Triumph Adler LP 4118 User manual

Instruction Handbook
LP 4118
Laser Printer b/w

OPERATION GUIDE i
Contents
1 Machine Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Key Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Loading Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Paper Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Prepare the Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Loading Paper into a Cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Manual Feed Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting to Parallel Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting to USB Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Connecting to Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 Loading Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5 Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Printing a Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Manual Duplex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Toner Container . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Cleaning the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Prolonged Non-Use and Moving the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
General Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Print Quality Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Paper Jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
8 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
9 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

ii OPERATION GUIDE

OPERATION GUIDE iii
Legal and Safety
Information
FCC statement (for users in the United States)
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
• This device may not cause harmful interference
• This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the manufacturer for
compliance could void the user’s authority to operate the equipment.
Shielded circular cable should be used for interfacing with the computer.
Precautions for Use
Any modification without prior permission may cause harmful interference.
If any modification/change is introduced to this equipment without prior
permission, the manufacturer cannot guarantee compliance with FCC
rules. To use equipment which does not comply with FCC rules is
prohibited.

Legal and Safety Information
iv OPERATION GUIDE
Interface connectors
IMPORTANT: Ensure the printer is powered off before connecting or
disconnecting an interface cable to the printer.
IMPORTANT: For protection against static discharge which may be
applied to the printer's internal electronics through the interface
connector(s), keep any interface connector which is not in use capped
using the protective cap supplied.
NOTE: Use shielded interface cable.
Safety information
Laser safety
This printer is certified as a Class 1 laser product under the U.S.
Department of Health and Human Services (DHHS) Radiation
Performance Standard according to Radiation Control for Health and
Safety Act of 1968. This means that the printer does not produce
hazardous laser radiation. Since radiation emitted inside the printer is
completely confined within protective housings and external covers, the
laser beam cannot escape from the printer during any phase of user
operation.
Laser notice
This printer is certified in the U.S. to conform to the requirements of DHHS
21 CFR, Chapter I, Subchapter for Class I (1) laser products, and
elsewhere is certified as a Class I laser product conforming to the
requirements of IEC 825.
DANGER: CLASS 3B INVISIBLE LASER RADIATION WHEN
OPEN. AVOID DIRECT EXPOSURE TO BEAM.
CAUTION: Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous radiation
exposure.

Legal and Safety Information
OPERATION GUIDE v
Caution Labels
CDRH Regulations
The Center for Devices and Radiological Health (CDRH) of the U.S. Food
and Drug Administration implemented regulations for laser products on
August 2, 1976. These regulations apply to laser products manufactured
after August 1, 1976. Compliance is mandatory for products marketed in
the United States. A label indicating compliance with the CDRH regulations
must be attached to laser products marketed in the United States.
NOTE: Do not remove these labels.
Label inside the printer
(Laser radiation warning)
Label on the printer’s rear panel
European/
Asian/Pacific
countries
U.S.A./Canada
Label inside the rear

Legal and Safety Information
vi OPERATION GUIDE
Ozone Concentration
The printers generate ozone gas (O3) which may concentrate in the place
of installation and cause an unpleasant smell. To minimize concentration
of ozone gas to less than 0.1 ppm, we recommend the printer is not located
in a confined area where ventilation may be blocked.
IMPORTANT SAFEGUARDS
1Read all of these instructions and save these instructions for later
use.
2Unplug this product from the wall outlet before cleaning.
3Do not use this product near water.
4Do not place this product on an unstable cart, stand, or table. The
product may fall, causing serious damage to the product.
5Slots and openings in the cabinet and the back are provided for
ventilation to ensure reliable operation of the product and to protect it
from overheating, these openings must not be blocked or covered.
The openings should never be blocked by placing the product on a
bed, sofa, rug, or other similar surface. This product should never be
placed near or over a radiator or heat register. This product should
not be placed in a built-in installation unless proper ventilation is
provided.
6This product is equipped with a 3-wire grounding type plug, a plug
having a third (grounding) pin. This plug will only fit into a grounding-
type power outlet. This is a safety feature. If you are unable to insert
the plug into the outlet, contact your electrician to replace your
obsolete outlet. Do not defeat the purpose of the grounding-type
plug.
7Do not allow anything to rest on the power cord. Do not locate this
product where persons will walk on the cord.
8If an extension cord is used with this product, make sure that the total
of the ampere ratings on the products plugged into the extension
cord do not exceed the extension cord ampere rating.
9Never push objects of any kind into this product through cabinet slots
as they may touch dangerous voltage points or short out parts that
could result in a risk of fire or electric shock. Never spill liquid of any
kind on the product.
10 Except as explained elsewhere in the Operation Guide, do not
attempt to service this product yourself. Removing covers may
expose you to dangerous voltage points or other risks. Refer all
servicing in those compartments to a service technician.
11 Unplug this product from the wall outlet and refer servicing to a
qualified service technician under the following conditions:
- When the power cord or plug is damaged or frayed.
- If liquid has been spilled into the product.
- If the product has been exposed to rain or water.

Legal and Safety Information
OPERATION GUIDE vii
- If the product does not operate normally when the operating
instructions are followed. Adjust only those controls that are
covered by the operating instructions since improper adjustment
of other controls may result in damage and will often require
extensive work by a qualified technician to restore the product to
normal operation.
- If the product has been dropped or the cabinet has been damaged.
Canadian Department of Communications compliance statement
This Class B digital apparatus complies with Canadian ICES-003.
Avis de conformitè aux normes du ministère des
Communications du Canada
Cet appareil numèrique de à la classe B est conforme à la norme NMB-003
du Canada.
ISO 7779
Maschinenlärminformationsverordnung 3. GSGV, 18.01.1991: Der
höchste Schalldruckpegel beträgt 70 dB(A) oder weniger gemäß ISO
7779.
CE Marking Directive
According to Council Directive 89/336/EEC and 73/23/EEC
Manufacturer’s name:UTAX GmbH
Manufacturer’s address: Ohechaussee 235,
22848 Norderstedt, Germany
Declares that the product:
Product name: Page Printer
Model number: TA Triumph-Adler LP 4118
Conforms to the following product specifications:
- EN 55 022:1998 Class B
- EN 61 000-3-2:2000
- EN 61 000-3-3:1995+A1:2001
- EN 55 024:1998
- EN 60 950:2000
- EN 60 825-1:1994+A1+A2

Legal and Safety Information
viii OPERATION GUIDE
The manufacturer and its merchandising companies retain the following
technical documentation in anticipation of the inspection that may be
conducted by the authorities concerned.
- User’s instruction that conforms to the applicable specifications.
- Technical drawings.
- Descriptions of the procedures that guarantee the conformity.
- Other technical information.

Legal and Safety Information
OPERATION GUIDE ix

Legal and Safety Information
xOPERATION GUIDE
Energy Star Program
As an ENERGY STAR Partner, we have determined that this product
meets the ENERGY STAR guidelines for energy efficiency.
The basic objective of the ENERGY STAR Program is to reduce
environmental pollution by encouraging the manufacture and sale of
equipment that uses energy more efficiently.
This printer is equipped with a sleep timer function that conforms with the
standards of the ENERGY STAR Program. This function makes it possible
to reduce the amount of electrical power consumed by the printer. For
maximum power savings, turn off the printer's power supply when not
using the printer for extended periods of time.
For details on the sleep timer function and printer power consumption,
refer to the CD-ROM instruction manual provided with the printer.
( ): ENERGY STAR program guideline
Group for Energy Efficient Appliances (GEEA)
The goal of GEEA is efficient use of energy. This product has a high-
efficiency profile and meets the criteria for receiving the GEEA-Label.
( ): GEEA criteria
Regarding Trade Names
KPDL and KIR (Kyocera Image Refinement) are trademarks of Kyocera
Corporation. Hewlett-Packard, PCL, and PJL are registered trademarks of
Hewlett-Packard Company. Centronics is a trade name of Centronics Data
Computer Corp. PostScript is a registered trademark of Adobe Systems
Incorporated. Adobe and Acrobat are trademarks of Adobe Systems
Incorporated. ENERGY STAR is a U.S. registered mark. All other brand
and product names are registered trademarks or trademarks of their
respective companies.
Initial Sleep Mode Setting Power Consumption in Sleep Mode
5 minutes (15 minutes) 4.8W (20W) [220 to 240V, 50Hz/60Hz]
4.4W (20W) [120V, 60Hz]
Initial Sleep Mode Setting Power Consumption in Sleep Mode
5 minutes (15 minutes) 4.8W (10W) [220 to 240V, 50Hz/60Hz]
4.4W (10W) [120V, 60Hz]

Legal and Safety Information
OPERATION GUIDE xi
This product uses PeerlessPrintXL to provide the HP LaserJet compatible
PCL 6 language emulation. PeerlessPrintXL is a trademark of The
Peerless Group, Redondo Beach, CA 90278, U.S.A.
This product was developed using the Tornado™Real Time Operating
System and Tools from Wind River Systems.
This product contains UFST™and MicroType®fonts from Agfa MonoType
Corporation.
Agfa Monotype License Agreement
1"Software" shall mean the digitally encoded, machine readable,
scalable outline data as encoded in a special format as well as the
UFST Software.
2You agree to accept a non-exclusive license to use the Software to
reproduce and display weights, styles and versions of letters,
numerals, characters and symbols ("Typefaces") solely for your own
customary business or personal purposes at the address stated on
the registration card you return to Agfa Japan. Under the terms of
this License Agreement, you have the right to use the Fonts on up to
three printers. If you need to have access to the fonts on more than
three printers, you need to acquire a multi-user license agreement
which can be obtained from Agfa Japan. Agfa Japan retains all
rights, title and interest to the Software and Typefaces and no rights
are granted to you other than a License to use the Software on the
terms expressly set forth in this Agreement.
3To protect proprietary rights of Agfa Japan, you agree to maintain the
Software and other proprietary information concerning the Typefaces
in strict confidence and to establish reasonable procedures
regulating access to and use of the Software and Typefaces.
4You agree not to duplicate or copy the Software or Typefaces, except
that you may make one backup copy. You agree that any such copy
shall contain the same proprietary notices as those appearing on the
original.
5This License shall continue until the last use of the Software and
Typefaces, unless sooner terminated. This License may be
terminated by Agfa Japan if you fail to comply with the terms of this
License and such failure is not remedied within thirty (30) days after
notice from Agfa Japan. When this License expires or is terminated,
you shall either return to Agfa Japan or destroy all copies of the
Software and Typefaces and documentation as requested.
6You agree that you will not modify, alter, disassemble, decrypt,
reverse engineer or decompile the Software.

Legal and Safety Information
xii OPERATION GUIDE
7Agfa Japan warrants that for ninety (90) days after delivery, the
Software will perform in accordance with Agfa Japan-published
specifications, and the diskette will be free from defects in material
and workmanship. Agfa Japan does not warrant that the Software is
free from all bugs, errors and omissions.
THE PARTIES AGREE THAT ALL OTHER WARRANTIES,
EXPRESSED OR IMPLIED, INCLUDING WARRANTIES OF
FITNESS FOR A PARTICULAR PURPOSE AND
MERCHANTABILITY, ARE EXCLUDED.
8Your exclusive remedy and the sole liability of Agfa Japan in
connection with the Software and Typefaces is repair or replacement
of defective parts, upon their return to Agfa Japan.
IN NO EVENT WILL AGFA JAPAN BE LIABLE FOR LOST
PROFITS, LOST DATA, OR ANY OTHER INCIDENTAL OR
CONSEQUENTIAL DAMAGES, OR ANY DAMAGES CAUSED BY
ABUSE OR MISAPPLICATION OF THE SOFTWARE AND
TYPEFACES.
9New York, U.S.A. law governs this Agreement.
10 You shall not sublicense, sell, lease, or otherwise transfer the
Software and/or Typefaces without the prior written consent of Agfa
Japan.
11 Use, duplication or disclosure by the Government is subject to
restrictions as set forth in the Rights in Technical Data and Computer
Software clause at FAR 252-227-7013, subdivision (b)(3)(ii) or
subparagraph (c)(1)(ii), as appropriate. Further use, duplication or
disclosure is subject to restrictions applicable to restricted rights
software as set forth in FAR 52.227-19 (c)(2).
12 YOU ACKNOWLEDGE THAT YOU HAVE READ THIS
AGREEMENT, UNDERSTAND IT, AND AGREE TO BE BOUND BY
ITS TERMS AND CONDITIONS. NEITHER PARTY SHALL BE
BOUND BY ANY STATEMENT OR REPRESENTATION NOT
CONTAINED IN THIS AGREEMENT. NO CHANGE IN THIS
AGREEMENT IS EFFECTIVE UNLESS WRITTEN AND SIGNED
BY PROPERLY AUTHORIZED REPRESENTATIVES OF EACH
PARTY. BY OPENING THIS DISKETTE PACKAGE, YOU AGREE
TO ACCEPT THE TERMS AND CONDITIONS OF THIS
AGREEMENT.

Legal and Safety Information
OPERATION GUIDE xiii
IBM PROGRAM LICENSE AGREEMENT
THE DEVICE YOU HAVE PURCHASED CONTAINS ONE OR MORE
SOFTWARE PROGRAMS ("PROGRAMS") WHICH BELONG TO
INTERNATIONAL BUSINESS MACHINES CORPORATION ("IBM").
THIS DOCUMENT DEFINES THE TERMS AND CONDITIONS UNDER
WHICH THE SOFTWARE IS BEING LICENSED TO YOU BY IBM. IF YOU
DO NOT AGREE WITH THE TERMS AND CONDITIONS OF THIS
LICENSE, THEN WITHIN 14 DAYS AFTER YOUR ACQUISITION OF
THE DEVICE YOU MAY RETURN THE DEVICE FOR A FULL REFUND.
IF YOU DO NOT SO RETURN THE DEVICE WITHIN THE 14 DAYS,
THEN YOU WILL BE ASSUMED TO HAVE AGREED TO THESE TERMS
AND CONDITIONS.
The Programs are licensed not sold. IBM, or the applicable IBM country
organization, grants you a license for the Programs only in the country
where you acquired the Programs. You obtain no rights other than those
granted you under this license. The term "Programs" means the original
and all whole or partial copies of it, including modified copies or portions
merged into other programs. IBM retains title to the Programs. IBM owns,
or has licensed from the owner, copyrights in the Programs.
1License
Under this license, you may use the Programs only with the device on
which they are installed and transfer possession of the Programs and the
device to another party. If you transfer the Programs, you must transfer a
copy of this license and any other documentation to the other party. Your
license is then terminated. The other party agrees to these terms and
conditions by its first use of the Program.
You may not:
- use, copy, modify, merge, or transfer copies of the Program except
as provided in this license;
- reverse assemble or reverse compile the Program; or
- sublicense, rent, lease, or assign the Program.
2Limited Warranty
The Programs are provided "AS IS."
THERE ARE NO OTHER WARRANTIES COVERING THE PROGRAMS
(OR CONDITIONS), EXPRESS OR IMPLIED, INCLUDING, BUT NOT
LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE.
Some jurisdictions do not allow the exclusion of implied warranties, so the
above exclusion may not apply to you.
SUPPLEMENT TO AGREEMENT FOR SOFTWARE BUNDLING AND
DISTRIBUTION FOR ALDC.

Legal and Safety Information
xiv OPERATION GUIDE
3Limitation of Remedies
IBM’s entire liability under this license is the following;
• For any claim (including fundamental breach), in any form, related in
any way to this license, IBM's liability will be for actual damages only
and will be limited to the greater of:
- the equivalent of U.S.$25,000 in your local currency; or
- IBM's then generally available license fee for the Program
This limitation will not apply to claims for bodily injury or damages to real
or tangible personal property for which IBM is legally liable. IBM will not be
liable for any lost profits, lost savings, or any incidental damages or other
economic consequential damages, even if IBM, or its authorized supplier,
has been advised of the possibility of such damages. IBM will not be liable
for any damages claimed by you based on any third party claim. This
limitation of remedies also applies to any developer of Programs supplied
to IBM. IBM's and the developer's limitations of remedies are not
cumulative. Such developer is an intended beneficiary of this Section.
Some jurisdictions do not allow these limitations or exclusions, so they may
not apply to you.
4General
You may terminate your license at any time. IBM may terminate your
license if you fail to comply with the terms and conditions of this license. In
either event, you must destroy all your copies of the Program. You are
responsible for payment of any taxes, including personal property taxes,
resulting from this license. Neither party may bring an action, regardless of
form, more than two years after the cause of action arose. If you acquired
the Program in the United States, this license is governed by the laws of
the State of New York. If you acquired the Program in Canada, this license
is governed by the laws of the Province of Ontario. Otherwise, this license
is governed by the laws of the country in which you acquired the Program.

OPERATION GUIDE 1
1 Machine Overview
Top Cover
Output Tray
Manual Feed Tray
Power Switch
Parallel Interface USB InterfacePaper Cassette
Rear Cover
Indicators
Power Cord
Paper Stopper
Cancel KeyGo Key

Machine Overview
2OPERATION GUIDE
Indicators
There are two indicators located on the top right of the printer. The
indicators are used to identify the status of the printer at any time. To
identify the printer status, check the indicators on the printer and then refer
to the table below.
NOTE: For other combinations of the two indicators, call for service.
KM-NET for Clients (a software included in the CD-ROM) will provide
more detailed information about the printer status.
Key Status
Indicator Action
Ready Indicator (green)
Lit
Fast
Flashing
Slow
Flashing Off
Very Slow
Flashing
Any
Indicator
Attention
Indicator
(red)
Lit XXX
Cover Open,
Toner Container
Empty, Developer
Unit or
Drum Unit missing
XX
Fast
Flashing XWarm Up XPaper Jam or
Waiting for Jam
Reset XX
Slow
Flashing XXX
Paper empty or
Paper Cassette is
not installed
(during printing)
XToner Low,
Add Paper
(during ready)
Off On-line / Ready Off-line Data Processing Power is Off Sleeping X
Key Status Operation Function
Go At Ready Press momentarily Switches On-line / Off-line
Press for 3 to 10 seconds Prints the status page
Press for 10 seconds or more Prints the service status page
At Error Press momentarily Clears the error
After Power
On
Press until Ready is lit Resets the toner counter after
replacing the toner container
Cancel Press momentarily Stops the audible alarm
Press for 1 second or more Cancels the data from the PC

OPERATION GUIDE 3
2 Loading Paper
Paper Specifications
The following table summarizes the basic paper specifications:
NOTE: For further information about the sizes and types of media that
can be used, refer to Specifications, on page 31.
Paper Cassette
- 250 sheets (80 g/m2)
- 60 to 105 g/m2
- A4, B5 (JIS), A5, Letter,
Legal, Folio, Oficio II,
Executive, B5 (ISO),
Envelope C5, and 16K
Manual Feed Tray
-1sheet
- 60 to 163 g/m2
- A4, B5 (JIS), A5, Letter,
Legal, Folio, Oficio II,
Statement, Executive, A6, B6, B5
(ISO), Envelope #10, Envelope #9,
Envelope Monarch, Envelope #6,
Envelope C5, Envelope DL and 16K
Item Specification
Weight Cassette: 60 - 105 g/m2(16 to 28 lb/ream)
Manual Feed Tray: 60 - 163 g/m2(16 to 43 lb/ream)
Thickness 0.086 to 0.110mm (3.4 to 4.3 mils)
Dimensional Accuracy ±0.7 mm (±0.0276 inches)
Squareness of Corners 90° ±0.2°
Moisture Content 4% to 6%
Direction of Grain Long grain
Pulp Content 80% or more

Loading Paper
4OPERATION GUIDE
Prepare the Paper
After removing paper from the
packaging, fan through the sheets
to separate them prior to loading.
If using paper that has been
folded or is curled, straighten it
prior to loading. Failure to do so
may result in a paper jam.
IMPORTANT: Ensure paper is not stapled and clips are removed.
Loading Paper into a Cassette
1Pull the cassette completely out of
the printer.
IMPORTANT: When pulling the
cassette out of the printer, ensure
it is supported and does not fall
out.
2Press the release button and
adjust the paper length guide to
the paper size required.
3Adjust the position of the width
guides located on the left and right
sides of the paper cassette. Press
the release button on the left
guide and slide the guides to the
paper size required.
NOTE: The paper sizes are marked on the cassette.
