Tripp Lite S054-45I User manual

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model #: S054-45I
45-inch Internal SCSI U2/160 SCSI-LVD/SE 4-Drive Ribbon Cable with Terminator (5xHD68 M)
Highlights
Cable includes Active T-Type LVD/SE terminator
UL-rated Amphenol brand cable
Connects up to 5 drives
Description
Introducing Tripp Lite's internal SCSI Ultra2/U160 4-drive LVD ribbon cable with an active U160 terminator. This cable measures 45 inches in length
and is made with twist and flat cabling. Because the cable is backwards compatible, it will support SCSI 1,2 & 3 devices such as CD-ROMs and Hard
Drives. All Tripp Lite SCSI products regardless of the SCSI generation meet the latest SCSI specifications of ANSI (American National Standards
Institute).
System Requirements
Wide SCSI controller card
Internal SCSI drives and devices with HD68 Pin interface
Package Includes
45-in. internal U160 SCSI ribbon cable 5Conn HD68M 4 drive with terminator
Features
Ribbon cable connects up to 4 internal SCSI drives/devices to your internal SCSI controller
HD68 male connectors
Cable includes active terminator
UL rated twist and flat cable
SCSI U160 cables include active terminators which compensate for impedance mismatches
All Tripp Lite SCSI products, regardless of the SCSI generation, meet the latest specifications of ANSI
Tripp Lite offers a complete line of internal and external solutions for SCSI/RAID and fibre channel ranging from the very latest ultra 320 to
legacy SCSI-1 and every combination in between
Specifications
OVERVIEW
Drives Supported 4
Intended Application Connecting Drives

Model Type SCSI Ultra160 Ribbon
INPUT
Cable Length (in.) 45
PHYSICAL
Color Gray
Style Ribbon & Internal Cables
CONNECTIONS
Connector A
INTERNAL HD68 (MALE)
Connector B
INTERNAL HD68 (MALE)
Number of Connectors 5
WARRANTY
Product Warranty Period
(Worldwide)
Lifetime limited warranty
Related Items
Optional Products
Product Type Related Model Description Qty.
SCSI Cables S053-36I 36-inch Internal SCSI U2/160 SCSI-LVD/SE 3-Drive Ribbon Cable with
Terminator
(4xHD68 M)
1
SCSI Cables S212-000 Internal SCSI Adapter
(HD68F/50F Socket IDC)
1
SCSI Cables S222-000 Internal SCSI Adapter SCA
(Ultra Micro 80F/HD68F)
1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=2354.
Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
