Tripp Lite Classic DMCS3770L User manual

1
Owner’s Manual
Mobile Flat-Panel
Classic
Model: DMCS3770L
CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR
PROPERTY DAMAGE MAY OCCUR!
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2017 Tripp Lite. All rights reserved.
200 x 200 / 300 x 300 /
400 x 200 / 400 x 400 /
600 x 400
70”
MAX
TV
88 lb.
(40 kg)
MAX
DVD
22 lb.
(10 kg)
MAX
Este manual esta disponible en español en la página de Tripp Lite: www.tripplite.com
Ce manuel est disponible en français sur le site Web de Tripp Lite : www.tripplite.com
Русскоязычная версия настоящего руководства представлена на веб-сайте компании
Tripp Lite по адресу: www.tripplite.com
Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar: www.tripplite.com
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate peace of mind.
You could also win an ISOBAR6ULTRA surge protector—a $100 value!
www.tripplite.com/warranty
17-11-297-9337CE-EN.indd 1 12/21/2017 10:10:12 AM

2
NOTE: Read the entire instruction manual before you start assembly and installation.
WARNING
• Do not begin the installation until you have read and understood the instructions
and warnings contained in this manual. If you have any questions regarding any
of the instructions or warnings, please visit www.tripplite.com/support
• This mounting bracket was designed to be installed and utilized ONLY as
specified in this manual. Improper installation of this product may cause damage
or serious injury.
• This product should only be installed by someone of good mechanical ability,
with basic building experience and a full understanding of this instruction
manual.
• Make sure that the mounting surface can safely support the combined load of
the equipment and all attached hardware and components.
• Always use an assistant or mechanical lifting equipment to safely lift and position
equipment.
• Tighten screws firmly, but do not over-tighten. Over-tightening screws can
damage the items, greatly reducing their holding power.
• This product is intended for indoor use only. Using this product outdoors could
lead to product failure and personal injury.
17-11-297-9337CE-EN.indd 2 12/21/2017 10:10:12 AM

3
Component Checklist
IMPORTANT: Ensure that you have received all parts according to the component checklist prior to
installing. If any parts are missing or faulty, visit www.tripplite.com/support for service.
Left Leg
A
M5 x 14 Screw (x4)
M-A
M5 x 14 Screw (x4)
P-A
D8 Washer (x4)
P-F
8mm Allen Wrench (x1)
P-K
M8 x 50 Screw (x4)
M-E
Front
Caster (x2)
F
Rear
Caster,
Locking (x2)
G
Mounting Arm (x2)
M
Universal Plate
J
Telescoping Pole (x2)
H
Shelf Screw Cover (x2)
N
DVD Shelf
K
Bracket (x2)
L
Hole Cover (x6)
I
Right Leg
B
M6 x 14 Screw (x4)
M-B
M6 x 40 Screw (x4)
P-B
D6 Washer (x8)
P-G
Washer (x4)
M-F
M8 x 60 Screw (x4)
P-C
M8 Nut (x4)
P-H
Small Spacer (x8)
M-G
M6 x 30 Screw (x4)
M-C
M10 x 35 Screw (x2)
P-D
Wrench (x1)
P-I
Big Spacer (x8)
M-H
M8 x 30 Screw (x4)
M-D
D10 Washer (x2)
P-E
5mm Allen Wrench (x1)
P-J
Left Cover
C
Right Cover
D
Middle Base
E
Package M
Package P
17-11-297-9337CE-EN.indd 3 12/21/2017 10:10:12 AM

4
1. Assembling the Base
P-A
P-G
P-G
P-I
P-B
P-J
A
D
B
C
E
G
G
F
F
FRONT
1) Attach Front Casters Fand Rear Casters Gto both Left Leg Aand Right Leg Busing Wrench P-I.
2) Attach Middle Base Eto the Legs. Secure top bar with Screws P-A and Washers P-G. Secure to sides of Legs
with Screws P-B and Washers P-G using Allen Wrench P-J.
3) Attach Left Cover Cand Right Cover Dto Legs.
17-11-297-9337CE-EN.indd 4 12/21/2017 10:10:15 AM

5
2. Attaching Telescoping Sidebars
P-K
P-D
P-E
H
1) Adjust Telescoping Poles Hto desired height using button. Cover exposed holes with Hole Covers I.
2) Insert Poles Hinto the holes on the Middle Base E. Secure with Screws P-D and Washers P-E using Allen
Wrench P-K.
17-11-297-9337CE-EN.indd 5 12/21/2017 10:10:17 AM
H
locking pin
Position 1
Rotate the inner column to locate the locking pin, then press it and adjust to Position 1.
I

6
3. Attaching Universal Plate
Insert Washers P-F and Nuts P-H into rear of Telescoping Poles Hat desired height. Secure Universal Plate J
with Screws P-C using Allen Wrench P-J.
P-I
P-JP-C
J
P-H P-F
17-11-297-9337CE-EN.indd 6 12/21/2017 10:10:20 AM

7
4. Installing the DVD Shelf
K
N
L
1) Slide Brackets Linto DVD Shelf K.
2) Insert Bracket hooks at desired height into Telescoping Poles H. Push down to secure.
3) Cover exposed holes with Shelf Screw Covers N.
17-11-297-9337CE-EN.indd 7 12/21/2017 10:10:22 AM

8
M-C
M-D
M-E
M-C
M-D M-E M-E
M-C
M-D
M-F
M-F
M-F M-F M-F
M-F
M-G
M-H
M-G M-G M-G
M-H M-H M-H
M-H
M-A
M-B
M
M
M-F
5. Installing the Mounting Arms
5.1 For Flat-Back Screens
5.2 For Recessed-Back Screens or Accessing A/V Inputs
Note: Choose the appropriate Screws, Washers and Spacers (if needed) according to the type of screen.
Screw the Mounting Arms onto the display.
CAUTION: Tighten all screws but do not over-tighten.
Note: Choose the appropriate Screws, Washers and Spacers (if needed) according to the type of screen.
Screw the Mounting Arms onto the display.
CAUTION: Tighten all screws but do not over-tighten.
17-11-297-9337CE-EN.indd 8 12/21/2017 10:10:27 AM

9
6. Hooking the Display to the Universal Plate
CAUTION: Be sure the display is correctly mounted and that the screws are safely tightened
before releasing the display.
1) Hook the Mounting Arms onto the Universal Plate attached to the Telescoping Poles.
2) Secure by tightening Screws with user-supplied Phillips-head screwdriver.
17-11-297-9337CE-EN.indd 9 12/21/2017 10:10:29 AM

10
7. Cable Management & Display Adjustment
+10°
–10°
Route cables through
Hole Covers (optional).
Loosen the knobs to adjust the display to the desired angle.
Tighten the knobs to secure.
-
+
