Tripp Lite B126-1P0-WP-1 User manual

1
Owner’s Manual
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2011 Tripp Lite. All rights reserved.
HDMI over Cat5 Extenders
and Extender/Splitters
Extender Kit Model: B126-1A1 and B126-1A1-WP
Local Unit Models: B126-002 and B126-004
Remote Unit Models: B126-1P0, B126-1P0-WP-1,
B126-1A0, B126-1A0-WP-1 and B126-110
Warranty
Registration:
register online today for a
chance to win a FREE Tripp Lite
product—www.tripplite.com/warranty
Package Contents 2
Product Features 2
Mounting Instructions 7
Standard Extender Kit Installation 8
Extender Kit with Remote/Repeater Installation 10
Standard Extender/Splitter Installation 13
Extender/Splitter with Remote/Repeater Installation 16
Extender/Splitter Daisy-Chain Installation (B126-004 only) 20
Extender/Splitter Daisy-Chain with Remote/Repeater 23
Installation (B126-004 only)
Warranty & Warranty Registration 27
201109206-93-3023-EN.indd 1 10/24/2011 10:01:17 AM

2
Package Contents
Product Features
B126-1A1 B126-1A1-WP B126-002 B126-004 B126-1A0 B126-1A0-WP-1 B126-1P0 B126-1P0-WP-1 B126-110
Local Unit (L), Remote Unit (R),
or Both (B) B B L L R R R R R
External Power Supplies
(0, 1, or 2) 221111001
Mounting Hardware X X X X X
Wallplate Screws X X X
Screwdriver for
Equalization Adjustment X X X X X
HDMI Daisy-chain Cable X
All
• Supportamaximumvideoresolutionof1080p(60Hz)
• Plug-and-play;nosoftwareordriversrequired
• Supportupto7.1channelsurroundsoundaudio
• HDCPand3Dcompatible
201109206-93-3023-EN.indd 2 10/24/2011 10:01:17 AM

3
Product Features
B126-1A1
• HDMIoverCat5ActiveExtenderKit(Box-style)
• Extendsa1080i(60Hz)signalupto200ft.fromthesource,ora
1080p(60Hz)signalupto150ft.fromthesource
• FeaturesanadditionalHDMIportonthelocaltransmitterunitforthe
connection of local monitor
• Remotereceiverunitfeaturesabuilt-inEqualizationcontrolforvideo
image adjustment
• Includesmountinghardwarethatallowsboththelocaltransmitter
and remote receiver units to be wallmounted, rackmounted or pole
mounted
B126-1A1-WP
• HDMIoverCat5ActiveExtenderWallplateKit
• Extendsa1080i(60Hz)signalupto200ft.fromthesource,ora
1080p(60Hz)signalupto150ft.fromthesource
• Remotereceiverunitfeaturesabuilt-inEqualizationcontrolforvideo
image adjustment
• RJ45-stylewallplatesallowfortheuseofstandardCat5e/6patch
cables;110punchdownconnectionnotrequired
B126-002
• 2-PortHDMIoverCat5Extender/SplitterLocalTransmitterUnit
(Box-style)
• SplitsanHDMIsignalinto2
• Workswithremote/repeaterandreceiverunitstoextendanHDMI
signalpastthe16ft.(5m)distancelimitation
• Includesmountinghardwarethatallowsunittobewallmounted,
rackmounted or pole mounted
201109206-93-3023-EN.indd 3 10/24/2011 10:01:17 AM

4
Product Features
B126-004
• 4-PortHDMIoverCat5Extender/SplitterLocalTransmitterUnit
(Box-style)
• SplitsanHDMIsignalinto4
• FeaturesanadditionalHDMIport,whichcanbeusedtoconnecta
local monitor or to daisy-chain additional B126-004 units.
Upto3B126-004unitscanbedaisy-chainedtogethertoincrease
the number of connected monitors.
• Workswithremote/repeaterandreceiverunitstoextendanHDMI
signalpastthe16ft.(5m)distancelimitation
• Includesmountinghardwarethatallowsunittobewallmounted,
rackmounted or pole mounted.
• Upto3B126-004unitscanbemountedinaB132-004-RB1U
rackmount bracket
B126-1A0
• HDMIoverCat5ActiveExtenderRemoteReceiverUnit(Box-style)
• WorkswithB126-002andB126-004extender/splitterstoextend
a1080i(60Hz)signalupto200ft.fromthesource,ora1080p
(60Hz)signalupto150ft.fromthesource
• Featuresabuilt-inEqualizationcontrolforvideoimageadjustment
• Includesmountinghardwarethatallowstheunittobewallmounted,
rackmounted or pole mounted
201109206-93-3023-EN.indd 4 10/24/2011 10:01:17 AM

5
Product Features
B126-1A0-WP-1
• HDMIoverCat5ActiveExtenderWallplate
• WorkswithB126-002andB126-004extender/splitterstoextend
a1080i(60Hz)signalupto200ft.fromthesource,ora1080p
(60Hz)signalupto150ft.fromthesource
• Featuresabuilt-inEqualizationcontrolforvideoimageadjustment
• RJ45-stylewallplateallowsfortheuseofstandardCat5e/6patch
cables;110punchdownconnectionnotrequired
B126-1P0
• HDMIoverCat5PassiveExtenderRemoteReceiverUnit(Box-style)
• WorkswithB126-002andB126-004extender/splitterstoextend
a1080i(60Hz)signalupto100ft.fromthesource,ora1080p
(60Hz)signalupto50ft.fromthesource
• Featuresabuilt-inHDMIcable;aseparateHDMIcableisnotrequired
• Noexternalpowerrequired
B126-1P0-WP-1
• HDMIoverCat5PassiveExtenderWallplate
• WorkswithB126-002andB126-004extender/splitterstoextend
a1080i(60Hz)signalupto100ft.fromthesource,ora1080p
(60Hz)signalupto50ft.fromthesource
• RJ45-stylewallplateallowsfortheuseofstandardCat5e/6patch
cables;110punchdownconnectionnotrequired
• Noexternalpowerrequired
201109206-93-3023-EN.indd 5 10/24/2011 10:01:17 AM

6
Product Features
B126-110
• HDMIoverCat5ActiveExtenderRemote/RepeaterUnit(Box-style)
• ExtendsandexpandsTrippLiteHDMIoverCat5installation,allowing
multiple monitors to be located at different points in a chain of up to
700ft.
• Extendsa1080i(60Hz)signalupto175ft.,ora1080p(60Hz)
signalupto125ft.fromthelocaltransmitterunittotherstremote/
repeater unit in the installation
• Extendsa1080i(60Hz)signaluptoanadditional175ft.,ora
1080p(60Hz)signaluptoanadditional125ft.fromeachremote/
repeater unit to the next unit in the chain. In a full 4 level daisychain
installation,a1080i(60Hz)signalcanbeextendedupto700ft.,
ora1080p(60Hz)signalupto500ft.fromthesourcetothelast
remote unit in the chain.
• Connectupto4remoteunits(3remote/repeatersand1receiver),
with a monitor located at each point in the chain
• Featuresabuilt-inEqualizationcontrolforvideoimageadjustment
• Includesmountinghardwarethatallowstheunittobewall-mounted,
rack-mounted or pole-mounted
Optional Accessories:
• B132-004-RB1URackmountBracket
• N202-SeriesCat624AWG,solidwirepatchcables
• P568-SeriesHigh-SpeedHDMIcables
201109206-93-3023-EN.indd 6 10/24/2011 10:01:17 AM

7
Mounting Instructions (select models only)
The B126-002, B126-004, B126-1A1, B126-1A0 and B126-110
come with mounting hardware that allows them to be mounted in
a variety of ways. The following images show the different ways the
included mounting brackets can be attached for different mounting
methods.Note:TheB126-004canalsobemountedtoaTrippLite
B132-004-RB1URackmountBracket.Upto3B126-004localunits
canbeconnectedtoaB132-004-RB.
Wallmount
19” Rackmount Pole Mount
201109206-93-3023-EN.indd 7 10/24/2011 10:01:19 AM

OPTIONAL LOCAL
MONITOR
LOCAL
TRANSMITTER
REMOTE
RECEIVER
Up to 200 ft. at 1080i (60Hz)
Up to 150 ft. at 1080p (60Hz)
BLU-RAY
8
Standard Extender Kit Installation
Notes:
1) Test to make sure the entire installation works properly before pulling
cables through ceilings/walls.
2) To achieve maximum distance and performance, use 24 AWG solid
wire Cat5e/6 cable. Using stranded wire Cat5e/6 cable, or cable
with a gauge (AWG) size higher than 24 AWG, will result in shorter
extension distance. Higher gauge cabling, such as 26 AWG, has a
more limited transmission capability than lower gauge cabling. All
Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid wire
cabling.
3) The B126-1A1 and B126-1A1-WP are set to transmit a stereo audio
signal by default. Press the Audio button on the local unit to switch to
7.1-channel surround-sound audio.
4) The installation diagram shows a B126-1A1 unit. The B126-1A1-WP
installation is the same, except there is no local monitor port.
201109206-93-3023-EN.indd 8 10/24/2011 10:01:20 AM

9
Standard Extender Kit Installation
1Make sure the HDMI source is powered OFF.
2ConnecttheHDMIsourcetotheINPUTportontheB126-1A1or
B126-1A1-WPlocalunitusingaTrippLiteP568-SeriesHDMICable.
3Optional for B126-1A1: Connect a local monitor to the LOCAL port
ontheB126-1A1localunitusingaTrippLiteP568-SeriesHDMI
Cable.
4Connect the external power supply to the local unit and plug it into
a Tripp Lite Surge Suppressor, Power Distribution Unit (PDU) or
Uninterruptible Power Supply (UPS). The green LED illuminates to
indicate the unit is receiving power from the external power supply.
5UsingCat5e/6cable,connecttheRJ45portonthelocalunittothe
RJ45portontheremoteunit.
6Connect the external power supply to the remote unit and plug it
into a Tripp Lite Surge Suppressor, PDU or UPS. The green LED
illuminates to indicate the unit is receiving power from the external
power supply. The orange LED illuminates to indicate the unit is
connectedtoapoweredONlocalunit.
7Connect the remote unit’s HDMI port to a monitor using a Tripp Lite
P568-SeriesHDMICable.
8Turn on the power to the HDMI source. The orange LED on the
local unit illuminates to indicate a signal is being received from the
source.
9If necessary, use the Equalization control on the remote unit to
adjust the video image. Note: An improper Equalization setting
can cause the monitor not to display a picture at all. Try each
Equalization setting until an acceptable picture is displayed.
201109206-93-3023-EN.indd 9 10/24/2011 10:01:20 AM

OPTIONAL LOCAL
MONITOR
B126-1A1 LOCAL
TRANSMITTER
B126-1A1 REMOTE
RECEIVER
B126-110 REMOTE
REPEATER
B126-110 REMOTE
REPEATER
B126-110 REMOTE
REPEATER
Up to 175 ft. at 1080i (60Hz)
Up to 125 ft. at 1080p (60Hz)
Up to 175 ft. at 1080i (60Hz)
Up to 125 ft. at 1080p (60Hz)
BLU-RAY
Up to 175 ft. at 1080i (60Hz)
Up to 125 ft. at 1080p (60Hz)
Up to 175 ft. at 1080i (60Hz)
Up to 125 ft. at 1080p (60Hz)
10
Extender Kit with Remote/Repeater Installation
Notes:
1) Test to make sure the entire installation works properly before pulling
cables through ceilings/walls.
2) To achieve maximum distance and performance, use 24 AWG solid
wire Cat5e/6 cable. Using stranded wire Cat5e/6 cable, or cable
with a gauge (AWG) size higher than 24 AWG, will result in shorter
extension distance. Higher gauge cabling, such as 26 AWG, has a
more limited transmission capability than lower gauge cabling. All
Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid wire
cabling.
3) The B126-1A1 and B126-1A1-WP are set to transmit a stereo audio
signal by default. Press the Audio button on the local unit to switch to
7.1-channel surround-sound audio.
4) The installation diagram shows a B126-1A1 unit. The B126-1A1-WP
installation is the same, except there is no local monitor port.
1Make sure the HDMI source is powered OFF.
2ConnecttheHDMIsourcetotheINPUTportontheB126-1A1or
B126-1A1-WPusingaTrippLiteP568-SeriesHDMICable.
201109206-93-3023-EN.indd 10 10/24/2011 10:01:21 AM

11
Extender Kit with Remote/Repeater Installation
3Optional for B126-1A1: Connect a local monitor to the LOCAL
HDMIportusingaTrippLiteP568-SeriesHDMICable.
4Connect the external power supply to the local unit and plug it into a
Tripp Lite Surge Suppressor, PDU or UPS. The green LED illuminates
to indicate the unit is receiving power from the external power
supply.
5UsingCat5e/6cable,connecttheRJ45portonthelocalunittothe
RJ45INPUTportontheB126-110remote/repeaterunit.
6Connect a monitor to the HDMI OUTPUT port on the remote/repeater
unitusingaTrippLiteP568-SeriesHDMICable.
7Connect the external power supply to the remote/repeater unit and
plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The green
powerLEDandthegreenRJ45LEDsilluminatetoindicatetheunit
is receiving power.
Upto4unitscanbedaisy-chained(3remote/repeatersand1receiver).
Toconnectadditionalremote/repeaterunits,proceedtostep8.Tonish
your installation with the B126-1A1 or B126-1A1-WP remote receiver
unit, proceed to step 12.
8UsingCat5e/6cable,connecttheRJ45OUTPUTportontherst
remote/repeaterunittotheRJ45INPUTportonasecondremote/
repeater unit.
9Connect a monitor to the HDMI OUTPUT port on the remote/repeater
unityoujustaddedusingaTrippLiteP568-SeriesHDMICable.
10 Connect the external power supply to the remote/repeater unit and
plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The green
powerLEDandthegreenRJ45LEDsilluminatetoindicatetheunit
is receiving power.
201109206-93-3023-EN.indd 11 10/24/2011 10:01:21 AM

12
Extender Kit with Remote/Repeater Installation
11 Toaddathirdremote/repeaterunit,repeatsteps8through10.
TonishyourinstallationwiththeB126-1A1orB126-1A1-WP
remote receiver unit, proceed to step 12.
12 UsingCat5e/6cable,connecttheRJ45OUTPUTportonthelast
remote/repeaterunittotheRJ45INPUTportoftheB126-1A1or
B126-1A1-WP remote receiver unit.
13 Connect a monitor to the HDMI OUTPUT port on the remote receiver
unitusingaTrippLiteP568-SeriesHDMICable.
14 Connect the external power supply to the remote receiver unit and
plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The green
LED illuminates to indicate the unit is receiving power from the
external power supply. The orange LED illuminates to indicate the
unitisconnectedtoapoweredONremote/repeaterunit.
15 Turn on the power to the HDMI source. The orange LED on the
local unit illuminates to indicate a signal is being received from the
source.
16 If necessary, use the Equalization control on the remote/repeater
unit(s) and remote receiver unit to adjust the video image. Note: An
improper Equalization setting can cause the monitor not to display
a picture at all. Try each Equalization setting until an acceptable
picture is displayed.
201109206-93-3023-EN.indd 12 10/24/2011 10:01:21 AM

B126-004
OPTIONAL LOCAL
MONITOR
BLU-RAY
B126-1P0-WP-1B126-1A0-WP-1
B126-1P0B126-1A0
Up to 100 ft. at 1080i (60Hz)
Up to 50 ft. at 1080p (60Hz)
Up to 200 ft. at 1080i (60Hz)
Up to 150 ft. at 1080p (60Hz)
13
Standard Extender/Splitter Installation
Notes:
1) Test to make sure the entire installation works properly before pulling
cables through ceilings/walls.
2) To achieve maximum distance and performance, use 24 AWG solid
wire Cat5e/6 cable. Using stranded wire Cat5e/6 cable, or cable
with a gauge (AWG) size higher than 24 AWG, will result in shorter
extension distance. Higher gauge cabling, such as 26 AWG, has a
more limited transmission capability than lower gauge cabling. All
Tripp Lite N202-Series cables are made with 24 AWG solid wire
cabling.
3) The B126-002 and B126-004 are set to transmit a stereo audio
signal by default. Press the Audio button on the B126-002 or
B126-004 to switch to 7.1-channel surround-sound audio.
4) The installation diagram shows the B126-004 local transmitter unit.
The B126-002 installation is the same except there are only
2 remote ports and no local monitor port.
201109206-93-3023-EN.indd 13 10/24/2011 10:01:21 AM

14
Standard Extender/Splitter Installation
1Make sure the HDMI source is powered OFF.
2ConnecttheHDMIsourcetotheINPUTportontheB126-002or
B126-004usingaTrippLiteP568-SeriesHDMICable.
3Optional for B126-004: Connect an HDMI monitor to the LOCAL
portontheB126-004usingaTrippLiteP568-SeriesHDMICable.
4Connect the external power supply to the B126-002 or B126-004
local unit and plug it into a Tripp Lite Surge Suppressor, PDU or UPS.
ThegreenRJ45LEDsandtheredPowerLEDontheB126-004,and
thegreenRJ45LEDsontheB126-002,willilluminatetoindicate
power is being received from the external power supply.
5UsingCat5e/6cable,connectoneoftheRJ45outputportsonthe
localunittotheRJ45inputportonaB126-1P0,B126-1A0,
B126-1P0-WP-1 or B126-1A0-WP-1 remote unit.
6Repeatstep5foreachadditionalremoteunityouareconnecting.
7B126-1A0 and B126-1A0-WP-1 only: Connect the external power
supply to the B126-1A0 or B126-1A0-WP-1, and plug it into a
Tripp Lite Surge Suppressor, PDU or UPS. The green and orange
LEDs illuminate, with the green LED indicating the unit is receiving
power from the external power supply, and the orange LED indicating
theunitisconnectedtoapoweredONlocalunitviaCat5e/6cable.
8Repeatstep7foreachadditionalB126-1A0orB126-1A0-WP-1in
the installation.
9ConnecttheB126-1P0HDMIconnectortoamonitor;or,connect
the B126-1P0-WP-1, B126-1A0 or B126-1A0-WP-1 to a monitor
usingaTrippLiteP568-SeriesHDMICable.Boththegreenand
orangeRJ45LEDsontheB126-1P0,andthegreenLEDonthe
B126-1P0-WP-1, illuminate to indicate the unit is receiving power
from the connected monitor.
201109206-93-3023-EN.indd 14 10/24/2011 10:01:21 AM

15
Standard Extender/Splitter Installation
10 Repeat step 9 for each additional monitor you are connecting.
11 TurnonthepowertotheHDMIsource.TheorangeRJ45LEDs
illuminate on the B126-002 and B126-004 to indicate the unit
is receiving a signal from the source. The screen should now be
displayed on the connected monitors.
12 If necessary, use the Equalization control on the B126-1A0 or
B126-1A0-WP-1 to adjust the video image.
Note: An improper Equalization setting can cause the monitor not to
display a picture at all. Try each Equalization setting until an acceptable
picture is displayed.
201109206-93-3023-EN.indd 15 10/24/2011 10:01:21 AM

OPTIONAL LOCAL
MONITOR
B126-004 LOCAL
TRANSMITTER
B126-110 REMOTE/
REPEATER
B126-110 REMOTE/
REPEATER
B126-110 REMOTE/
REPEATER
Up to 175 ft. at 1080i (60Hz)
Up to 125 ft. at 1080p (60Hz)
Up to 175 ft. at 1080i (60Hz)
Up to 125 ft. at 1080p (60Hz)
BLU-RAY
B126-110 REMOTE/
REPEATER
B126-110 REMOTE/
REPEATER
B126-110 REMOTE/
REPEATER
B126-110 REMOTE/
REPEATER
B126-110 REMOTE/
REPEATER
B126-110 REMOTE/
REPEATER B126-1A0-WP-1
REMOTE RECEIVER
B126-1A0-WP-1
REMOTE RECEIVER
B126-1A0-WP-1
REMOTE RECEIVER
B126-1A0-WP-1
REMOTE RECEIVER
B126-110 REMOTE/
REPEATER
B126-110 REMOTE/
REPEATER
B126-110 REMOTE/
REPEATER
16
Extender/Splitter with Remote/Repeater Installation
Notes:
1) Test to make sure the entire installation works properly before pulling
cables through ceilings/walls.
2) To achieve maximum distance and performance, use 24 AWG solid
wire Cat5e/6 cable. Using stranded wire Cat5e/6 cable, or cable
with a gauge (AWG) size higher than 24 AWG, will result in shorter
extension distance. Higher gauge cabling, such as 26 AWG, has a
more limited transmission capability than lower gauge cabling. All
Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid wire
cabling.
3) The B126-002 and B126-004 are set to transmit a stereo audio
signal by default. Press the Audio button on the local unit to switch to
7.1-channel surround-sound audio.
4) The installation diagram shows the B126-004. The B126-002
installation will be the same, except there are only 2 remote ports
and there is no local monitor port.
201109206-93-3023-EN.indd 16 10/24/2011 10:01:23 AM

17
Extender/Splitter with Remote/Repeater Installation
1Make sure the HDMI source is powered OFF.
2ConnecttheHDMIsourcetotheINPUTportontheB126-002or
B126-004usingaTrippLiteP568-SeriesHDMICable.
3Optional for B126-004: Connect a local monitor to the LOCAL
HDMIportusingaTrippLiteP568-SeriesHDMICable.
4Connect the external power supply to the local unit and plug it into
aTrippLiteSurgeSuppressor,PDUorUPS.ThegreenRJ45LEDs
illuminate to indicate power is being received from the external
power supply. An additional Red LED on the B126-004 also
illuminates to indicate that power is being received.
5UsingCat5e/6cable,connectoneoftheRJ45outputportsonthe
localunittotheRJ45inputportontheB126-110remote/repeater
unit.
6Connect a monitor to the HDMI OUTPUT port on the remote/repeater
unitusingaTrippLiteP568-SeriesHDMICable.
7Connect the external power supply to the remote/repeater unit and
plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The green
powerLEDandtheGreenRJ45LEDsilluminatetoindicatetheunit
is receiving power.
Upto4unitscanbedaisy-chained(3remote/repeatersand1receiver).
Toconnectadditionalremote/repeaterunits,proceedtostep8.Tonish
your installation with a B126-1A0 or B126-1A0-WP-1 remote receiver
unit, proceed to step 12.
8UsingCat5e/6cable,connecttheRJ45OUTPUTportontherst
remote/repeaterunittotheRJ45INPUTportonasecondremote/
repeater unit.
9Connect a monitor to the HDMI OUTPUT port on the remote/repeater
unitthatyoujustaddedusingaTrippLiteP568-SeriesHDMICable.
201109206-93-3023-EN.indd 17 10/24/2011 10:01:23 AM

18
Extender/Splitter with Remote/Repeater Installation
10 Connect the external power supply to the remote/repeater unit and
plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The green
powerLEDandthegreenRJ45LEDsilluminatetoindicatetheunit
is receiving power.
11 Toaddathirdremote/repeaterunit,repeatsteps8through10.
TonishyourinstallationwithaB126-1A0orB126-1A0-WP-1
remote receiver unit, proceed to step 12.
12 UsingCat5e/6cable,connecttheRJ45OUTPUTportonthelast
remote/repeaterunittotheRJ45INPUTportonaB126-1A0or
B126-1A0-WP-1 remote receiver unit.
13 Connect a monitor to the HDMI OUTPUT port on the remote receiver
unitusingaTrippLiteP568-SeriesHDMICable.
14 Connect the external power supply to the remote receiver unit and
plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The green
LED illuminates to indicate the unit is receiving power from the
external power supply. The orange LED illuminates to indicate the
unitisconnectedtoapoweredONremote/repeaterunit.
15 Repeatsteps5through14foreachadditionalRJ45outputporton
the local transmitter unit.
16 TurnonthepowertotheHDMIsource.TheorangeRJ45LEDson
the local unit illuminate to indicate a signal is being received from
the source.
17 If necessary, use the Equalization control on the remote/repeater
unit(s) and remote receiver unit to adjust the video image. Note: An
improper Equalization setting can cause the monitor not to display
a picture at all. Try each Equalization setting until an acceptable
picture is displayed.
201109206-93-3023-EN.indd 18 10/24/2011 10:01:23 AM

19
Extender/Splitter Daisy-Chain Installation (B126-004 only)
Notes:
1) Test to make sure the entire installation works properly before pulling
cables through ceilings/walls.
2) To achieve maximum distance and performance, use 24 AWG solid
wire Cat5e/6 cable. Using stranded wire Cat5e/6 cable, or cable
with a gauge (AWG) size higher than 24 AWG, will result in shorter
extension distance. Higher gauge cabling, such as 26 AWG, has a
more limited transmission capability than lower gauge cabling. All
Tripp Lite N202-Series cables are made with 24 AWG solid wire
cabling.
3) The B126-004 is set to transmit a stereo audio signal by default.
Press the Audio button on the B126-004 to switch to 7.1-channel
surround-sound audio.
4) Using the B126-1A0 and B126-1A0-WP-1, a 1080i (60 Hz) signal
can be extended up to 200 ft. from the source, or a 1080p (60 Hz)
signal up to 150 ft. from the source. Using a B126-1P0 or
B126-1P0-WP-1, a 1080i (60Hz) signal can be extended up to
100 ft. from the source, or a 1080p (60Hz) signal up to 50 ft.
201109206-93-3023-EN.indd 19 10/24/2011 10:01:23 AM

Level 1
Level 2
Level 3
OPTIONAL LOCAL MONITOR
BLU-RAY
20
Extender/Splitter Daisy-Chain Installation (B126-004 only)
201109206-93-3023-EN.indd 20 10/24/2011 10:01:23 AM
