Model #: TMC-6
6-outlet, 6-ft cord, 1440 joules, Tel/Modem protection, Under-Monitor Protect It! Surge Suppressor
Highlights
6 outlets / 6-ft. cord
1440 joule rating
Tel/modem surge protection
Individual switches
$50,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)
Description
Tripp Lite's TOUCHMASTER COMPACT surge suppressor offers complete AC and phone line surge suppression for comprehensive protection of
workstations, desktop PCs, telecom systems and other sensitive electronics. Heavy grade AC surge suppression shields connected equipment from
damage and performance problems due to transient surges. RJ11 telephone line suppression jacks protect dialup and DSL modem lines, fax
machines, cordless phones and more. TOUCHMASTER COMPACT offers 6 total outlets, 6 foot cord and LEDs to warn of power and wiring
problems. Heavy grade AC suppression rated at 1440 joules shields equipment from surges and line noise. Attractive, slim design is perfect for use
under desktop computer monitors or notebook computers. Individual switches offer power control over connected equipment. $50,000 Ultimate
Lifetime Insurance (USA, Puerto Rico and Canada only).
PLUG/OUTLETS: Input: NEMA5-15P/Output: 6 NEMA5-15R/6-ft. AC line cord
ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA5-15R wall receptacle)
FORMAT: Slim, compact design perfect for use under desktop monitors and notebook computers
SUPPRESSION: AC: 150V RMS Clamping/1440 joules/400V UL1449 3rd Edition
Applications
Ideal for PCs, notebook computers, peripherals and home electronics
Package Includes
TOUCHMASTER COMPACT surge suppressor
6-ft. phone cord
Instruction manual and warranty information
Features
6 outlets
6-ft. cord with space-saving right-angle plug
Built-in RJ11 jacks prevent surges from damaging your modem/fax equipment; 6-ft. telephone cord included
Surge suppression rating: 1440 joules
EMI/RFI noise filtering

15 amp resettable circuit breaker
Diagnostic LEDs confirm suppressor "protection present" (green), "grounded" (red) status and "power on" (green)
Always-on outlet provides power for equipment you always need on, even when the "master" switch is off
Includes full normal mode (H-N) and common mode (N-G/H-G) line surge suppression
Allows for the computer to be controlled by the "master" switch and other outlets to be controlled either the "master" switch or corresponding
switch on the front panel
$50,000 Ultimate Lifetime Insurance (USA, Puerto Rico and Canada only) covers connected equipment
Specifications
OVERVIEW
Intended Application Home/Office
OUTPUT
Frequency compatibility 50 / 60 Hz
Output watts 1800
Circuit Breaker (amps) 15
Outlet quantity / type 6 NEMA 5-15R
INPUT
Recommended
Electrical Service
120V (110-125V)
Input connection type NEMA 5-15P input plug
Input plug features Space-saving right angle input plug
Input cord length (ft.) 6
Input cord length (m) 1.8
Input cord gauge, type 14 gauge, SJT
Voltage compatibility
(VAC)
120
Maximum Surge Amps 84000
LEDS ALARMS & SWITCHES
Switches Includes 5 front panel AC power switches. 4 switches control individual outlets and 1 serves as a main power
switch that controls all but the one marked "unswitched" on the back panel
Diagnostic LEDs Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
SURGE / NOISE SUPPRESSION
AC suppression joule
rating
1440
AC suppression
response time
< 1 ns
Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression
Clamping voltage (RMS) 150V
UL1449 let through
rating
400V - UL Verified
DATALINE SURGE SUPPRESSION
Telephone/DSL
Protection
Yes

Telephone/DSL
Protection Details
1 line
Cable (Coax) Protection No
Network (Ethernet)
Protection
No
PHYSICAL
Shipping weight (lbs) 3.4
Shipping weight (kg) 1.54
Unit Dimensions
(HWD/in)
1.75 x 11.5 x 12
Unit Dimensions
(HWD/cm)
4.45 x 29.21 x 30.48
Shipping Dimensions
(HWD/in)
2.25 x 12.5 x 14
Shipping Dimensions
(HWD/cm)
5.72 x 31.75 x 35.56
Unit weight (lbs) 2.8
Unit weight (kg) 1.27
Material of construction Plastic
Style Under Monitor
Form factors supported Supports under monitor placement as a power control center for an entire PC system with peripherals
SPECIAL FEATURES
Right-Angle Plug Yes
WARRANTY
Product Warranty
Period (Worldwide)
Lifetime limited warranty
Connected Equipment
Insurance (U.S.,
Canada & Puerto Rico)
$50,000 Ultimate Lifetime Insurance
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=2636.
