Model #: EZB-DVIM-2
Easy Pull Type-B Connectors - M/M set of DVI (Single-Link)
Highlights
DVI-D Connector Kit includes: 2 x DVI-D Male 1 ft. Cables
Versatile trunk cable allows for a variety of connection options
High quality digital cable supports resolutions up to 1080p
Requires B120-000 DVI signal booster
Description
Easy Pull Connector Kit includes: 2 x DVI-D Single Link Male Cable - 1 ft. pigtail. Completes your Easy Pull trunk run with a finished appearance.
Digital video support up to 1080p. Use with either PVC or Plenum digital trunk cables. Requires B120-000 DVI signal booster.
Applications
Use where standard DVI cables won't fit, such as conduit or confined wall or ceiling spaces
Package Includes
2 x DVI-D Male 1 ft. Pigtail Cable
Requires B120-000 DVI signal booster (not included)
Features
Eliminates the need to field terminate DVI connectors
Allows cable to be run according to code - inside conduit, drop ceilings, etc.
Makes pulling long cables fast and easy
Digital trunk cables available in 50 and 100 ft. lengths
Requires B120-000 DVI signal booster
High quality digital cable supports resolutions up to 1080p
Specifications
OVERVIEW
Display Style Easy Pull; Kit
INPUT
Cable Length (ft.) 1
Cable Length (m) 0.30
CONNECTIONS

Connector A
DVI-D SINGLE LINK (MALE)
Connector B
DVI-D SINGLE LINK (MALE)
Number of Connectors 2
WARRANTY
Product Warranty Period
(Worldwide)
Lifetime limited warranty
Related Items
Optional Products
Product Type Related Model Description Qty.
Video Cables & Adapters EZB-050 50-ft. Easy Pull Long-Run Display Cable
Type-B Digital PVC Trunk Cable
1
Video Cables & Adapters EZB-100 100-ft. Easy Pull Long-Run Display Cable
Type-B Digital PVC Trunk Cable
1
Video Cables & Adapters EZB-DVIF-2 Easy Pull Type-B Connectors
F/F set of DVI (Single-Link) with Faceplates
1
Video Cables & Adapters EZB-DVIX-2 Easy Pull Type-B Connectors
M/F set of DVI (Single-Link) with Faceplate
1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=3797.
