Quick Start Guide
USB 3.1 Gen 1 to
DVI Alternate Mode
Adapter
Model: U444-06N-DVI-AM (White),
U444-06N-DVIBAM (Black)
Español 8 • Français 14 • Русский 20
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2017 Tripp Lite. All rights reserved.
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate
peace of mind. You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
17-10-087-93376C.indb 1 11/20/2017 10:24:47 AM

2
Product Features
• Connects your existing DVI TV, monitor or projector
to the USB-C or Thunderbolt 3 port on your
tablet, laptop, notebook, MacBook, Chromebook,
smartphone or PC
• Supports USB DisplayPort Alternate Mode for
transmitting video
• Supports USB 3.1 Gen 1 data transfer rates up to
5 Gbps
• Supports HD video resolutions up to 1920 x 1080
(1080p) @ 60 Hz
• Supports 36-bit Deep Color (12 bits per channel)
• Supports DVI transfer rates up to 6.75 Gbps
(2.25 Gbps per channel)
• Plug-and-play adapter—no software, drivers or
external power required
USB Type-C™ and USB-C™ are trademarks of USB
Implementers Forum.
17-10-087-93376C.indb 2 11/20/2017 10:24:47 AM

3
System Requirements
Installation
Package Contents
• USB Type-C (USB-C) device that supports USB
DisplayPort Alternate Mode
• DVI-enabled monitor
1. Connect the adapter’s USB Type-C connector
to the USB Type-C port on your tablet, laptop,
notebook, MacBook, Chromebook, smartphone
or PC.
2. Connect the adapter’s DVI port to a monitor using
a DVI cable (such as Tripp Lite’s P561-Series
cables).
3. The video image will appear on the add-on
monitor. Customize how video is displayed on
the add-on monitor using your device’s display
settings.
• U444-06N-DVI-AM (White) or
U444-06N-DVIBAM (Black)
• Quick Start Guide
17-10-087-93376C.indb 3 11/20/2017 10:24:47 AM
