Tripp Lite AVR750U User manual

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model #: AVR750U
AVR Series 750VA Ultra-compact Line-Interactive 120V UPS with USB port
Highlights
750VA ultra-compact 120V line interactive UPS
Corrects brownouts and overvoltages from 83V to 147V
6 UPS battery supported outlets, 6 surge-only outlets
USB port, TEL/DSL protection, Wall mountable, 98% efficient
NEMA 5-15P input plug and 12 NEMA 5-15R outlets
Description
Tripp Lite's AVR750U Ultra-Compact Line Interactive UPS offers complete power protection for desktop PCs, network workstations and a wide
variety of professional and consumer electronic devices. Uninterruptible Power Supply / UPS circuits switch to battery backup mode within
milliseconds to keep connected equipment running without interruption or data loss during power failures. Automatic Voltage Regulation / AVR power
conditioning maintains smooth, continuous operation of connected equipment during brownouts and overvoltages. Surge-only outlets offer
convenient protection for printers and other desktop accessories not requiring battery support. AC and dataline surge suppression prevents
connected equipment damage. USB communications port supports built-in power management and auto-shutdown features of Windows and Mac
OS X or full featured monitoring and data-saving auto-shutdown options using Tripp Lite's free PowerAlert monitoring software.
Package Includes
AVR750U UPS System
USB cable
Instruction manual
Features
AVR750U ultra-compact 120V line interactive UPS offers complete AC power protection from blackouts, brownouts and transient surges
750VA / 450 watt UPS output capacity
Uninterruptible Power Supply / UPS operation maintains battery-derived AC output during blackouts to prevent data loss and system
downtime for connected equipment
Built-in USB port enables data-saving unattended shutdown when used with Tripp Lite's PowerAlert software, available via FREE download
from www.tripplite.com
HID-compliant USB port also enables integration with built-in power management and auto shutdown features of Windows and Mac OS X
Automatic Voltage Regulation / AVR corrects extended brownouts and overvoltages from 83 to 147V, without using battery power
3 minutes runtime at 100% load (450 watts), 10 minutes runtime at 50% load (225 watts)
44 minutes runtime for a desktop computer system consuming 80 watts continuous
12 built-in NEMA 5-15R outlets, two with extra wide spacing to accommodate transformer plugs
6 UPS battery backup outlets, plus 6 additional surge-only outlets
Right angle NEMA 5-15P input connection with 6ft / 1.8m line cord
Network grade AC surge and lightning protection is available from all outlets; Built-in data line surge suppression protects a single dialup or
DSL line
Supports Tripp Lite's Watchdog system service to restore operation to locked equipment through soft reboot of application/OS or hard
power off/on reboot of connected equipment, ideal for unattended kiosk applications
98% line mode efficiency rating uses less energy and BTU emissions
Built-in grounding lug

Hot swappable user battery replacement
Space saving, ultra-compact housing with support for wall-mount, desktop or floor placement
Specifications
OUTPUT
Output Volt Amp Capacity
(VA)
750
Output Watt Capacity (watts) 450
Nominal Output Voltage(s)
Supported
115V; 120V
Frequency compatibility 60 Hz
Output voltage regulation
(line mode)
120V (+8%, -21%)
Output voltage regulation
(Battery mode)
115V (+/- 5%)
Built-in UPS output
receptacles
12 5-15R outlet(s)
Surge suppression only
outlets
6 UPS outlets, 6 surge-only outlets
Output AC waveform (AC
mode)
Sine wave
Output AC waveform
(battery mode)
PWM sine wave
INPUT
Rated input current (at
maximum load)
12A
Nominal Input Voltage(s)
Supported
120V AC
UPS input connection type 5-15P
UPS Input cord length (ft.) 6
UPS Input cord length (m) 1.8
Recommended Electrical
Service
15A 120V
BATTERY
Full load runtime (minutes) 3 min. (450w)
Half load runtime (minutes) 10 min. (225w)
DC system voltage (VDC) 12
Replacement battery
cartridge (internal UPS
battery replacement)
RBC51
Battery Access Battery access door
Battery replacement
description
Hot-swappable, user replaceable battery
VOLTAGE REGULATION

Voltage regulation
description
Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 83 to 147
Overvoltage correction Input voltages between 129 and 147 are reduced by 12%
Undervoltage correction Input voltages between 83 and 104 are boosted by 14%
LEDS ALARMS & SWITCHES
LED Indicators 2 LEDs indicate power status and overload/check battery status
Alarms Audible alarm indicates power-failure and overload status
Switches Combination switch controls on/off power status and self-test operation
SURGE / NOISE SUPPRESSION
UPS AC suppression joule
rating
420
UPS AC suppression
response time
Instantaneous
UPS Dataline suppression 1 line TEL/DSL (1 in / 2 out)
EMI / RFI AC noise
suppression
Yes
PHYSICAL
Installation form factors
supported with included
accessories
Tower; Ultra-compact desktop; Wallmount (using keyhole mounting tabs)
Primary form factor Desktop
UPS / Power Module
dimensions in primary form
factor (height x width x
depth / inches)
4 x 12 x 7
UPS / Power Module
dimensions in primary form
factor (height x width x
depth / cm)
10.2 x 30.5 x 17.8
UPS / Power Module weight
(lbs)
15.3
UPS / Power Module weight
(kg)
6.9
UPS Shipping dimensions
(height x width x depth /
inches)
5.5 x 14.5 x 9.8
UPS Shipping dimensions
(height x width x depth / cm)
14 x 36.8 x 24.8
Shipping weight (lbs) 16.8
Shipping weight (kg) 7.6
UPS housing material ABS
ENVIRONMENTAL
Operating Temperature
Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 0 to 95%, non-condensing
AC mode BTU / hr. (full load) 27
COMMUNICATIONS
Communications interface USB (HID enabled)
PowerAlert software Free download from www.tripplite.com
Communications cable USB interface cable included
WatchDog compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications
LINE / BATTERY TRANSFER
Transfer time 2 to 4 milliseconds
Low voltage transfer to
battery power (setpoint)
83
High voltage transfer to
battery power (setpoint)
147
SPECIAL FEATURES
Grounding lug Included
Cold Start (startup in battery
mode during a power failure)
Cold-start operation supported
High availability UPS
features
Hot swappable batteries
Green & high efficiency
features
Greater than 95% efficiency - GREEN UPS
CERTIFICATIONS
UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category
B (EMI)
WARRANTY
Product Warranty Period
(U.S. & Canada)
3-year limited warranty
Product Warranty Period
(International)
2-year limited warranty
Product Warranty Period
(Mexico)
3-year limited warranty
Product Warranty Period
(Puerto Rico)
3-year limited warranty
Connected Equipment
Insurance (U.S., Canada &
Puerto Rico)
$100,000 Ultimate Lifetime Insurance
Related Items
Optional Products
Product Type Related Model Description Qty.
Audio Cables CT120 Instant-Read- AC Outlet Circuit Tester 1
Extended Warranties WEXT5-INTERNET 5-Year Extended Warranty - For Internet Office, AVR and ECO Series
UPS Systems
1

Software WATCHDOGSW WatchDog Service Monitoring / Reboot Software 1
Surge Protectors DCATV Network Surge Suppressor - Essential protection for TV/VCR coaxial
lines
1
Surge Protectors DNET1 Network Surge Suppressor - Essential protection for data and
communication lines
1
Surge Protectors DTEL2 Network Surge Suppressor - Essential protection for data and
communication lines
1
USB Cables & Adapters U005-10I 10-inch USB A/A Gold Extension Cable
(USB-A Right Angle Male to USB-A Female)
1
USB Hubs/Accessories U222-004-R 4-Port USB2.0 Ultra-Mini Hub 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=3141.
