Vu Phong S400VA User manual

Pure Sine Wave Inverter
S400VA / S1000VA / S1500VA
www.vuphong.vn|www.vuphong.asia
User Manual
1. Introduction
The Vu Phong Sine Wave series models are used in a wide range
of applications. It will operate most televisions, fans, lamps,
personal computers, small appliances and tools.
The inverter must have a greater power rating than the
load it provides power to.
To get the most out of the power inverter, it must be installed
and used properly.
Please read the instructions in this manual before installing and
using this model.

S400VA / S1000VA / S1500VA
www.vuphong.vn|www.vuphong.asia
2. Specifications
S400VA
S1000VA
S1500 VA
Input Voltage
12V DC
Output Voltage
230V AC +/- 5%; 50Hz
Rated Output
Power
320W
800W
1200W
Max. Output
Power
400VA
1000VA
1500VA
Peak Surge
Power (5s)
600VA
2000VA
3000VA
Power factor
0.8
Max Efficiency
90%
Protections
Battery Deep Discharge (Low Voltage
Disconnect / Reconnect); AC Short Circuit; Over
Load; Reverse DC Polarity
No Load Power
Consumption
<2W (in
Green Power
status)
< 6W
< 4W (in
Green Power
status)
Cooling
Method
Natural convection, heat dissipation via
aluminium casing and heat sink; fan
Available
Versions
Inverter
Inverter; UPS
w/ AC Battery
Recharging
Function
Inverter
Transfer time
----
12ms
----
Size
200x125x115
mm; 2.0kg
340x135x134
mm; 3.8 kg
365x195x155
mm; 6.4 kg
Accessories
DC cables w/ cable shoe for battery connection

S400VA / S1000VA / S1500VA
www.vuphong.vn|www.vuphong.asia
3. Name and Main Function
3.1. Back side
a) ON / OFF switch: Power ON/OFF switch, leave in the OFF
position during installation.
b) Ventilation port(s): Allow air flow. Do not obstruct.
c) Battery Cables w/ Cable shoe: Connect to 12V battery.
Red is positive; Black / Blue is negative.
3.2. Front side
a) AC outlets: Connect to 220V loads
b) Green Power switch (S400VA / S1500VA): Energy saving
enable. Turn the switch ON to reduce the consumption
of the battery when AC output is without load.
c) LED indicators:
S400VA
-Fault: over temperature / over load (red)
-Normal (green): normal operation (green)
S1000VA
-Fault: over temperature; over load (red)
-Normal: normal operation (green)

S400VA / S1000VA / S1500VA
www.vuphong.vn|www.vuphong.asia
-Empty: empty battery / loose connection (red)
S1500VA
-(1): load detection (green)
-(2): Green Power mode ON (green)
-(3): over input voltage (red)
-(4): load short circuit (red)
-(5): over load (red)
-(6): normal operation (green)
-(7): empty battery / loose connection (red)
4. Installation
4.1. Where to install
The power inverter should be installed in a location that meets
the following requirements:
a) Dry - Do not allow water to drip or splash on the inverter.
b) Cool - Ambient air temperature should be between 0°C and
40°C (the cooler the better).
c) Ventilated - Allow at least two inches of clearance around the
inverter for air flow. Ensure the ventilation openings on the rear
and side of the unit are not obstructed.

S400VA / S1000VA / S1500VA
www.vuphong.vn|www.vuphong.asia
d) Safe - Do not install the inverter in the same compartment as
batteries or in any compartment capable of igniting flammable
liquids such as gasoline.
e) Keep the product away from children
4.2. Hook-up and testing
a) Unpack and inspect your Vu Phong Inverter, check to see that
the power switch is in the OFF position.
b) Connect the Red cable of the inverter to the positive (+)
terminal of the battery and the Black / Blue cable to the
negative (-) terminal of the battery. Tighten the screw to
clamp the wires securely.
Caution! Loose connections result in excessive voltage drop and
may cause overheated wires and melted insulation.
Caution! A reverse polarity connection may blow a fuse in the
inverter. Damage caused by reverse polarity connection is not
covered by our warranty.
Warning! You may observe a spark when you make this
connection since current may flow to charge capacitors in the
power inverter. Do not make this connection in the presence of
flammable fumes, as explosion or fire may result.
c) Plug the test load into the AC receptacle on the front panel of
the inverter. Leave the test load switch OFF.

S400VA / S1000VA / S1500VA
www.vuphong.vn|www.vuphong.asia
d) Set the power inverter switch to the ON position. The fan runs
and the LED “Normal”lights. Turn the test load on. The inverter
should supply power to the load.
Notice! Please do not connect the AC output of the invert to the
grid. Damage caused by this action is not covered by our
warranty.
5. Operation
To operate the power inverter, turn it on using the ON/OFF
switch on the rear panel. The power inverter is now ready to
deliver AC power to your loads. If you are operating several
loads from the power inverter, turn them on separately after the
inverter has been turned on. This will ensure that the power
inverter does not have to deliver the starting-currents for all the
loads at once.
5.1. Fault indicator
-Thermal shutdown:
The fault indicator(s) indicates that the power inverter has shut
itself down because it has become overheated. The power
inverter may overheat because it has been operated at power
levels above its rating, or because it has been installed in a
location which does not allow it to dissipate heat properly.
Switch the ON/OFF switch to OFF. Allow the inverter to cool off.
Reduce load if continuous operation required. Improve

S400VA / S1000VA / S1500VA
www.vuphong.vn|www.vuphong.asia
ventilation, make sure ventilation openings in inverter are not
obstructed. Then switch the ON/OFF switch back to ON.
-Short circuit / wiring error/ very high power load:
The fault indicator(s) also indicates that the power inverter has
shut itself down because its output circuit has been short
circuited or drastically overloaded.
Switch the ON/OFF switch to OFF. Check AC wiring for short
circuit or improper connection, correct the fault condition; or
remove load. Then switch the ON/OFF switch back to ON.
5.2. Empty battery indicator
The indicator “Empty”indicates that the power inverter has shut
itself down because of low input voltage. This maybe because
the battery is almost empty or connections are loose or rusted.
Switch the ON/OFF switch to OFF, recharge the battery, check
connections, and then switch the ON/OFF switch back to ON.
6. Green Power
This status features automatic load-sensing, which allows the
inverter to wait in Standby mode until an AC load is switched ON.
When an AC load appears, the inverter will immediately start.
This feature conserves valuable battery energy as the inverter
uses only about 10% of normal power when in standby mode.

S400VA / S1000VA / S1500VA
www.vuphong.vn|www.vuphong.asia
7. Operating limits
7.1 Power output
The inverter will operate most AC loads within its power rating.
Some motor-operated equipment require very high surge
currents to start. The power inverter may not be able to start
some of them even though their rated current draw is within the
power inverter.
7.2 Input voltage:
The power inverter will shut down if the input voltage drops
below 10.5V. This protects your battery from being overly
discharged.
8. Maintenance
Very little maintenance is required to keep your inverter
operating properly. You should clean the exterior of the unit
periodically with a damp cloth to prevent accumulation of dust
and dirt. At the same time, tighten the screws on the DC input
connection points.
