Tripp Lite ISOBAR6DBS User manual

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model #: ISOBAR6DBS
6 outlet, 6ft cord, 2850 joules, 2-line coaxial, 1-line tel/modem, All-metal housing Isobar Surge Suppressor
Highlights
6 outlets / 6-ft. cord
2850 joule rating
Isolated Filter Banks / all-metal housing
2-line 2.2 GHz gold coaxial protection
1-line tel/modem surge protection
$250,000 Ultimate Lifetime Insurance (USA and Canada only)
Description
Tripp Lite's ISOBAR6DBS Isobar Home/Business Theater Surge Suppressor provides premium protection--2850 joules--stopping damaging surges
and filtering disruptive line noise so components perform at their peak! You can see and hear the difference: sharper, crisper video; deeper, fuller
audio and longer component life spans. Perfect for small-to-medium home/business theater installations: high-definition TVs, satellite and A/V
receivers, DVD/CD players and more. Exclusive Isolated Filter Banks eliminate noise interference between components. 6 outlets (with transformer
spacing and plug-in safety covers), 2-line 2.2 GHz gold coaxial protection and 1-line tel/modem protection safeguard an entire home/business
theater system. $250,000 Ultimate Lifetime Insurance coverage (USA and Canada only). Includes all-metal housing, three diagnostic LEDs, 6-ft. cord
with a right-angle plug, 6-ft. coaxial cable and 6-ft. phone cord.
Applications
Perfect for small-to-medium home/business theater installations: high-definition TVs, satellite and A/V receivers, DVD/CD players and more
Package Includes
ISOBAR6DBS Home/Business Theater Surge Suppressor
6 ft. gold coaxial cable
6 ft. phone cord
Instruction manual with warranty information
Features
2850 joules surge suppression rating with EMI/RFI line noise filtering help components perform at their peak (sharper, crisper video; deeper,
fuller audio and longer component life spans)
$250,000 Ultimate Lifetime Insurance (USA and Canada only) covers connected components against surge damage...for life!
Isolated Filter Banks eliminate interference between connected components
All-metal housing safely withstands the strongest surges
6 surge-protected NEMA 5-15R AC outlets safeguard an entire home/business theater system
Widely spaced outlets accommodate up to 3 transformers
Four plug-in safety covers protect against accidental contact
2 sets of 2.2GHz gold coaxial protection to safeguard components on cable, satellite or antenna line (includes 6-ft gold coax cable)
1-line tel/modem surge protection (with included 6-ft. phone cord) safeguards personal video recorders (PVRs) on a single dial-up line.
6-ft. cord with right-angle NEMA 5-15P plug provides convenient location anywhere within a home/business theater system
3 diagnostic LEDs alert user to protection, line power and fault status
Keyhole slots provide convenient wall or cabinet mounting
Illuminated master switch provides one-touch power control over all components. Circuit breaker protects against dangerous system
overload

All-metal housing (black) stands up to the most demanding environments
UL and cUL listed
Specifications
OVERVIEW
Intended Application Home/Office, Computer Networks, Audio/Video
OUTPUT
Frequency compatibility 50 / 60 Hz
Output watts 1440
Circuit Breaker (amps) 12
Outlet quantity / type 6 NEMA 5-15R
Transformer accommodation Accommodates 3 transformers
INPUT
Recommended Electrical
Service
120V (110-125V)
Input connection type NEMA 5-15P
Input plug features Space-saving right angle input plug
Input cord length (ft.) 6
Input cord length (m) 1.8
Input cord gauge, type 14 gauge, SJT
Voltage compatibility (VAC) 120
Maximum Surge Amps 135000
LEDS ALARMS & SWITCHES
Switches Combination AC circuit breaker and two position red illuminated on/off power switch
Diagnostic LEDs PROTECTION PRESENT (green), LINE FAULT (red) and LINE OK (green)
SURGE / NOISE SUPPRESSION
AC suppression joule rating 2850
AC suppression response
time
NM = 0 ns. CM =
Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression
Clamping voltage (RMS) 140V
UL1449 let through rating 330V - UL verified
EMI / RFI filtering Up to 40 dB40-80 dB
DATALINE SURGE SUPPRESSION
Telephone/DSL Protection Yes
Telephone/DSL Protection
Details
1 line
Cable (Coax) Protection Yes

Cable (Coax) Protection
Details
2 line
Network (Ethernet) Protection No
PHYSICAL
Shipping weight (lbs) 3.6
Shipping weight (kg) 1.6
Unit Dimensions (HWD/in) 2.5 x 9 x 3.5
Unit Dimensions (HWD/cm) 6.35 x 22.9 x 8.9
Shipping Dimensions
(HWD/in)
3 x 11.5 x 7
Shipping Dimensions
(HWD/cm)
7.62 x 29.2 x 17.8
Unit weight (lbs) 2.8
Unit weight (kg) 1.27
Material of construction Metal
Integrated keyhole mounting
tabs
Keyhole mounting slots allow desk or wall mounting
Receptacle Color Black
AC line cord color Black
Style Strip
Outlets center to center
measurement
Distance between horizontal outlets = 39.45mm; Distance between vertical outlets = 39.30mm
Keyhole slot center to center
measurement
Distance between horizontal tabs = 210.79mm; Distance between vertical tabs = 58.17mm
SPECIAL FEATURES
Appearance Rugged all-metal corded strip format with high quality duplex receptacles
Right-Angle Plug Yes
CERTIFICATIONS
UL1449 3rd Edition (AC
Suppression)
UL1449
UL1363 (Power Tap) UL1363UL1363
UL497A (Communications) UL497A
FCC Part 68
(Communications)
FCC PFCC Part 68art 68
cUL / CSA (Canada) cULcUL
Approvals Exceeds IEEE 587 category A&B specifications
WARRANTY
Product Warranty Period
(Worldwide)
Lifetime limited warranty

Connected Equipment
Insurance (U.S., Canada &
Puerto Rico)
$250,000 Ultimate Lifetime Insurance
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=2814.
