Owner’s Manual
HDMI to VGA +
Audio Splitter – 2-Port
Model: P131-06N-2VA-U
Espanol 9 • Français 16 • Русский 23
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind. You could also win an
ISOBAR6ULTRA surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2018 Tripp Lite. All rights reserved.
18-01-069-9337CB.indb 1 1/26/2018 10:23:41 AM

2
Product Features
Package Includes
• Split and transmit an HDMI signal on two VGA
displays simultaneously
• Supports video resolutions up to 1920 x 1440,
including 1080p
• Compact design features a built-in HDMI cable
with latching connector to securely connect to the
source
• No external power supply required;
USB Micro-B port supplies power to the unit
• Supports 3.5 mm mini stereo audio
• HDCP, EDID and 3D compliant
• Compatible with all operating systems
• Plug-and-play; no software or drivers required
• P131-06N-2VA-U
• USB Micro-B Cable – 3 ft.
• Owner’s Manual
18-01-069-9337CB.indb 2 1/26/2018 10:23:41 AM

3
Optional Accessories
System Requirements
• P312-Series 3.5 mm Mini Stereo Audio Cables
• P502-Series SVGA/VGA Monitor Cable with
RGB Coax
• P504-Series SVGA/VGA Monitor Cables with Audio
and RGB Coax
• UR05C-Series USB Micro-B Charge-Only Cables
• U280-002-W12 2-Port USB Wall Charger
• UAC-1B 1-Port USB Wall Charger
• A computer, Blu-ray™, or other HDMI source with
an HDMI output port
• An available USB port for power
• Up to two displays with VGA input ports
18-01-069-9337CB.indb 3 1/26/2018 10:23:41 AM

4
Installation
Note:
• The video port on the same side of the unit as the USB
Micro-B port is the only port that will transmit EDID
information to the connected source. Connect this port to
the monitor that has the EDID information you wish to use.
1. Make sure the power to all devices you are
connecting is turned off prior to installation.
2. Connect the built-in latching HDMI cable to the
source video output port.
3. Connect the included USB Micro-B cable between
the unit and a USB port on the source or a USB
wall outlet.
4. Connect the monitor that has the EDID information
you wish to use to the video output port on the
same side of the unit as the USB Micro-B port
using a VGA cable, such as Tripp Lite’s P504-
Series VGA + Audio Cable.
5. Connect the 3.5 mm audio port to the audio jack
on your monitor or speakers.
6. Connect a second monitor to the remaining video
output port using a VGA cable, such as Tripp Lite’s
P504-Series VGA + Audio Cable.
7. Connect the second 3.5 mm audio port to the
audio jack on your monitor or speakers.
8. Turn on the power to the source and displays. The
orange LEDs next to each video output port will
illuminate to indicate the unit is powered on and
transmitting a signal to the connected monitors.
18-01-069-9337CB.indb 4 1/26/2018 10:23:41 AM

5
Troubleshooting
If you are unable to get an acceptable image
after following the installation instructions, try the
troubleshooting tips below.
1. Is the USB Micro-B cable that came with the
product connected and plugged into a working
power source?
For the product to function properly, it must be
connected to and receiving power from the USB
Micro-B cable.
2. Was the power to the source turned off prior
to installation?
If not, restart your computer.
3. What resolution are you trying to reach?
See the Product Features section in this manual
for details on maximum resolution. If you are not
able to get an acceptable image, try lowering
your computer’s video resolution or adjusting the
refresh rate.
4. What type of cabling are you using?
Inferior cabling can result in poor performance, so
it is important that you use cables that can support
the video resolution you are trying to obtain. The
P131-06N-2VA-U has been tested to work with the
Tripp Lite video cables recommended for use in the
Optional Accessories section of this manual.
18-01-069-9337CB.indb 5 1/26/2018 10:23:41 AM

6
Troubleshooting
Warranty and Product Registration
5. Test your cables to ensure they are working
properly.
For example, connect your cable directly between a
computer and a monitor to verify that the video can
be displayed.
6. Do you have a splitter, switch or other device
in between the computer and the unit?
Tripp Lite’s P131-06N-2VA-U was designed to
connect directly with the source computer via the
built-in HDMI cable. If you have a splitter, switch, or
other device in between, it should be removed from
the installation.
3-YEAR LIMITED WARRANTY
TRIPP LITE warrants its products to be free from defects in materials and
workmanship for a period of three (3) years from the date of initial purchase.
TRIPP LITE’s obligation under this warranty is limited to repairing or replacing
(at its sole option) any such defective products. To obtain service under
this warranty, you must obtain a Returned Material Authorization (RMA)
number from TRIPP LITE or an authorized TRIPP LITE service center. Products
must be returned to TRIPP LITE or an authorized TRIPP LITE service center
with transportation charges prepaid and must be accompanied by a brief
description of the problem encountered and proof of date and place of
purchase. This warranty does not apply to equipment, which has been
damaged by accident, negligence or misapplication or has been altered or
modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE.
18-01-069-9337CB.indb 6 1/26/2018 10:23:41 AM

7
Warranty and Product Registration
Some states do not permit limitation or exclusion of implied warranties;
therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the
purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR
DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for
any costs, such as lost profits or revenue, loss of equipment, loss of use of
equipment, loss of software, loss of data, costs of substitutes, claims by third
parties, or otherwise.
PRODUCT REGISTRATION
Visit www.tripplite.com/warranty today to register your new Tripp Lite product.
You’ll be automatically entered into a drawing for a chance to win a FREE
Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply.
See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interfer-
ence that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
18-01-069-9337CB.indb 7 1/26/2018 10:23:41 AM

8
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Warranty and Product Registration
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to this equipment not expressly approved by
Tripp Lite could void the user’s authority to operate this equipment.
WEEE Compliance Information for Tripp Lite Customers and Recyclers
(European Union)
Under the Waste Electrical and Electronic Equipment (WEEE) Directive
and implementing regulations, when customers buy new electrical
and electronic equipment from Tripp Lite they are entitled to:
• Send old equipment for recycling on a one-for-one, like-for-like
basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately
becomes waste
Warning
Use of this equipment in life support applications where failure of this
equipment can reasonably be expected to cause the failure of the life
support equipment or to significantly affect its safety or effectiveness is not
recommended.
Tripp Lite has a policy of continuous improvement. Specifications are subject
to change without notice.
18-01-069-9337CB.indb 8 1/26/2018 10:23:41 AM

9
Manual del Propietario
Divisor HDMI a VGA +
Audio – 2 Puertos
Modelo: P131-06N-2VA-U
English 1 • Français 16 • Русский 23
1111 W. 35th Street, Chicago, IL 60609 EE UU
www.tripplite.com/support
Copyright © 2018 Tripp Lite. Todos los derechos
reservados.
18-01-069-9337CB.indb 9 1/26/2018 10:23:42 AM

10
Características del Producto
El paquete incluye
• Divida y transmita una señal HDMI a dos pantallas
VGA simultáneamente
• Soporta resoluciones de video hasta 1920 x 1440,
incluyendo 1080p
• El diseño compacto cuenta con un cable HDMI
incorporado con conector con seguro para conectar
firmemente a la fuente
• No requiere fuente de alimentación externa;
El puerto USB Micro-B suministra energía a la
unidad
• Soporta Audio Mini Estéreo de 3.5 mm.
• Compatible con HDCP, EDID y 3D
• Compatible con todos los sistemas operativos
• Conectar y Usar—No requiere software ni
controladores
• P131-06N-2VA-U
• Cable USB Micro-B – 91 cm [3 pies]
• Manual del Propietario
18-01-069-9337CB.indb 10 1/26/2018 10:23:42 AM
