Triton XT18 User manual

tritontools.com
X T18 CD2BS
18V Combi Hammer Drill
144696_Z1MANPRO1.indd 2 07/07/2015 12:46

2
144696_Z1MANPRO1.indd 2 07/07/2015 12:46

3
1
2 3 4
5
6
7
8
11
9
10
13
12
14
15
Fig.I
POWER LEVEL
PRESS
144696_Z1MANPRO1.indd 3 07/07/2015 12:46

4
Thank you for purchasing this Triton tool. This manual contains information necessary for safe and effective operation of this product.
This product has unique features and, even if you are familiar with similar products, it is necessary to read this manual carefully to ensure
you fully understand the instructions. Ensure all users of the tool read and fully understand this manual.
VVolts
~Alternating current
AAmpere
n0No load speed
Hz Hertz
W, kW Watt, kilowatt
/min or min-1 (revolutions or reciprocation) per minute
Technical Abbreviations Key
Specification
Model number: XT18CD2BS
Voltage: 18V, D.C.
No load speed: 0 - 450min-1 (low gear)
0 - 1600min-1 (high gear)
Impact frequency: 7200/min (low gear)
25,600/min (high gear)
Gears: 2
Speed control: Trigger
Torque settings: 16+2
Maximum torque: 48Nm
Chuck capacity: Ø13mm
Drilling capacity (wood): Ø26mm
Drilling capacity (masonry): Ø10mm
Drilling capacity (steel): Ø13mm
Dimensions (L x W x H): 100 x 235 x 230mm
Weight: 1.9kg (with battery)
Battery Pack:
Cell type: Li-Ion
Voltage: 18V, D.C.
Capacities: 1.5Ah (XT15AHB), 2.0Ah
(XT2AHB), 3.0Ah (XT3AHB) &
4.0Ah (XT4AHB)
Charging times (XT35C charger): 3-5hrs (1.5Ah & 2.0Ah),
5-7hrs (3.0Ah & 4.0Ah)
• Batteries supplied will vary depending on pack configuration
Battery Charger PSU
Model No: XT35C
Input power: 230-240V~ 50/60Hz, 13W
Output power: 22.7V DC, 380mA
Protection class:
Cable length: 2m
Battery Charger
Input Voltage: 22.7V DC
Output Voltage: 14.4-18V DC
Battery Compatibility: XT 18V
As part of our ongoing product development, specifications of Triton
products may alter without notice.
Description of Symbols
Wear hearing protection
Wear eye protection
Wear breathing protection
Wear head protection
Wear hand protection
Read instruction manual
Caution!
Charger: Class II construction (double insulated for
additional protection)
Indoors use only (battery and battery charger)
DO NOT incinerate batteries!
Internal time-lag fuse with rated current 3.15A
Environmental Protection
Waste electrical products should not be disposed of
with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for
recycling advice.
Environmental Protection
Waste electrical products and batteries, including
Li-Ion batteries, should not be disposed of with
household waste. Please recycle where facilities
exist. Check with your local authority or retailer for
recycling advice.
Conforms to relevant legislation and safety
standards.
T3.15A
144696_Z1MANPRO1.indd 4 07/07/2015 12:46

5
WARNING: Always wear ear protection where the sound level exceeds 85dB(A)
and limit the time of exposure if necessary. If sound levels are uncomfortable,
even with ear protection, stop using the tool immediately and check the ear
protection is correctly fitted and provides the correct level of sound attenuation
for the level of sound produced by your tool.
WARNING: User exposure to tool vibration can result in loss of sense of touch,
numbness, tingling and reduced ability to grip. Long term exposure can lead to
a chronic condition. If necessary, limit the length of time exposed to vibration
and use anti-vibration gloves. Do not operate the tool with hands below a
normal comfortable temperature, as vibration will have a greater effect. Use
the figures provided in the specification relating to vibration to calculate the
duration and frequency of operating the tool.
Sound and vibration levels in the specification are determined according to
EN60745 or similar international standards. The figures represent normal use
for the tool in normal working conditions. A poorly maintained, incorrectly
assembled, or misused tool, may produce increased levels of noise and
vibration. www.osha.europa.eu provides information on sound and vibration
levels in the workplace that may be useful to domestic users who use tools for
long periods of time.
General Safety
WARNING Read all safety warnings and all instructions. Failure to follow
the warnings and instructions may result in electric shock, fire and/or serious
injury.
WARNING: This appliance is not intended for use by persons (including
children) with reduced, physical or mental capabilities or lack of
experience or knowledge unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety. Children must be supervised to ensure that they do not play with
the appliance.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce risk of electric
shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is unavoidable, use a
residual current device (RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
g) When used in Australia or New Zealand, it is recommended that this tool is
ALWAYS supplied via Residual Current Device (RCD) with a rated residual
current of 30mA or less.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal
injury.
b) Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard hat,
or hearing protection used for appropriate conditions will reduce personal
injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your finger on the switch or
energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool may
result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery
or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of dust collection can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off.
Any power tool that cannot be controlled with the switch is dangerous and
must be repaired.
c) Disconnect the plug from the power source and/or the battery pack
from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to
operate the power tool. Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
Sound and vibration information
Sound pressure LPA:87.6dB(A)
Sound power LWA:98.6dB(A)
Uncertainty K: 3dB
Weighted vibration
(metal) αh,D: 2.373m/s2
(masonry) αh,ID: 13.83m/s2
Uncertainty K: 1.5m/s2
The sound intensity level for the operator may exceed 85dB(A) and sound
protection measures are necessary.
144696_Z1MANPRO1.indd 5 07/07/2015 12:46

6
5) Battery tool use and care
a) Recharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk of
fire when used with another battery pack.
b) Use power tools only with specifically designated battery packs. Use
of any other battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other small
metal objects that can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or
a fire. If liquid contacts eyes, additionally seek medical help. Liquid ejected
from the battery may cause irritation or burns.
d) Under abusive conditions, liquid may be ejected from the battery;
avoid contact. If contact occurs, flush with water. If liquid contacts
eyes, additionally seek medical help. Liquid ejected from the battery
may cause irritation or burns.
6) Service
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
Hammer Drill Safety
WARNING!
• Wear ear protectors when impact drilling. Exposure to noise can cause
hearing loss.
• Use auxiliary handle(s), if supplied with the tool. Loss of control can
cause personal injury.
• Hold power tool by insulated gripping surfaces, when performing an
operation where the cutting accessory may contact hidden wiring
or its own cord. Cutting accessory contacting a “live” wire may make
exposed metal parts of the power tool “live” and could give the operator an
electric shock
IMPORTANT: If you suspect or discover asbestos is present in any area you
are working in, seek professional advice immediately. Removal of asbestos
should be done by a licensed contractor. Contact the HSE in the UK (www.hse.
gov.uk) or your national health and safety authority in your country for further
information about dealing with asbestos. European Directive 2009/148/EC
provides additional information related to exposure to asbestos at work.
a) DO NOT allow anyone under the age of 18 years to use this tool.
Ensure that operators are qualified and familiar with the operating and
safety instructions.
b) Use personal protective equipment (PPE) including safety glasses and
protective clothing.
c) Wear respiratory protection suitable for the work being undertaken.
A minimum rating of FFP2 is recommended.
d) If operating the tool causes discomfort in any way, stop immediately
and review your method of use.
e) Wear suitable protective anti-vibration gloves that are non-fabric
or coated fabric to prevent loose strands of material catching in the
rotating drill bit. Discard gloves immediately if material is visibly frayed.
f) Hammer drills produce a very high level of vibration when operating
in hammer mode. Frequent breaks are advised.
g) Use metal and voltage detectors to locate concealed electric, water or
gas lines. Avoid touching live components or conductors.
h) Extension cable reels used with this tool must be completely
unwound. Minimum conductor cross section: 1.0mm2.
i) When using this tool outdoors fit a RCD (GFCI in USA and Canada) to
the mains connection. Ensure any extension cables used are suitable for
outdoor use with water-resistant connections.
j) Ensure that the drill bit is securely fixed in the chuck. Insecure drill bits
can be ejected from the machine causing a hazard.
k) Ensure that the lighting is adequate.
l) Ensure that the drill bit is in contact with the workpiece prior to
starting up the tool.
m) Before drilling, check that there is sufficient clearance for the drill bit
under the workpiece.
n) Use both hands when operating this tool.
o) DO NOT put pressure on the tool; to do so would shorten its service
life.
p) Drill bits get hot during operation; allow to cool prior to handling
them.
q) NEVER use your hands to remove sawdust, chips or waste close by
the bit.
r) If you are interrupted when operating the drill, complete the process
and switch off before looking up.
s) Where possible, use clamps or a vice to hold your work.
t) ALWAYS disconnect the hammer drill from the electric supply before
changing a drill bit.
u) Examine the chuck regularly for signs of wear or damage.
Have damaged parts repaired by a qualified service centre.
v) ALWAYS wait until the drill has come to a complete stop before
putting it down.
w) On completion of the work, disconnect the tool from the power source
and remove bit from the machine.
x) Periodically check all nuts, bolts and other fixings and tighten where
necessary.
Battery and Charger Safety
Use the battery charger correctly
• Refer to the section of this manual relating to use of the battery charger
before attempting to charge the battery.
• DO NOT attempt to use the charger with any batteries other than those
supplied. Keep your battery charger clean; foreign objects or dirt may
cause a short or block air vents. Failure to follow these instructions may
cause overheating or fire
• If the supply cord is damaged, it must be replaced by the manufacturer, the
service agent or similarly qualified persons in order to avoid a hazard
• Examine the battery charger regularly for damage, especially the cord, plug
and enclosure. If the battery charger is damaged, it must not be used until
it has been repaired
• Children should be supervised to ensure that they do not play with the
appliance
WARNING: DO NOT attempt to recharge non-rechargeable batteries.
Battery and charger safety features
• The battery and charger are fitted with a number of safety features which
may be triggered during charging or operation:
• Over-charge protection: Charger automatically switches off when
the battery has reached full charge capacity, protecting the internal
components of the battery
• Over-discharge protection: Prevents the battery from discharging beyond
the recommended lowest safety voltage
• Over-heat protection: Sensor switches off if the battery becomes too
hot during operation. This can happen if the tool is overloaded or being
used for extended periods of time. Up to 30 minutes cooling time may be
required depending on the ambient temperature
• Overload protection: Battery temporarily stops if it is overloaded or the
maximum current draw is exceeded, protecting the internal components.
The battery will resume normal operation when the current draw returns to
a normal safe level. This may take a few seconds
• Short circuit protection: The battery will stop working immediately if a
short circuit occurs, this prevents damage to the battery or tool
Use batteries correctly
• Only charge batteries using the charger provided. Only use batteries
provided with this power tool, or others recommended by the supplier.
Keep batteries clean; foreign objects or dirt may cause a short. Allow
batteries to cool for 15 minutes after charging or heavy use. Failure to
follow these instructions may cause overheating or fire.
WARNING: Li-Ion batteries, if incorrectly used, stored or charged are a
fire, burn and explosion hazard.
144696_Z1MANPRO1.indd 6 07/07/2015 12:46

7
• Keep the battery out of reach of children
• Only charge Li-Ion batteries using the charger provided or designed
specifically for your product
• Only use Li-Ion batteries provided with a product or specifically designed to
be compatible
• Allow batteries to cool for 15 minutes after charging or heavy use. Failure
to follow these instructions may cause overheating or fire
• When not in use batteries should be stored at room temperature
(approximately 20˚C)
• Ensure that battery contacts cannot accidentally short in storage. Keep
batteries clean; foreign objects or dirt may cause a short. Keep away from
other metal objects, for example paperclips, coins, keys, nails and screws
• Under abusive conditions, liquid may be ejected from the battery. This
liquid may cause skin irritation or burns. Avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, seek medical
help
• Do not open, disassemble, crush, heat above 60°C or incinerate. Do not
dispose of in fire or similar
Product Familiarisation
1. Keyless Chuck
2. Torque Adjustment Collar
3. Mode Selector
4. Gear Selector
5. Forward/Reverse Switch
6. Speed Control Trigger Switch
7. Hand grip
8. Charge Indicator (not visible)
9. Battery
10. Battery Release
11. Belt Clip
12. Green LED
13. Red LED
14. Battery Charger
15. Work Light LED
Accessories (not shown):
• Soft carry case
Note: This manual may be supplied with different package configurations and
supplied accessories may vary.
Intended Use
• Battery-operated drill with screwdriver, drill and hammer drill functions
suitable for medium duty drilling and driving tasks
Unpacking Your Tool
• Carefully unpack and inspect your tool. Fully familiarise yourself with all its
features and functions
• Ensure that all parts of the tool are present and in good condition. If any
parts are missing or damaged, have such parts replaced before attempting
to use this tool
Before Use
Removing a battery
• To remove the Battery (9) from the drill, press the Battery Release (10),
then slide the Battery off the Hand Grip (7)
WARNING: DO NOT try to remove the Battery without pressing the Battery
Release button. The drill or Battery could be damaged.
Fitting a battery
1. To fit a charged battery, slide it on to the Hand Grip (7) of the drill until it
clicks and locks into position
Note: Make sure the Battery and drill are lined up correctly. If the Battery does
not slide into the drill easily, don’t force it. Instead, slide the Battery out of the drill
again, check the top of Battery and the drill battery slot are clean and undamaged
and that the contacts are not bent.
Setting up the battery charger
1. Insert the PSU DC Plug (14) into the Charger DC Socket (16)
2. If fitted, remove any existing battery from the Battery Charger (15)
3. Insert the Charger PSU (13)into a suitable mains socket
Note: The Green LED (17) on the Battery Charger will flash to indicate that the
charger is ready to charge the battery.
WARNING: Use this charger ONLY to charge the supplied battery or additional
purchased batteries that are specifically designed for this tool.
WARNING: The charger is designed for indoor use only, and MUST NOT be used
in damp or wet conditions.
Charging the battery
WARNING: Failure to follow the correct procedure when charging batteries will
result in permanent damage.
1. Slide the Battery Charger (15) onto a fully or partially discharged Battery
Note: Make sure the Battery and Battery Charger are lined up correctly. If the
Battery does not slide on to the Battery Charger easily, don’t force it. Instead,
remove the Battery, check the top of Battery and the Battery Charger slot are
clean and undamaged and that the contacts are not bent.
2. Once charging commences, the Red LED (18) will illuminate
3. When the Battery is fully charged, the Green LED (17) will be illuminated
Battery Charge Level: The battery has a built-in Charge Indicator (8) (Fig. I).
Pressing on the button to the right will indicate the charge level. The right LED
indicates a high charge level and the left a low charge level that will mean the
battery pack will require charging soon.
IMPORTANT: When a low charge level is indicated, the tool may stop operating
while in use. In some instances this may be dangerous. Always ensure the battery
pack has a good charge level.
Notes about battery charging:
• The battery should be charged at ambient temperatures between 10 and
40°C (ideally around 20°C)
• After charging, allow 15 minutes for the battery to cool before use
• Ensure that the charger is disconnected from the mains supply after use, and
is stored correctly
• DO NOT leave batteries on charge for extended periods and NEVER store
batteries on charge
• The Battery Charger monitors battery temperature and voltage while charging.
Remove the Battery once charging has been completed to maximise charge
cycles of the battery and not waste power
• Batteries can become faulty over time, individual cells in the battery can fail
and the battery could short. The charger will not charge faulty batteries. Use
another battery, if possible, to check correct functionality of the charger and
purchase a replacement battery if a faulty battery is indicated
• DO NOT store Lithium-Ion battery packs in a discharged state long term. This
can damage the Lithium-Ion cells. For long-term storage, store batteries in a
high charge state disconnected from the power tool
• The capacity of batteries will reduce over time. After 100 charge cycles, the
battery’s operation time and the maximum torque performance of the drill
will slightly reduce. This decline will continue until the battery has minimal
capacity after 500 charge cycles. This is normal and not a fault with the
battery pack
Fitting a drill or driver bit
WARNING: DO NOT fit any attachment with a maximum speed lower than the no
load speed of the machine.
1. Rotate the Keyless Chuck (1) collar clockwise and insert the bit into the chuck
2. Rotate the Keyless Chuck collar anti-clockwise to secure the drill bit
144696_Z1MANPRO1.indd 7 07/07/2015 12:46

8
Note: DO NOT run the tool whilst tightening or releasing the chuck. Ideally
select the locked middle position of the Forward/Reverse Switch (5).
3. When the bit is held tightly, test that it is positioned centrally by running the
tool. The bit should rotate smoothly without uneven rotation. If the bit is not
central, release the chuck, reposition the bit and retighten the chuck
Direction control
• The rotation direction can be set using the Forward/Reverse Switch (4)
• To let the chuck rotate clockwise, push the Forward/Reverse Switch to the
left
• To let the chuck rotate anti-clockwise, push the Forward/Reverse Switch to
the right
• When the Forward/Reverse Switch is in the central position, the tool is
locked
WARNING: DO NOT attempt to move the Forward/Reverse Switch when the
tool is running
Speed control
• This drill driver features a 2-speed gearbox:
- 1st gear range: 0 – 450min-1
- 2nd gear range: 0 – 1600min-1
• Use the Gear Selector (4) to set the gear: forward for first gear, back for
second gear
Note: The first gear would be used normally for driving screws, for example,
and offers higher torque and superior control at low rpm. The second gear
would normally be used exclusively for drilling.
Torque control
• This drill driver is fitted with torque control, which limits the torque output
of the drill, enabling screws to be driven without the risk of damage
• There are 16 torque settings and two drill settings. The lower the number,
the lower the torque
• To adjust the torque, select the first gear and rotate the Torque
Adjustment Collar (2) until the setting you require is aligned with the
arrow on the impact drill housing
• Check that the torque setting is correct by practising first on a piece of
scrap material
Mode selection
• For drilling, select the correct gear, then rotate the Mode Selector (3) to
the drill symbol. This will lock the tool for maximum torque
• For screwdriving, select the correct gear, then rotate the Mode Selector to
the screw symbol. This will activate the torque clutch
• For masonry drilling, select the correct gear, then rotate the Mode Selector
to the hammer symbol. This will lock the tool for maximum torque and
activate hammer drill function
WARNING: The drill can be fitted with a drive adaptor for use with driving
nuts and bolts. Do not attempt to use this tool in the drill position when doing
so. Use the 16 torque settings and the first gear to allow the torque clutch to
protect the tool from excessive load. The use of a spanner to loosen or tighten
a nut/bolt is recommended. This allows the tool to speed up the operation,
without risk of damage, when high torque is required at the beginning or end
of the operation.
Operation
WARNING: Always use adequate protective equipment, including eye
protection, respiratory and hearing protection, when working with this tool.
Switching on and off
• To start the tool, squeeze the Speed Control Trigger Switch (6).
The Work Light LED (12) will illuminate
• Further pressure on the Speed Control Trigger Switch will increase the
running speed of the tool
• Release the Speed Control Trigger Switch to stop the tool
Note: It is possible the drill may switch off during heavy use due to thermal
protection of the battery and internal components. This may prevent the tool
being used again for a short period of time and does not represent a fault
condition.
Drilling guidance
• Use sharp drill bits and ensure that drill bits are suitable for the material
being drilled
• Never exceed the maximum drilling capacities listed in ‘Specification’
• Begin drilling at slow speeds by partially squeezing the Speed Control
Trigger Switch
• Reduce pressure on the Speed Control Trigger Switch when the drill bit is
about to break through to the other side of material
• To avoid splintering on breakthrough, either clamp a piece of scrap wood to
the back of the workpiece or continue the hole from the back of the wood
when the drill bit first breaks through
Drilling metal
• Support thin material with a piece of scrap wood
• Mark the intended hole position using a hammer and centre punch
• Use only HSS (high speed steel) drill bits or others recommended for
drilling into metal
• Prior to drilling large holes, use a smaller bit to drill a pilot hole
• Use a suitable coolant/lubricant to prolong the service life of the drill bit,
and produce good results
Drilling masonry
• ‘Hammer drill mode’ should be used for drilling into masonry and concrete
• Always use a masonry drill bit, preferably a TCT masonry bit, when drilling
into walls, stone or concrete
• DO NOT apply too much pressure to the back of the tool. If debris blocks
the drill hole, run the drill slowly and remove the bit from the hole. Repeat
until the hole is clear of debris and continue
Accessories
• A range of accessories, including including additional batteries as well as
drill and screwdriver bits, is available from your Triton dealer. Spare parts
can be purchased from your Triton dealer or online at
www.toolsparesonline.com
Maintenance
• This tool is manufactured using class leading components and makes
use of the latest in intelligent circuitry that protects the tool and its
components. In normal use it should provide a long working life
Cleaning
• Keep your machine clean at all times. Dirt and dust will cause internal parts
to wear quickly, and shorten the machine’s service life. Clean the body of
your machine with a soft brush or dry cloth. If available, use clean, dry,
compressed air to blow through the ventilation holes
Storage
• Store this tool and its accessories after use in its case, in a dry, secure
place out of the reach of children
Disposal
Always adhere to national regulations when disposing of power tools that are
no longer functional and are not viable for repair.
• Do not dispose of power tools, batteries or other waste electrical and
electronic equipment (WEEE), with household waste
• Contact your local waste disposal authority for information on the correct
way to dispose of power tools and batteries
144696_Z1MANPRO1.indd 8 07/07/2015 12:46

9
Troubleshooting
Problem Possible cause Solution
Red charging LED does not illuminate and battery
not charging
Battery not correctly inserted Clean battery socket of charger
Charger not powered Recheck mains connection
Battery pack has low capacity
Battery not being fully charged Charge the battery until the charger indicates a
full charge
Battery pack has been charged over 100 times and
capacity has started to reduce
This is normal for battery packs. Contact your Triton
dealer to purchase a replacement battery pack
Drill cannot be switched on Speed Control Trigger
Switch (5) does not move)
The Forward/Reverse Switch (5) may be in the
middle (‘locked’) position
Slide the Forward/Reverse Switch either to the
left or right
Drill does not start when Speed Control Trigger
Switch (5) is depressed
Battery completely discharged Recharge battery or replace with a fully charged
battery
Defective battery Replace battery
Machine defective Contact your Triton dealer or authorised service
centre
Screws do not reach deep enough into the
workpiece
Not enough torque; torque clutch setting too low Choose a higher torque setting
Low battery voltage Recharge battery or replace with a fully charged
battery
Screws are driven too deep into the workpiece
surface Too much torque; torque clutch setting too high Choose a lower torque setting
During masonry drilling the drill bit does not
penetrate the wall
Unsuitable or blunt drill bit Replace drill bit with a new high quality masonry
drill bit
Drill bit too large See ‘Specification’ for maximum drilling capacities
Drill not set to hammer mode Rotate mode selector to switch the machine into
hammer drill mode (see ‘Mode Selection’)
Guarantee
To register your guarantee visit our web site at
www.tritontools.com* and enter your details.
Your details will be included on our mailing list (unless indicated
otherwise) for information on future releases. Details provided will not
be made available to any third party.
Purchase Record
Date of Purchase: ___ / ___ / ____
Model: XT18CD2BS
Serial Number:
(located on tool housing)
Retain your receipt as proof of purchase a
Triton Precision Power Tools guarantees to the purchaser of this
product that if any part proves to be defective due to faulty materials or
workmanship within 3 YEARS from the date of original purchase,
Triton will repair, or at its discretion replace, the faulty part free of
charge.
This guarantee does not apply to commercial use nor does it extend to
normal wear and tear or damage as a result of accident, abuse or misuse.
* Register online within 30 days.
Terms & conditions apply.
This does not affect your statutory rights oves to be defecti
Warranty
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure
and for compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to
be of acceptable quality and the failure does not amount to a major failure.
This product is covered by a 36 month warranty.
This warranty will not apply:
(i) where this product has been subjected to misuse, abuse, accident or want
of care;
(ii) where this product has been used for a purpose for which it was not
designed or is not suited;
(iii) where the service of this product has been undertaken by a non-
authorised person or company or if non-approved parts have been used;
(iv) where this product has been used for industrial purposes.
Should service become necessary during the warranty period, the purchaser
should contact an Authorised Service Centre or White International. In order to
obtain warranty service, the purchaser must present the store receipt showing
the name of the retailer and the date of purchase.
The period of the warranty begins from the original date of purchase,
notwithstanding any subsequent repair or parts replacement.
Purchaser shall be responsible for all transport charges to and from the
Authorised Service Centre.
Damage in transit is not covered by this warranty. The purchaser should
remove from the product any liquids (if applicable) before sending the tool for
service or repair. The tool should be packed securely to prevent damage.
Warranty exclusions
Wear parts or service related parts required when performing normal and
regular maintenance of this product are not covered by warranty unless it is
found to be defective by an Authorised Service Centre. These include, but are
not limited to: Blades
Distributed in Australia by White International.
PO Box 304 Milperra LPO, NSW Australia, 2214
Ph:1800 251 338
The White International Policy is one of continuous improvement and the
company reserves the right to alter designs, colours and specifications without
notice.
144696_Z1MANPRO1.indd 9 07/07/2015 12:46

10
Notes
144696_Z1MANPRO1.indd 10 07/07/2015 12:46

11
Notes
144696_Z1MANPRO1.indd 11 07/07/2015 12:46

144696_Z1MANPRO1.indd 2 07/07/2015 12:46
