Quick Start Guide
Digital Signage In-Line 1G
POE Surge Protector
Model: B110-SP-POE
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
Este guía esta disponible en español en la página de Tripp Lite:
www.tripplite.com/support
Ce guide est disponible en français sur le site Web de Tripp Lite :
www.tripplite.com/support
Русскоязычная версия настоящего краткого руководства представлена
на веб-сайте компании Tripp Lite по адресу: www.tripplite.com/support
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
surge protector in our monthly drawing!
www.tripplite.com/warranty
19-03-092-93389F-EN.indd 1 5/17/2019 1:01:45 PM

2
Package Includes
Product Features
• B110-SP-POE
• Grounding Wire, 12 in. / 305 mm
• Mounting Screws (x4)
• Screw Anchors (x4)
• Grounding Wire Screw
• Quick Start Guide
• Protects your Power over Ethernet (PoE) device’s inputs and outputs against
electrostatic discharge (ESD), lightning surges and cable discharge events
• Meets the following IEC/EN regulations:
o IEC61000-4-2 / IEC61000-4-5 (ESD) 30kV (Air, Contact)
o EN61000-4-5 (Lightning) 5kA (8/20µs) / 4kV (10/700µs)
• Supports network data transmission speeds up to 1 Gbps
• Lightning reaction speed < 1 ns
• Solid-state silicon-avalanche technology
• Meets IEEE standards 802.3af and 802.3at
• Supports both mid- and end-span PoE
• Easy in-line installation with integrated mounting ears
• Passive by design – no external power required
19-03-092-93389F-EN.indd 2 5/17/2019 1:01:45 PM
Protection

3
Installation
Note: The following instructions assume that two PoE devices are currently connected
together.
Single Device Protection:
1. Disconnect the installed patch cable from the device you wish to protect
and attach this cable to the “Cable End” of the In-Line 1G PoE Surge
Protector.
2. Using a Cat5/5e/6 patch cable (not included), connect the device to be
protected to the “Equipment End” of the In-Line 1G PoE Surge Protector.
Note: For the best protection performance, the patch cable between the
“Equipment End” of the In-Line 1G PoE Surge Protector and the equipment to
be protected should not exceed 300 ft. (90 m). Tripp Lite’s N001-Series Cat5e
Snagless Patch Cables are recommended.
3. Connect the ground wire to the In-Line 1G PoE Surge Protector and then
to earth ground.
IP Phone
PoE Hub
OR
OR
PoE Camera
PoE NVR
Equipment End
PoE Equipment
(Protected)
PoE Sources
(Unprotected)
In-Line 1G PoE
Surge Protector
Cable End
19-03-092-93389F-EN.indd 3 5/17/2019 1:01:45 PM

4
Installation
Multiple Device Protection:
Note: The max distance between any two In-Line 1G PoE Surge Protectors is 328 ft.
(100 m).
1. Disconnect the installed patch cable from both of the devices you wish to
protect.
2. Connect an In-Line 1G PoE Surge Protector to each end of the previously
uninstalled patch cable, ensuring both ends of the patch cable are
connected to the “Cable End” of the In-Line 1G PoE Surge Protector.
3. Using Cat5/5e/6 patch cables (not included), connect the “Equipment
End” of each In-Line 1G PoE Surge Protector to the PoE device and
equipment you wish to protect.
Note: For the best protection performance, the Cat5/5e/6 patch cable between
the “Equipment End” of the In-Line 1G PoE Surge Protector and the PoE
equipment to be protected should not exceed 300 ft. (90 m). Tripp Lite’s
N001-Series Cat5e Snagless Patch cables are recommended.
4. Connect the ground wire to each In-Line Surge Protector and then to earth
ground.
Equipment End
Cable End
Equipment End
Cable End
328 ft.
(100 m) Max
OR
PoE Equipment
(Protected)
PoE Sources
(Protected)
PoE Hub
OR
PoE NVR
IP Phone PoE Camera
19-03-092-93389F-EN.indd 4 5/17/2019 1:01:45 PM

5
Specifications
Input / Output Connectors RJ45 (Female)
ESD Protection 30kV (Air, Contact)
Lightning Protection 5kA (8/20 µs) / 4kV (10/700µs)
Lightning Protection Reaction Speed <1 ns
Operating Temp 14 to 158°F / -10 to 70 °C
Storage Temp -40 to 194°F / -40 to 90°C
Bandwidth (Date Rate) Up to 1 Gbps
IEEE Standards Supported 802.3af/at
Dimensions 2.63 x 3.43 x 1.06 in. /
67 x 87 x 27 mm
Weight 0.28 lb. / 127 g
19-03-092-93389F-EN.indd 5 5/17/2019 1:01:45 PM

6
Warranty and Product Registration
2-Year Limited Warranty
Tripp Lite warrants its products to be free from defects in materials and workmanship for a period
of two (2) years from the date of initial purchase. Tripp Lite’s obligation under this warranty is
limited to repairing or replacing (at its sole option) any such defective products. To obtain service
under this warranty, you must obtain a Returned Material Authorization (RMA) number from
Tripp Lite or an authorized Tripp Lite service center. Products must be returned to Tripp Lite or an
authorized Tripp Lite service center with transportation charges prepaid and must be accompanied
by a brief description of the problem encountered and proof of date and place of purchase. This
warranty does not apply to equipment, which has been damaged by accident, negligence or
misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, Tripp Lite MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid
limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL Tripp Lite BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS
PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, Tripp Lite is not
liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment,
loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.
Product Registration
Visit www.tripplite.com/warranty today to register your new Tripp Lite product. You’ll be
automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
Use of this equipment in life support applications where failure of this equipment can reasonably
be expected to cause the failure of the life support equipment or to significantly affect its safety
or effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without
notice. Photos and illustrations may differ slightly from actual products.
