Tripp Lite DMCSD3545M User manual

1
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
Owner’s Manual
Dual Flat-Panel
Mobile Cart
Model: DMCSD3545M
200x200 / 300x200
300x300 / 400x200
400x300 / 400x400
45"
MAX 88 lb. x 2
(40 kg x 2)
TV
11 lb.
(5 kg)
DVD
11 lb.
(5 kg)
WEBCAM
Español 17 • Français 33 • Русский 49 • Deutsch 65
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
surge protector in our monthly drawing!
www.tripplite.com/warranty
19-04-453-933909.indb 1 5/6/2019 11:33:25 AM

2
NOTE: Read the entire instruction manual before you start assembly and
installation.
Warranty and Product Registration
WARNING
• Do not begin the installation until you have read and understood
the instructions and warnings contained in this manual. If you have
questions regarding any of the instructions or warnings, please visit
www.tripplite.com/support.
• This product was designed to be installed and utilized ONLY as specified
in this manual. Improper installation of this product may cause damage
or serious injury.
• This product should only be installed by someone of good mechanical
ability, with basic building experience and a full understanding of this
instruction manual.
• Make sure the unit can safely support the combined load of the
equipment and all attached hardware and components.
• Always use an assistant or mechanical lifting equipment to safely lift
and position equipment.
• This product is intended for indoor use only. Using this product outdoors
could lead to product failure and/or personal injury.
5-Year Limited Warranty
Seller warrants this product, if used in accordance with all applicable instructions, to be free from original
defects in material and workmanship for a period of 5 years from the date of initial purchase. If the product
should prove defective in material or workmanship within that period, Seller will repair or replace the
product, in its sole discretion.
THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT,
MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY
EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED
WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION
TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY EXCLUDES ALL
INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied
warranty lasts, and some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal
rights, and you may have other rights which vary from jurisdiction to jurisdiction).
WARNING: The individual user should take care to determine prior to use whether this device is suitable,
adequate or safe for the use intended. Since individual applications are subject to great variation, the
manufacturer makes no representation or warranty as to the suitability or fitness of these devices for any
specific application.
PRODUCT REGISTRATION
Visit www.tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered
into a drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
Photos and illustrations may differ slightly from actual products.
19-04-453-933909.indb 2 5/6/2019 11:33:25 AM

3
Component Checklist
IMPORTANT: Ensure you have received all parts according to the component
checklist prior to installing. If any parts are missing or faulty,
visit www.tripplite.com/support for service.
A
Left Plastic Cover
E
Universal Plate
H
Left Column
J
Left Adapter Brackets
L
Camera Shelf
P
Left Base
Q
Right Base
M
Connecting Plate
N
Crossbar
O
Support Bar
I
Right Column
K
Right Adapter Brackets
F
Top Covers
G
Cable Covers
B
Right Plastic Cover
C
Middle Base
D
DVD Shelf
19-04-453-933909.indb 3 5/6/2019 11:33:25 AM

4
Component Checklist
Package M
Package P
M-A
M5x14
M-B
M6x14
M-C
M8x20
M-D
M6x30
M-E
M8x30
M-F
Washer
M-G
Small Spacer
M-H
Big Spacer
P-I
M8x65
P-N
5 mm Hex Key
P-O
Wrench
P-J
M4x6
P-K
M4x6
P-L
D8 Washers
P-M
D6 Washers
P-C
M8x30
P-D
M8x40
P-E
M6x14
P-F
M6x25
P-G
M6x8
P-H
M6x14
P-A
Butterfly Nuts
P-B
Butterfly Nuts
19-04-453-933909.indb 4 5/6/2019 11:33:25 AM

5
Assembly
1Assemble the Base
Using M8x40 screws (P-D) and the 5 mm hex key (P-N), attach the right base to the
middle base. Repeat this step for the left base.
Note: Lock the brakes on the casters to avoid any sudden movements during installation.
Each caster can be adjusted independently for fine adjustments. Slightly turn each caster
nut to lower or raise the base.
P
C
Q
P-N
P-D
A
B
P-O
19-04-453-933909.indb 5 5/6/2019 11:33:26 AM

6
Assembly
2Attach the Columns to the Base
H
H
P-C
Pin
Pin
I
I
Inner
Column
V
Pull the pin outward and lift the inner column upward at the same time until the inner
column is at the desired height. Release the pin to secure.
Using M8x30 screws (P-C),
attach the columns to the base.
Tighten
the Safety
Screw.
19-04-453-933909.indb 6 5/6/2019 11:33:27 AM

7
Assembly
3
4
Install the Crossbar
Install the Cable Covers
Using M6x14
screws (P-H),
attach the crossbar
to the columns.
Once the crossbar
installation is
completed, use
the 5 mm hex key
(P-N) to tighten the
bottom screws on
the base.
HP-H
G
19-04-453-933909.indb 7 5/6/2019 11:33:28 AM

8
Assembly
5Install the Universal Plate
P-B P-L
P-I E
Using M8x65 screws (P-I),
D8 washers (P-L) and butterfly
nuts (P-B), attach the universal
plate to the columns.
19-04-453-933909.indb 8 5/6/2019 11:33:29 AM

9
Assembly
6a
6Install the Adapter Brackets
Install the Adapter Brackets
For Flat-Back Screen
Note: Choose appropriate screws and washers according to the type of screen.
• Screw the adapter brackets onto the display.
Tighten all screws, but do not over-tighten.
Top of the
display.
J K
M-A
M-F
M-F
M-B
M-C
19-04-453-933909.indb 9 5/6/2019 11:33:30 AM

10
Assembly
6b Install the Adapter Brackets
For Recessed-Back Screen or to Access A/V Inputs
Note: Choose appropriate screws, washers and spacers (if necessary) according to the type
of screen.
• Screw the adapter brackets onto the display.
Tighten all screws, but do not over-tighten.
M-C
M-D
M-E
M-D
M-E
M-D
M-E
M-F
M-G M-G M-G
M-H
M-H
M-C
M-F M-F M-F
19-04-453-933909.indb 10 5/6/2019 11:33:31 AM

11
Assembly
7Attach the Displays onto the Universal Plate
F
• Hang the displays onto the universal plate.
• Tighten the bottom screws to secure.
Make sure the displays are mounted correctly and the
screws are tightened safely before releasing the
displays.
19-04-453-933909.indb 11 5/6/2019 11:33:31 AM

12
Assembly
8
Using M4x6 screws (P-J) and (P-K), attach the camera shelf to the connecting plate.
Using M6x25 screws (P-F) and D6 washers (P-M), attach the connecting plate to the
universal plate.
M
L
P-J
P-M P-F
P-K
Install the Camera Shelf
19-04-453-933909.indb 12 5/6/2019 11:33:33 AM

13
Assembly
9Install the DVD Shelf
O
P-G
D
P-A
P-H
P-F
P-A
Using M6x8 screws (P-G), attach the support bar to the columns at the desired position.
Using M6x25 screws (P-F), M6x8 screws (P-H) and butterfly nuts (P-A), attach the DVD
shelf to the support bar.
19-04-453-933909.indb 13 5/6/2019 11:33:34 AM

14
Assembly
10 Cable Management
Route the cables through
the cable covers.
19-04-453-933909.indb 14 5/6/2019 11:33:35 AM

15
Assembly
11 Adjustment
+10°
–10° TV height is measured
from the floor to the TV
center.
• Adjust the columns to the desired height before installing the display.
• If adjusting the column height after completing the display installation,
first remove the DVD shelf, then adjust the columns to the desired
height.
19-04-453-933909.indb 15 5/6/2019 11:33:36 AM

16
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
19-04-453 93-3909_RevB
Maintenance
• Check that the bracket is secure and safe to use at regular intervals (at
least every three months).
• Please visit www.tripplite.com/support if you have any questions.
19-04-453-933909.indb 16 5/6/2019 11:33:36 AM

17
1111 W. 35th Street, Chicago, IL 60609 EE UU • www.tripplite.com/support
Copyright © 2019 Tripp Lite. Todos los derechos reservados.
Manual del Propietario
Carro Móvil para
Dos Pantallas
Planas
Modelo: DMCSD3545M
200x200 / 300x200
300x300 / 400x200
400x300 / 400x400
1143 mm
[45"] MÁX. 40 kg x 2
[88 lb x 2]
TV
5 kg
[11 lb]
DVD
CÁMARA
WEB DE
5 kg
[11 lb]
English 1 • Françaís 33 • Русский 49 • Deutsch 65
19-04-453-933909.indb 17 5/6/2019 11:33:36 AM

18
NOTA: Lea todo el manual de instrucciones antes de iniciar la instalación y
ensamble.
Garantía
ADVERTENCIA
•No inicie la instalación hasta que haya leído y entendido las
instrucciones y advertencias contenidas en este manual. Si
tiene preguntas con respecto a cualquiera de las instrucciones o
advertencias, visite www.tripplite.com/support.
• Este producto fue diseñado para ser instalado y utilizado SOLAMENTE
como se especifica en este manual. La instalación incorrecta de este
producto puede causar daños o lesiones severas.
• Este producto debe ser instalado únicamente por alguien con una
buena habilidad mecánica, experiencia básica de construcción y un
entendimiento completo de este manual de instrucciones.
• Cerciórese que la unidad pueda soportar con seguridad la carga
combinada de todo el hardware y componentes instalados.
• Utilice siempre un ayudante o equipo de elevación mecánico para
levantar y colocar el equipo con seguridad.
• Este producto está diseñado para usarse sólo en interiores. Usar este
producto en exteriores podría derivar en fallas del producto y/o lesiones
personales.
Garantía Limitada por 5 Años
El vendedor garantiza este producto, si se usa de acuerdo con todas las instrucciones aplicables, de que
está libre de defectos en material y mano de obra por un período de 5 años a partir de la fecha de compra
inicial. Si el producto resultara defectuoso en material o mano de obra dentro de ese período, el vendedor
reparará o reemplazará el producto a su entera discreción.
ESTA GARANTÍA NO SE APLICA AL DESGASTE NORMAL O A LOS DAÑOS QUE RESULTEN DE ACCIDENTES,
USO INCORRECTO, USO INDEBIDO O NEGLIGENCIA. EL VENDEDOR NO OTORGA GARANTÍAS EXPRESAS
DISTINTAS A LA ESTIPULADA EN EL PRESENTE. SALVO EN LA MEDIDA EN QUE LO PROHÍBAN LAS
LEYES APLICABLES, TODAS LAS GARANTÍAS IMPLÍCITAS, INCLUYENDO TODAS LAS GARANTÍAS DE
COMERCIALIZACIÓN O IDONEIDAD, ESTÁN LIMITADAS EN DURACIÓN AL PERÍODO DE GARANTÍA
ESTABLECIDO; ASIMISMO, ESTA GARANTÍA EXCLUYE EXPRESAMENTE TODOS LOS DAÑOS INCIDENTALES
E INDIRECTOS. (Algunos estados no permiten limitaciones en cuanto a la duración de una garantía y
algunos estados no permiten la exclusión o limitación de daños incidentales o indirectos, de modo que las
limitaciones anteriores pueden no aplicar para usted. Esta garantía le otorga derechos legales específicos y
usted puede tener otros derechos que pueden variar de una jurisdicción a otra).
ADVERTENCIA: antes de usarlo, cada usuario debe tener cuidado al determinar si este dispositivo es
adecuado o seguro para el uso previsto. Ya que las aplicaciones individuales están sujetas a gran variación,
el fabricante no garantiza la adecuación de estos dispositivos para alguna aplicación específica.
19-04-453-933909.indb 18 5/6/2019 11:33:36 AM

19
Accesorios y Partes Incluidas en el Empaque
IMPORTANTE: Asegúrese antes de instalar, de haber recibido todas las piezas de
acuerdo a la lista de comprobación de componentes. Si faltase cualquier parte
o estuviese dañada, visite www.tripplite.com/support para solicitar servicio.
A
Tapa de Plástico
Izquierda
E
Placa Universal
H
Columna Izquierda
J
Soportes Adaptadores Izquierdos
L
Repisa para Cámara
P
Base Izquierda
Q
Base Derecha
M
Placa de Conexión
N
Travesaño
O
Barra de Soporte
I
Columna Derecha
K
Soportes Adaptadores Derechos
F
Tapas Superiores
G
Tapas para
Cables
B
Tapa de Plástico
Derecha
C
Base Central
D
Repisa para DVD
19-04-453-933909.indb 19 5/6/2019 11:33:36 AM

20
Lista de Comprobación de Componentes
de 5 mm
Paquete M
Paquete P
M-A
M5x14
M-B
M6x14
M-C
M8x20
M-D
M6x30
M-E
M8x30
M-F
Arandela
M-G
Espaciador
Pequeño
M-H
Espaciador
Grande
P-I
M8x65
P-N
Llave Hexagonal
P-O
Llave
P-J
M4x6
P-K
M4x6
P-L
Arandelas
D8
P-M
Arandelas
D6
P-C
M8x30
P-D
M8x40
P-E
M6x14
P-F
M6x25
P-G
M6x8
P-H
M6x14
P-A
Tuercas de
Mariposa
P-B
Tuercas de
Mariposa
19-04-453-933909.indb 20 5/6/2019 11:33:36 AM
