Owner’s Manual
SmartRack®High-Capacity
Horizontal Cable Manager
Models: SRCABLEDUCT1UHD, SRCABLEDUCT2UHD
Introduction
SRCABLEDUCT Horizontal Cable Managers route patch cables horizontally at the front or the rear of a
standard 19-in. rack. Plastic finger ducts and a dual-hinge cover help organize patch cables and reduce
cable stress within a rack enclosure cabinet or open-frame rack.
Included Hardware
• 4 x M6 Cage Nuts
• 4 x M6 / #12 Cup Washers
• 4 x M6 Flat Washers
• 4 x M6 Screws
• 4 x #12 Flat Washers
• 4 x #12-24 Screws
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved. SmartRack is a trademark of Tripp Lite.
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
surge protector in our monthly drawing!
www.tripplite.com/warranty

2
Note: The following diagrams show the SRCABLEDUCT2UHD being installed in a rack enclosure. SRCABLEDUCT1UHD uses
the same procedure, but the cage nuts will be installed with 1U rack spaces between them rather than 2U. Both the 1U and
2U units can also be installed in a 2-post or 4-post rack in the same manner, but 12-24 hardware will be used for 2-post
mounting.
Installation
1Install the cage nuts in the desired location
in the rack horizontally using a cage nut tool
(user-supplied).
2Attach the cable manager to the rack by
tightening the included screws and washers
into the cage nuts.
Compete (Front) Complete (Back)
1
2

3
Warranty and Product Registration
5-Year Limited Warranty
Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material
and workmanship for a period of 5 years from the date of initial purchase. If the product should prove defective in material or
workmanship within that period, Seller will repair or replace the product, at its sole discretion.
THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE
OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN.
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES OF
MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS
WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some states do not allow limitations
on how long an implied warranty lasts, and some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you
may have other rights which vary from jurisdiction to jurisdiction).
WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for
the use intended. Since individual applications are subject to great variation, the manufacturer makes no representation or
warranty as to the suitability or fitness of these devices for any specific application.
Product Registration
Visit www.tripplite.com/warranty today to register your new Tripp Lite product.You’ll be automatically entered into a drawing for
a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Photos and illustrations
may differ slightly from actual products.
