the micro inverter.
04
05
0 4

●BDM-300X2-EU (Europe)
L1 to L2
230 Vac
2. Mount the adapter plate at a suitable locaon on the PV racking system (typically
at the end of a row of modules).
3. Install an appropriate juncon box with the adapter plate.
4. Connect the open wire end of the AC interconnect cable into the junction box using
an appropriate gland or strain relief ng. The AC interconnect cable requires a
strain relief connector with an opening of 3/8 inches in diameter.
Step 2 - Aach BDM-300X2 tthe Racking
1. Mark the approximate centers of each PV module on the racking system. Evaluate
the locaon of the micro inverter with respect to the PV module juncon box or any
other obstrucons.
WARNING: ALLOW A MINIMUM OF 2.75 INCHES BETWEEN THE TOP OF THE ROOF AND THE
BOTTOM OF BDM-300X2, AND ALSO A MINIMUM 2.75 INCHES BETWEEN THE BACK OF THE PV
MODULE AND THE TOP OF BDM-300X2. DO NOT MOUNT BDM-300X2 IN A LOCATION THAT
ALLOWS LONG-TERM EXPOSURE TO DIRECT SUNLIGHT.
2. Mount one micro inverter at each of these locaons using hardware recommended
by your module racking vendor
Step 3 - Cnnect the BDM-300X2 Wiring Harnesses
Each BDM-300X2 comes with one 3-pin bulkhead receptacle mounted on the
case. The three pins of this connector are for phases L1, L2 and ground. This AC
connector is oppositely sexed with the connector at the end of the extension
cable from the trunk cable through a T-connector. Plug the AC connector of the
each BDM-300X2 into the connector of the extension cable to form a connuous
AC branch circuit. Please check the rang label of the trunk cable for the
maximum allowable number of BDM-300X2 on one AC branch circuit.
WARNING: DO NOT EXCEED THE MAXIMUM NUMBER OF BDM-300X2 IN AN AC BRANCH
CIRCUIT, AS DISPLAYED ON THE UNIT-RATING LABEL. For 12AWG trunk cable, EACH BDM-
300X2 AC BRANCH CIRCUIT MUST BE SOURCED FROM A DEDICATED BRANCH CIRCUIT
PROTECTED BY A 20A MAXIMUM BREAKER.
Install a protece end cap on the open AC connector at the end of the truck
cable.
WARNING: MAKE SURE PROTECTIVE END CAPS HAVE BEEN INSTALLED ON ALL UNUSED
AC CONNECTORS. UNUSED AC BDM-300X2 WIRE HARNESS CONNECTORS ARE LIVE WHEN
THE SYSTEM IS ENERGIZED BY THE UTILITY SYSTEM.
07
0 6

Step 4 – Grund the system
Each BDM-300X2 has an integrated ground protecon circuit. The grounding
wire is through the trunk cable, and should be securely connected to the ground
connector in the juncon box.
Step 5 – Grund the system thrugh racking (pn)
BDM-300X2 may also be grounded through the racking as shown below.
Step 6 – Cmplete the cnnecn map and cnnect the PV Mdules
BDM-300X2 connecon Map is a diagrammac representaon of the physical
locaon of each BDM-300X2 in your PV installaon. The virtual array in NEP micro
inverter gateway BDG-256 is created from the map you create.
Cmplete the cnnecn map
Each BDM-300X2 has a removable serial number label located on the mounng
plate. Enter this serial number into the BDG-256, and correspond it to a number in
the connecon map.
Cnnect the PV Mdules
Completely install all BDM-300X2 and all system inter-wiring connecons prior to
installing the PV modules.
1. Mount the PV modules above their corresponding BDM-300X2. Each BDM-300X2
comes with two oppositely sexed DC connectors.
2. First connect the posie DC wire from the PV module to the negavely marked
DC connector (male pin) of the BDM-300X2. Then connect the negave DC wire
from the PV module to the positively marked DC connector (female socket) of the
BDM-300X2. Repeat for all remaining PV modules using one BDM-300X2 for each
module.
09
0 8

5. COMMISSIONING
WARNING: CONNECT BDM-300X2 TO THE ELECTRICAL UTILITY GRID ONLY AFTER RECEIVING
PRIOR APPROVAL FROM THE UTILITY COMPANY.
WARNING: BE AWARE THAT ONLY QUALIFIED PERSONNEL CAN CONNECT BDM-300X2 TO
THE ELECTRICAL UTILITY GRID.
WARNING: ENSURE THAT ALL AC AND DC WIRING IS CORRECT. ENSURE THAT NONE OF THE
AC AND DC WIRES IS PINCHED OR DAMAGED. ENSURE THAT ALL JUNCTION BOXES ARE
PROPERLY CLOSED.
Following these steps to commission the BDM-300X2 PV system:
1. Turn on the AC disconnects or circuit breakers on each BDM-300X2 AC branch
circuit.
2. Turn on the main uty-grid AC circuit breaker. Your system will start producing
power aer a few minutes wait me.
3. The BDM-300X2 will start to send performance data over the power lines using
power line communicaon (PLC) to the BDG-256. The me required for each BDM-
300X2 in the system to communicate to the BDG-256 will vary with the number of
BDM-300X2 in the system.
6. OPERATING INSTRUCTIONS
The BDM-300X2 is powered on when sucient DC voltage from the module is
applied. The status LED will start ashing aer sucient DC power is applied as an
indicaon that the BDM-300X2 is live.
Status: standby
The LED light is on by 2 second, and oby 2 seconds
Red: in error.
Orange: no error, but not communicating to BDG-256
Green: no error, and communicang to BDG-256
Status: prducing pwer
The LED light is on by 1 second, and oby 1 second.
Orange: not communicang to BDG-256
Green: communicang to BDG-256
Status: grunding fault
The LED light is in solid red color.
In case of fault, BDM-250 has mulple protece funcons and stops output power.
The fault message may be sent to a connected BDG-256 gateway through power
line communicaon. The error message is displayed on the screen of BDG-256
gateway by a 16-bit error code.
Errr cde Errr
Bit-0 DC over voltage
Bit-1 DC under voltage
Bit-2 hardware error
Bit-3 Inverter over voltage
Bit-4 Frequency over
Bit-5 Frequency under
Bit-6 AC voltage RMS over
Bit-7 AC voltage RMS under
Bit-8 Peak AC voltage over
Bit-9 AC current RMS over
Bit-10 Peak AC current over
Bit-11 Temperature over
Bit-12 ADC error
Bit-13 GFDI fault indicator
Bit-14 Relay fault (BDM-250-AU/BDM-250-EU only)
Bit-15 PLC Communicaon Error
7. TROUBLESHOOTING AND MAINTENANCE
WARNING: DO NOT ATTEMPT TO REPAIR THE BDM-300X2; IT CONTAINS NO USER-
SERVICEABLE PARTS. IF TROUBLESHOOTING METHODS FAIL, PLEASE RETURN THE BDM-300X2
TO YOUR DISTRIBUTOR FOR MAINTENANCE.
WARNING: NEVER DISCONNECT THE DC WIRE CONNECTORS UNDER LOAD. ENSURE THAT
NO CURRENT IS FLOWING IN THE DC WIRES PRIOR TO DISCONNECTING. AN OPAQUE
COVERING MAY BE USED TO COVER THE MODULE PRIOR TO DISCONNECTING
WARNING: BDM-300X2 IS POWERED BY DC POWER FROM PV MODULES. MAKE SURE YOU
DISCONNECT THE DC CONNECTIONS AND RECONNECT DC POWER TO WATCH FOR THE TWO
SECONDS LED ON AND TWO SECONDS LED OFF AFTER DC IS APPLIED.
11
10

WARNING:
ALWAYS DISCONNECT AC POWER BEFORE DISCONNECTING PV MODULE WIRES
FROM BDM-300X2. THE AC CONNECTOR OF THE FIRST BDM-300X2 IN A BRANCH CIRCUIT IS
SUITABLE AS A DISCONNECTING MEANS ONCE THE AC BRANCH CIRCUIT BREAKER IN THE LOAD
CENTER HAS BEEN OPENED.
LED indican f errr
•errr mde (except fr grunding errr)
The LED light ashes in red color.
•NOT cmmunicang with BDG-256, and with nerrr
The LED light ashes in orangecolor.
•grunding fault
The LED light is in solid red color.
Trubleshng an inperable BDM-250
To troubleshoot an inoperable BDM-300X2, follow the steps in the order shown:
1. Check the connecon to the ulity grid. Verify that the uty voltage and
frequency are within allowable ranges shown in the label of BDM-300X2.
2. Verify uty power is present at the inverter in queson by removing AC, then DC
power. Never disconnect the DC wires while the BDM-300X2 is producing power.
Re-connect the DC module connectors, and then watch for the LED blinks.
3. Check the AC branch circuit interconnecon harness between all the BDM-300X2.
Verify that each inverter is energized by the ulity grid as described in the
previous step.
4. Make sure that any AC disconnects are funconing properly and are closed.
5. Verify the PV module DC voltage is within the allowable range shown in the label
of BDM-300X2.
6. Check the DC connecons between the BDM-300X2 and the PV module.
7. PLC signal quality may be checked through the interface on the BDG-256 gateway.
If the PLC signal is weak, it might be due to the distance between the micro
inverters and the gateway. It may also be caused by the interference from other
electronic devices. In most cases, signal quality may be signicantly improved by
moving the BDG-256 to closer to the micro inverter arrays, and/or farther away
from other interferers. In some cases, a signal ter (LCF) may be installed to
reduce the interference to PLC communicaon. If there are two or more
separate BDM systems close by, it is highly recommended to install LCF for each
micro inverter system to block interference from adjacent other systems.
7. If the problem persists, please call customer support at NEP.
WARNING: DO NOT ATTEMPT TO REPAIR THE BDM-300X2; IT CONTAINS NO USER-
SERVICEABLE PARTS. IF TROUBLESHOOTING METHODS FAIL, PLEASE RETURN THE BDM-300X2
TO YOUR DISTRIBUTOR FOR MAINTENANCE.
Discnnecng a BDM-300X2 frm the PV Mdule
To ensure the BDM-300X2 is not disconnected from the PV modules under load,
adhere to the following disconnecon steps in the order shown:
1. Disconnect the AC by opening the branch circuit breaker.
2. Disconnect the rst AC connector in the branch circuit.
3. Cover the module with an opaque cover.
4. Using a DC current probe, verify there is no current owing in the DC wires between
the PV module and the BDM-300X2.
5. Care should be taken when measuring DC currents, most clamp-on meters must be
zeroed rst and tend to driwith me.
6. Disconnect the PV module DC wire connectors from the BDM-300X2.
7. Remove the BDM-300X2 from the PV array racking.
Installing a replacement BDM-300X2
1. Aach the replacement BDM-300X2 to the PV module racking using hardware
recommended by your module racking vendor
2. Connect the AC cable of the replacement BDM-300X2 and the neighboring BDM-
300X2 to complete the branch circuit connecons.
3. Complete the connecon map and connect the PV Modules.
1) Complete the connecon map
2) Each BDM-300X2 has a removable serial number located on the mounng plate.
Enter this serial number into a BDG-256, and correspond it to a number in the
connecon map.
3) Connect the PV Modules
4) Completely install all BDM-300X2 and all system inter-wiring connecons prior to
installing the PV modules.
a) Mount the PV modules above their corresponding BDM-300X2. Each BDM-
300X2 comes with two oppositely sexed DC connectors.
b) First connect the posie DC wire from the PV module to the negavely
marked DC connector (male pin) of the BDM-300X2. Then connect the negae
DC wire from the PV module to the posiely marked DC connector (female
socket) of the BDM-300X2. Repeat for all remaining PV modules using one
BDM-300X2 for each module.
4. Replace the old PLC_ID in the BDG-256 gateway with the new PLC_ID of
the replacement micro inverter.
13
12

8. SPECIFICATION
MODEL BDM-300X2-240A(-D) BDM-300X2-208A(-D)
INPUT(DC)
Max Recommended PV Power (Wp) 340 x 2 340 x 2
Max DC Open Circuit Voltage (Vdc) 60 60
Max DC Input Current (Adc) 12 x 2 12 x 2
MPPT Tracking Accuracy >99.5% >99.5%
MPPT Tracking Range (Vdc) 22-55 22-55
OUTPUT(AC)
Peak AC Output Power (Wac) 550 550
Rated AC Output Power (Wac) 500 500
Nominal Power Grid Voltage (Vac) 240 208
Allowable Power Grid Voltage (Vac)
211-264
(Adjustable
*
)
183-228
(Adjustable
*
)
Allowable Power Grid Frequency (Hz)
59.3-60.5
(Adjustable
*
)
59.3-60.5
(Adjustable
*
)
THD
<3%
(at rated power)
<3%
(at rated power)
Power Factor
>0.99
(at rated power)
>0.99
(at rated power)
SYSTEM
EFFICIENCY
CEC Eciency 95.5% 95.5%
Night Time Tire Loss (W) 0.11 0.11
PROTECTION
FUNCTIONS
Over/Under Voltage Protecon Yes Yes
Over/Under Frequency Protecon Yes Yes
An-Islanding Protecon Yes Yes
Over Current Protecon Yes Yes
Reverse DC Polarity Protecon Yes Yes
Overload Protecon Yes Yes
Ground Fault Detecon Integrated Integrated
Protecon Degree NEMA-6 NEMA-6
Environment Temperature -40
℃
~ +65
℃
-40
℃
~ +65
℃
Operang Temperature -40
℃
~ +85
℃
-40
℃
~ +85
℃
OTHER
PARAMETERS
Display LED LIGHT
LED LIGHT
Communicaons POWERLINE POWERLINE
Dimension (D-W-H mm) 277*132*50 277*132*50
Weight (Kg) 2.9 2.9
(* Per IEEE 1547A)
MODEL
BDM-300X2-AU(-D)
BDM-300X2-EU(-D)
INPUT(DC)
Max Recommended PV Power (Wp) 340 x 2
Vmax PV (absolute maximum) (Vdc) 60
PV Input Operang Voltage Range (Vdc)
22-55
Maximum Operang PV Input Current (Adc) 12 x 2
MPPT Tracking Accuracy >99.5%
Isc PV (absolute maximum) (Adc) 14 x 2
Maximum Inverter Backfeed Current to the Array (Adc) 0
OUTPUT(AC)
Peak AC Output Power (W)
550
Rated AC Output Power (W) 500
Nominal Power Grid Voltage (Vac) 230
Nominal Output Current (Aac) 2.17
Current (inrush) (Peak and Duraon) 24A, 15us
Nominal Frequency (Hz)
50
Power Factor
>0.99
(at rated power)
Maximum Output Fault Current (Aac)
4.4A peak
Maximum Output Overcurrent Protecon (Aac)
10.0
SYSTEM
EFFICIENCY
CEC Eciency 95.5%
Night Time Tare Loss (W) 0.11
PROTECTION
FUNCTIONS
Over/Under Voltage Protecon Yes
Over/Under Frequency Protecon
Yes
An-Islanding Protecon
Yes
Over Current Protecon Yes
Reverse DC Polarity Protecon Yes
Overload Protecon Yes
Ground Fault Detecon
Integrated
Protecve Class
I
IP Rang IP66 / IP67
Environment Temperature -40
℃
~ +65
℃
Operang Temperature -40
℃
~ +85
℃
OTHER
PARAMETERS
Display LED LIGHT
Communicaons
POWERLINE
Dimension (D-W-H mm) 277*132*50
Weight (Kg) 2.9
15
14

9. WARRANTY AND PRODUCTION INFORMATION
What des this warranty cver and hw lng des it last?
This Limited Warranty is provided by Northern Electric & Power Co. Ltd (NEP) and
covers defects in workmanship and materials in your BDM-300X2 Grid-Tied Inverter.
This Warranty Period lasts for 10 years from the date of purchase at the point of sale
to you, the original end user customer, unless otherwise agreed in wring. You will be
required to demonstrate proof of purchase to make warranty claims.
This Limited Warranty is transferable to subsequent owners but only for the
unexpired poron of the Warranty Period. Subsequent owners also require original
proof of purchase as described in "What proof of purchase is required?"
What will NEP d?
During the Warranty Period, NEP will, at its opon, repair the product (if economically
feasible) or replace the defece product free of charge, provided that you nofy NEP
of the product defect within the Warranty Period, and provided that NEP through
inspecon establishes the existence of such a defect and that it is covered by this
Limited Warranty.
NEP will, at its opon, use new and/or recondioned parts in performing warranty repai
r
and building replacement products. NEP reserves the right to use parts or products of
original or improved design in the repair or replacement. NEP repairs or replaces a
product, its warranty connues for the remaining poron of the original Warranty
Period or 90 days from the date of the return shipment to the customer, whichever is
greater. All replaced products and all parts removed from repaired products become the
property of NEP.
Hw dyu get service?
If your product requires troubleshoong or warranty service, contact your merchant. If
you are unable to contact your merchant, or the merchant is unable to provide service,
contact NEP directly at:
Nrthern Electric & Pwer Inc
Email：[email protected]
What des this warranty nt cver?
Claims are limited to repair and replacement or if in NEP's discreon that is not
possible, reimbursement up to the purchase price paid for the product. NEP will be
liable to you only for direct damages suered by you and only up to a maximum
amount equal to the purchase price of the product.
This Limited Warranty does not warrant uninterrupted or error-free operaon of the
product or cover normal wear and tear of the product or costs related to the removal,
installaon, or troubleshoong of the customer's electrical systems. This warranty
does not apply to and NEP will not be responsible for any defect in or damage to:
a) the product if it has been misused, neglected, improperly installed, physically
damaged or altered, either internally or externally, or damaged from improper
use or use in an unsuitable environment; b) the product if it has been subjected
to re, water, generalized corrosion, biological infestaons, or input voltage that
creates operang condions beyond the maximum or minimum limits listed in
the NEP product specicaons including high input voltage from generators and
lightning strikes; c) the product if repairs have been done to it other than by NEP
or its authorized service centers (hereaer "ASCs"); d) the product if it is used as
a component part of a product expressly warranted by another manufacturer; e)
the product if its original idencaon (trade-mark, serial number) markings
have been defaced, altered, or removed; f) the product if it is located outside of
the country where it was purchased; and g) any consequenal losses that are
aributable to the product losing power whether by product malfuncon,
installaon error or misuse.
Disclaimer Prduct
THIS LIMITED WARRANTY IS THE SOLE AND EXCLUSIVE WARRANTY PROVIDED BY NEP IN
CONNECTION WITH YOUR NEP PRODUCT AND IS, WHERE PERMITTED BY LAW, IN LIEU OF ALL
OTHER WARRANTIES, CONDITIONS, GUARANTEES, REPRESENTATIONS, OBLIGATIONS AND
LIABILITIES, EXPRESS OR IMPLIED, STATUTORY OR OTHERWISE IN CONNECTION WITH THE
PRODUCT, HOWEVER ARISING (WHETHER BY CONTRACT, TORT, NEGLIGENCE, PRINCIPLES OF
MANUFACTURER'S LIABILITY, OPERATION OF LAW, CONDUCT, STATEMENT OR OTHERWISE),
INCLUDING WITHOUT RESTRICTION ANY IMPLIED WARRANTY OR CONDITION OF QUALITY,
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE TO THE EXTENT REQUIRED
UNDER APPLICABLE LAW TO APPLY TO THE PRODUCT SHALL BE LIMITED IN DURATION TO THE
PERIOD STIPULATED UNDER THIS LIMITED WARRANTY.
IN NO EVENT WILL NEP BE LIABLE FOR: (a) ANY SPECIAL, INDIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES, INCLUDING LOST PROFITS, LOST REVENUES, FAILURE TO REALIZE
EXPECTED SAVINGS, OR OTHER COMMERCIAL OR ECONOMIC LOSSES OF ANY KIND, EVEN IF
NEP HAS BEEN ADVISED, OR HAD REASON TO KNOW, OF THE POSSIBILITY OF SUCH DAMAGE,
(b) ANY LIABILITY ARISING IN TORT, WHETHER OR NOT ARISING OUT OF NEP'S NEGLIGENCE,
AND ALL LOSSES OR DAMAGES TO ANY PROPERTY OR FOR ANY PERSONAL INJURY OR
ECONOMIC LOSS OR DAMAGE CAUSED BY THE CONNECTION OF A PRODUCT TO ANY OTHER
DEVICE OR SYSTEM, AND (c) ANY DAMAGE OR INJURY ARISING FROM OR AS A RESULT OF
MISUSE OR ABUSE, OR THE INCORRECT INSTALLATION, INTEGRATION OR OPERATION OF THE
PRODUCT.
IF YOU ARE A CONSUMER (RATHER THAN A PURCHASER OF THE PRODUCT IN THE COURSE OF A
BUSINESS) AND PURCHASED THE PRODUCT IN A MEMBER STATE OF THE EUROPEAN UNION, THIS
LIMITED WARRANTY SHALL BE SUBJECT TO YOUR STATUTORY RIGHTS AS A CONSUMER UNDER
THE EUROPEAN UNION PRODUCT WARRANTY DIRECTIVE 1999/44/EC AND AS SUCH DIRECTIVE
HAS BEEN IMPLEMENTED IN THE EUROPEAN UNION MEMBER STATE WHERE YOU PURCHASED
THE PRODUCT. FURTHER, WHILE THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS,
YOU MAY HAVE OTHER RIGHTS WHICH MAY VARY FROM EU MEMBER STATE TO EU MEMBER
STATE OR, IF YOU DID NOT PURCHASE THE PRODUCT IN AN EU MEMBER STATE, IN THE COUNTRY
YOU PURCHASED THE PRODUCT WHICH MAY VARY FROM COUNTRY TO COUNTRY AND
JURISDICTION TO JURISDICTION.
7
17
16

Warranty Card
Custmer Infrman
Name:
Address:
City: State: Zip Code:
Tel: Fax: E-mail:
System Infrman
Fault Product(s) Serial Numbers:
System Commissioning Date: Product Models:
No. of Products Used: Bill of Lading Date:
Fault Product(s) Quanes: Fault Time/Date:
Fault Message(s) or Code(s):
Brief Fault Descripon and Photos (monitoring gateway is required for vericaon):
Installan Infrman
Modules Used:
Modules Quanty: Inverters quanty per string:
Installaon Company Name:
Installer Name:
For the informaon on our warranty terms and condions,
please see our website: www.northernep.com/en
All elds must be completed in order to process claim.
Custmer Signature: Date:
*All rights reserved by NEP. This informaon is subject to changes without noce.
19

USA
Address: 2570 N. First Street, Suite 200, San Jose, CA 95131
TEL: [phone]
Japan
Address: 812-0011 福岡市博多区博多駅前 3-10-24 藤井ビル 1F
TEL: [phone]
FAX: [phone]
China
Address: No.1 Anhe Rd Tsingtao Export Processing Zone, Tsingtao, China 266113
TEL: [phone]
FAX: [phone]
Email: [email protected]
Web: hp://www.northernep.com
hp://www.nep-japan.com
hp://www.micro-inverter.jp
