Tripp Lite PS-415-HGULTRA User manual

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model #: PS-415-HGULTRA
Medical Power Strip - Agency Approved for Use in Patient-Care Areas
Highlights
Fully tested, certified and compliant with UL 60601-1 and UL 60950-1
4 hospital-grade outlets with safety covers
Switchless design prevents accidental shutoff
15-ft. cord with hospital-grade plug
Rugged all-metal case
Approved for use within 6-ft. of patient-care areas
Description
Offering 15A AC power distribution for 120V applications in a rugged all-metal case, Tripp Lite's PS-415-HGULTRA is agency approved for use in a
variety of healthcare venues, including physicians' offices, imaging centers, laboratories and more. Featuring unique, patented (U.S. No. 7,375,939),
it resets automatically with no need for action by the user. Features include switchless design to prevent accidental shutoff, four NEMA 5-15R-HG
hospital-grade outlets with safety covers, NEMA 5-15P-HG hospital-grade plug, 15A resettable circuit breaker, and optional-use keyhole mounting
slots and flanges.
Applications
AC power distribution with hospital-grade receptacles and plug in healthcare applications where durability and reliability are required,
including areas where NEC requires hospital-grade receptacles
Patient rooms, treatment rooms, exam rooms, etc.
Package Includes
PS-415-HGULTRA Medical-Grade Power Strip
Owner's manual with warranty information
Features
Approved for use in Patient Care Areas
Rugged all-metal housing stands up to the most demanding environments
4 x NEMA 5-15R-HG outlets with safety covers
15-ft. cord with NEMA 5-15P-HG plug
Switchless design prevents accidental shutoff
15A circuit breaker
Multiple installation options with integral mounting flanges and slots
UL60601-1 and UL 60950-1 compliant
U.S. Patent No. 7,375,939

U.S. Patent No. 7,375,939
Specifications
OVERVIEW
Model Type For Patient-Care Areas
SYSTEM OVERVIEW
Voltage compatibility (VAC) 120
OUTPUT
Frequency compatibility 50 / 60 Hz
Output volt amp capacity
(amps)
15
Overload protection 15A resettable circuit breaker
Outlet quantity / type 4 NEMA 5-15R-HG
Outlet safety covers Yes
Outlet orientation Single row of 4
INPUT
Recommended Electrical
Service
15A 120V
Input connection type NEMA 5-15P-HG
Input cord length (ft.) 15
Input cord length (m) 4.572
LEDS ALARMS & SWITCHES
Switches No power switch
PHYSICAL
Unit Dimensions (HWD/in) 1.5 x 13.75 x 2.5
Unit Dimensions (HWD/cm) 3.8 x 34.9 x 6.4
Unit weight (lbs) 3.2
Unit weight (kg) 1.5
Material of construction Metal
Integrated keyhole
mounting tabs
Yes
Receptacle Color White
AC line cord color White
SPECIAL FEATURES
Appearance Attractive all-white color scheme
CERTIFICATIONS
Approvals TUV tested to UL 60601-1 and UL 60950-1 (USA); TUV tested to CAN/CSA-C22.2 No. 601.1-M90 and
60950-1-03 (Canada)
WARRANTY

Product Warranty Period
(U.S., Canada & Puerto
Rico)
Lifetime
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=3341.
