Trion CM2 User manual

TRION®
Model: CM2
Model CM4 (shown)
Technical Details
Average Air Volume m3/h
Filter Area m2
(Polyester BIA-C)
Filter Area m2
(Cellulose BIA-C)
Efficiency
Width mm
Depth (mm) unit + tank
Height less outlet duct
Height with outlet duct
Weight kg
Input Voltage
Cleaning System
Dust Collector
Inlet connection (mm)
High Inlet connection (mm)
Nominal resistance
through unit
CM2
2000
2 x 11.5 = 23
2 x 26 = 52
99.93%
750
850 + 200
2450
2760
260
230v/1ph/50Hz
Pulse Jet
1
1 x 200
1460
Cellulose 1000 PA / Polyester 1500 PA
CM4
4000
4 x 11.5 = 46
4 x 26 = 104
99.93%
1500
850 + 200
2450
2788
520
230v/1ph/50Hz
Pulse Jet
2
2 x 200
1460
CM6
6000
6 x 11.5 = 69
6 x 26 = 156
99.93%
2250
850 + 200
2450
2960
780
230v/1ph/50Hz
Pulse Jet
3
3 x 200
1460
CM8
8000
8 x 11.5 = 92
8 x 26 = 208
99.93%
3000
850 + 200
2450
3060
1040
230v/1ph/50Hz
Pulse Jet
4
4 x 200
1460
The TRION CM Series units are freestanding, self-cleaning cartridge filters suitable for the removal of
most dry smoke and dusts (not explosive or flammable).
The filter cabinet is made from 1.5mm welded sheet metal. The unit is supplied on a stand with a
collection hopper and dust barrel which can be easily removed and emptied.
The self-cleaning system utilises compressed air which is stored in tanks on the outside of the unit.
The compressed air is led directly through the tank into the cartridges.Alternatively, the cartridges can
be cleaned during operation (on-line) or through pressure difference, which saves on compressed air.
Additionally, there is an off-line cleaning system installed.The control box with a filter monitoring mech-
anism for cleaning is included. The interval-pulse sequences are individually adjustable as are the x-
P-value settings.
Changing the cartridges is made easy by the large doors on the front of the unit. The larger dust
particles are led directly into the collection hopper through a buffle which is installed at the air inlet.
The unit price includes a compressed air maintenance system with a reverse-safety valve, water filter
and pressure valve.The compressed air can be alternatively be supplied through a flexible hose with
a standard coupler plug or through a stiff tube system. Inlet duct shown is an optional extra.

Model: CM2
General Specification
780mm
2630mm
2760mm
250mm
1460mm
850mm
175mm
40mm
200mm
250mm
425mm
1090mm
1190mm
HOW IT WORKS
Dirty
Air
Clean Air Flow
Dirty
Air
200mm
