Triumph 96" User manual

User Manual v 5.0
July 2012
DUAL Touch Series
TRIUMPH BOARD 96” DUAL Touch
TRIUMPH BOARD 89” DUAL Touch
TRIUMPH BOARD 78” DUAL Touch
TRIUMPH BOARD a.s. , Neklanova 122/15, 128 00 Praha 2, Czech Republic, European Union, www.triumphboard.com

DUAL Touch Series
TRIUMPH BOARD a.s. Page 2 of 27
DECLARATION OF CONFORMITY
We TRIUMPH BOARD a.s., Neklanova 122/15, 128 00 Praha 2
Declare under sole responsibility that the product:
TRIUMPH BOARD DUAL Touch Series
Model: 89” DUAL Touch / 78” DUAL Touch
EAN: 8592580101144, 8592580101168, 8592580101151, 8592580101175,
Is in conformity of essential requirements of EU/CZ directives:
Czech Standards
EU Standards
ČSN ETSI EN 301 489-1 V1.8.1:2008
ČSN ETSI EN 301 489-3 V1.4.1:2003
ČSN ETSI EN 300 440-1 V1.4.1:2009
ČSN ETSI EN 300 440-2 V1.2.1:2009
ČSN EN 50371:2002
ČSN EN 60950-1 ed. 2:2006
EN 301 489-1 V1.8.1:2008
EN 301 489-3 V1.4.1:2002
EN 300 440-1 V1.4.1:2008
EN 300 440-2 V1.2.1:2008
EN 50371:2002
EN 60950-1:2006
and following Governmental regulations, as amended:
Government Regulation No. 17/2003 Coll. as amended (2006/95/EC including amendments)
Government Regulation No. 616/2006 Coll. as amended (including amendments 2004/108/EC)
The last two digits of the year in which the CE marking was affixed: 11
Place of Issue: Praha
Datum of issue: 15th June of 2011
Ing. Ondřej Kryšpín, Chairman of the Board of Directors
Note: Translation from original CE

DUAL Touch Series
TRIUMPH BOARD a.s. Page 3 of 27
DECLARATION OF CONFORMITY
We TRIUMPH BOARD a.s., Neklanova 122/15, 128 00 Praha 2
Declare under sole responsibility that the product:
TRIUMPH BOARD DUAL Touch Series
Model: 96” DUAL Touch
EAN: 8592580091377
Is in conformity of essential requirements of EU/CZ directives:
Czech Standards
EU Standards
ČSN ETSI EN 301 489-1 V1.8.1:2008
ČSN ETSI EN 301 489-3 V1.4.1:2003
ČSN ETSI EN 300 440-1 V1.4.1:2009
ČSN ETSI EN 300 440-2 V1.2.1:2009
ČSN EN 50371:2002
ČSN EN 60950-1 ed. 2:2006
EN 301 489-1 V1.8.1:2008
EN 301 489-3 V1.4.1:2002
EN 300 440-1 V1.4.1:2008
EN 300 440-2 V1.2.1:2008
EN 50371:2002
EN 60950-1:2006
and following Governmental regulations, as amended:
Government Regulation No. 17/2003 Coll. as amended (2006/95/EC including amendments)
Government Regulation No. 616/2006 Coll. as amended (including amendments 2004/108/EC)
The last two digits of the year in which the CE marking was affixed: 11
Place of Issue: Praha
Datum of issue: 10th July of 2012
Ing. Ondřej Kryšpín, Chairman of the Board of Directors
Note: Translation from original CE

DUAL Touch Series
TRIUMPH BOARD a.s. Page 4 of 27
Content
Declaration of Conformity
1. Safety Information ………………………………………………………………….5
2. Product description ………………………………………………………………….9
3. Technical specification ………………………………………………………….....10
4. Package content ……………………………………………………………………13
5. Wall Mount installation ……………………………………………………………..14
6. Software Installation ……………………………………………………………….18
7. Hardware Installation ………………………………………………………………19
a. Connection
b. Configuration
c. Wireless setting
d. Calibration
e. User profile
f. Hotkey setting
g. Settings
h. Language
i. Auto Run
8. MS Office Annotations …………………………………………………………….26
9. Warranty Service and Contact ……………………………………………………27

DUAL Touch Series
TRIUMPH BOARD a.s. Page 5 of 27

DUAL Touch Series
TRIUMPH BOARD a.s. Page 6 of 27
1. Safety Information
Please read, understand and follow the information contained in this User Guide before
installation and use this product.
Safety Information
This product was designed, and intended for use indoor via a USB cable or wireless USB receiver connected to a
desktop or laptop computer. Use this product in an outdoor and/or wet environment could damage this product and
create a potentially unsafe operating condition
Meaning of Signal Words
Indicates a potential hazard that could result in serious injury or death and/or
property damage.
Indicates hazards that could result in minor or moderate injury and/or property
damage.
oPlease read, understand and follow all safety information contained in this User Manual before
installation and use this product.
oDo not use this product in an outdoor and/or wet environment.
oDo not use this product near water. Electric shock will result.
oThis product is not intended for use by unsupervised children. Always provide proper adult
supervision when using this product around children.
oAt least two qualified service technicians should perform the installation and removal procedure.
Failure to do so could result in serious personal injury and/or damage from dropping this product.
oBefore installation, take the wall material and wall strength into consideration.
oAlways place this product on a stable and level surface.
oUse only the designated wall mount and mobile stand hardware.
oFollow all installation instructions carefully.
oMake sure the mounting screws are properly sized to handle the weight of this product.
oMake sure the mounting hardware is securely anchored to a solid structure.
oOnly plug the power cord, power plug or power adaptor into an AC power outlet with the proper and

DUAL Touch Series
TRIUMPH BOARD a.s. Page 7 of 27
Safety Information (Continue….)
indicated power supply voltage and is effectively grounded (earthed) through the normal wiring. If
this product is used at a power supply voltage other than the one indicated, it would fail and may
result in fire or electric shock.
oIf the power cord or power plug or power adaptor cannot be plugged into the AC power outlet,
contact a licenses electrician to replace the AC power outlet with a properly grounded (earthed)
one.
oWhen you operate this product, the AC power outlet should be near this product and easily
accessible.
oThe fact that this product operates satisfactorily does not imply that the AC power outlet is grounded
(earthed) and that the installation is completely safe. For your safety, if in any doubt about the
effective grounding (earthling) of the AC power point, consult a qualified electrician.
oDo not defeat the purpose of the grounding (Earthling) plug (for example, do not use a conversion
plug).
oAlways plug the power cord, power plug or power adaptor securely and firmly into an AC power
outlet. Otherwise, overheating will occur, possibly resulting in electric shock or fire.
oDo not pull, bend, rest objects on, or chafe the power cord or power plug or power adaptor. Damage
to the power cord or power plug or power adaptor can cause fire or electric shock.
oDo not attempt to repair the power cord, power plug or power adaptor. If the power cord or power
plug or power adaptor is damaged or frayed, contact an authorized service representative for a
replacement.
oPeriodically clean the power cord or power plug or power adaptor to ensure the connection is free of
dust. In a damp environment, a contaminated connector can draw a significant amount of current
that can generate heat and eventually cause fire if left unattended over an extended period of time.
oNever portable the power cord or power plug or power adaptor with wet hands. Electric shock will
result.
oStop operation immediately if your product emits smoke, excessive heat, abnormal smell or unusual
noise. These conditions can cause fire or electronic shock. Immediately turn your product off and
unplug the power cord or power plug or power adaptor, and contact an authorized service
representative for service.
oWhen disconnecting this product, hold the power plug or the power adaptor instead of the power
cord. Pulling on a power cord forcibly can damage it and cause fire or electric shock.
oTo prevent fire or shock hazard, do not expose this product to rain or any type of moisture.
oIf metal objects or a liquid get into this product, turn this product off and unplug this product
immediately. Contact an authorized service representative for service. Operating the contaminated
product can cause fire or electronic shock.
oNever open or remove unit covers that are screwed with screws. A high-voltage component can
cause electric shock.
oDo not alter this product or modify any parts. Alternation or modification can cause fire or electronic
shock
oBefore cleaning this product, unplug the power cord or power plug or power adaptor. Electric shock
sometimes results.

DUAL Touch Series
TRIUMPH BOARD a.s. Page 8 of 27
Safety Information (Continue….)
oDo not open or alter the casing of this product. Electric shock or injury may result.
oBe careful about the location of the power cord, power plug or power adaptor to avoid it trips someone
or causing this product to fall, etc. It may cause injury or product failure.
oDo not leave this product or any of its accessories on the floor to avoid someone break it when
stepping on it or injured by tripping on it.
oUse only the included power cord or power plug or power adaptor. If other power cord or power plug or
power adaptor is used, fire or electric shock might result.
oDo not operate this product in a location with high temperature or high humidity. This product is suitable
to work under: Temperature: 10℃ to 40℃; Humidity: 10% to 80%; NO condensation.
oUnplug the power cord, power plug or power adaptor from the AC power outlet when:
- The power cord or power supply plug is damaged.
- A liquid is spilled onto this product.
- This product is exposed to rain or water.
- This product becomes malfunctions and/or need repairing.
- This product falls or after its cabinet is damaged.
This product must be disposed in accordance with the relevant federal, state, and local laws and
regulations.
Do not install this product except by qualified service personnel.
Avoid fire and heat source above 100℃.
When this product is not used over an extended period of time, switch it off and unplug the power plug
or power adaptor. If it is unused and is left connected to a power source for a long period, degraded
insulation may cause electronic shock, current leakage or fire.
Do not position this product in a location where it is unstable.
Do not place this product in a hot humid or dusty environment. Prolonged exposure to these adverse
conditions may cause fire or electric shock.
When moving this product, be sure to unplug the power cord, plug or power adaptor from the AC power
outlet. If this product is moved with the power cord or plug or power attached, it can cause damage to
the power cord, plug or power adaptor which could result in fire or electric shock.
After installing or moving this product, lock the casters when it is hanging on a mobile stand.
If this product is fallen down or damaged, turn this product off and unplug the power cord or power plug
or power adaptor. Otherwise, it may cause fire or electric shock.
Do not put drinks, other liquids or heavy items on the tray or screen. Accidental spillage of liquid into
this product may cause severe damage. If this occurs, turn this product off, unplug the power cord or
power plug or power adaptor and contact an authorized service representative for service.

DUAL Touch Series
TRIUMPH BOARD a.s. Page 9 of 27
Do not lean against this product even this product is mounted on the wall.
When this product is not used over an extended period of time, take the batteries out of the electronic
stylus. Otherwise the batteries may leak. Do not use the leaked batteries.
Do not install this product where it may be exposed to direct sunlight, near heating equipment, or near
air-conditioning vents.
Do not install this product in strong sunlight or strong lighting.
Do not install this product in locations where the temperature may change suddenly.
Do not allow writing to remain on the screen for an extended period of time as it will become harder to
erase.
Do not erase with an overly dirty eraser.
Use commercially available whit board cleaner for hard-to-erase stains.
Use only designated markers and erasers. Use of accessories other than those authorized (such as oil-
based markers) may damage the screen or result in hard-to-erase markings.
If you connect the wireless USB receiver to a USB hub, it is not guaranteed to work.
Fasten the screws tightly to avoid the stand or this product fall which may cause injury or damage.
Before installation, take the wall material and wall strength into consideration. For details, please
consult your dealer.

DUAL Touch Series
TRIUMPH BOARD a.s. Page 10 of 27
2) Product Description
TRIUMPH BOARD DUAL Touch is an interactive whiteboard solution which enables two users to write and
draw simultaneously. Four touch inputs enhances this technology - allows two users not only simultaneously
write and draw, but also control two objects (resize, move, rotate) in same time. Truly multi-touch, requiring
no separate multiuser mode setting. Users can write, draw and move objects with a finger, stylus or even a
pointer.
TRIUMPH BOARD DUAL Touch connects to a computer through a fast USB 2.0 interface or optionally with
wireless radio technology with 2,4 GHz, just plug-n-play, makes the lecture more interactively and enhances
the efficiency of the class
TRIUMPH BOARD DUAL Touch supports Linux, Mac, all Microsoft Windows & multiuser writing and common
multi touch gestures currently recognized in Microsoft Win-7. Use simple intuitive finger or hand gestures to
toss, rotate or zoom in/out on objects
TRIUMPH BOARD DUAL Touch is based on IR Cell LED Optical technology which uses a combination of IR
LEDs and photo transistors that are aligned in pairs around the active surface. These pairs of LEDs and photo
transistors cast a grid over this surface. When the surface is touched, the beam of infrared light between the
LEDs and the photo transistors is interrupted at the point of touch. This position is converted into an ‘X’ and a
‘Y’ coordinate which the computer then converts into a mouse position.
TRIUMPH BOARD DUAL Touch interactive whiteboards are used in classrooms at all levels of education, in
corporate board rooms and training rooms, in professional sports coaching, etc. Interactive whiteboards
replace traditional whiteboards, flipcharts and other traditional systems
DUAL Touch 96” DUAL Touch 89” DUAL Touch 78”

DUAL Touch Series
TRIUMPH BOARD a.s. Page 11 of 27
3) Technical Specifications
TRIUMPH BOARD 78” DUAL Touch
EAN: 8592580101144(78” USB only), 8592580101168 (USB/“wireless ready”)
Active screen area size: 78” (1981 mm) diagonal
Aspect ratio: 4:3
Technology: IR (Infrared) cell LED optical
Resolution: 12800x9600
Projection screen area: 1573 x1181 mm, 1967 mm diagonal
Board size without packing: 1693 x1284x31 mm (width x height x depth without plastic pen tray)
Interface Type: USB 2.0 / 2.4 GHz RF Wireless (optional)
Cable Length: 6 m
Working Environment -20 to 40°C
Response time: 6ms
Power supply: USB DC 5V from PC (optional wireless PC receiver and USB adaptor /220V)
Power consumption: < 250 mA (wireless PC receiver 20mA)
Temperature Range: -20 to 40°C, storage temperature - 40 to 70°C
Humidity Operating 30-90% non condensing, storage 0-95%, non condensing
Platform: Windows 7, XP and Vista, Linux, MAC
Board weight (net): 24 kg
Weight incl. packing: 30 kg
Warranty 2 years (5 years upon registration)
Optional: Stand with Easy Lift system

DUAL Touch Series
TRIUMPH BOARD a.s. Page 12 of 27
TRIUMPH BOARD 89” DUAL Touch
EAN: 8592580101175 (89” USB), 8592580101137 (89” USB/ “wireless ready”)
Active screen area size: 89” (2265 mm) diagonal
Aspect ratio: 16:10
Technology: IR (Infrared) cell LED optical
Resolution: 12800x9600
Projection screen area: 1824 x1141 mm, 2151 mm diagonal (with the hotkeys)
Board size without packing: 2060 x1244x31 mm (width x height x depth without plastic pen tray)
Interface Type USB 2.0 / 2.4 GHz RF Wireless (optional)
Cable Length 6 m
Working Environment -20 to 40°C
Response time: 6ms
Power supply: USB DC 5V from PC (optional wireless PC receiver and USB adaptor /220V)
Power consumption: < 250 mA (wireless PC receiver 20mA)
Temperature Range: -20 to 40°C, storage temperature - 40 to 70°C
Humidity Operating: 30-90% non condensing, storage 0-95%, non condensing
Platform: Windows 7, XP and Vista, Linux, MAC
Board weight (net): 28 kg
Weight incl. packing: 35 kg
Warranty: 2 years (5 years upon registration)
Optional: Stand with Easy Lift system

DUAL Touch Series
TRIUMPH BOARD a.s. Page 13 of 27
TRIUMPH BOARD 96” DUAL Touch
EAN: 8592580091377 (USB / možnost bezdrátového připojení)
Active screen area size: 96” (2446 mm) diagonal
Aspect ratio: 16:9
Technology: IR (Infrared) cell LED optical
Resolution: 12800x9600
Projection screen area: 2044 x1143 mm, 2394 mm diagonal (with the hotkeys)
Board size without packing: 2269 x1249x30 mm (width x height x depth without plastic pen tray)
Interface Type: USB 2.0 / 2.4 GHz RF Wireless (optional)
Cable Length: 6 m
Working Environment: -20 to 40°C
Response time: 6ms
Power supply: USB DC 5V from PC (optional wireless PC receiver and USB adaptor /220V)
Power consumption: < 250 mA (wireless PC receiver 20mA)
Temperature Range: -20 to 40°C, storage temperature - 40 to 70°C
Humidity Operating: 30-90% non condensing, storage 0-95%, non condensing
Platform: Windows 7, XP and Vista, Linux, MAC
Board weight (net): 28 kg
Weight incl. packing: 35 kg
Warranty: 2 years (5 years upon registration)
Optional: Stand with Easy Lift system

DUAL Touch Series
TRIUMPH BOARD a.s. Page 14 of 27
4) Package contents
After unpacking, please make sure all of the following parts (subject to your purchase) are present
DUAL Touch – USB / Wireless ready
Item
Description
Quantity
1
Whiteboard with built-in IR Sensor
1
2
USB Cable
1
3
Pen tray
1
4
Hotkey strip ( 78” 20*20 mm included / 89“,96” 50*50 mm stick on the board )
2
5
Stylus ( plastic pen )
2
6
Eraser
1
7
Hard Copy User Manual incl. mount instructions
1
8
TB Comenius – Software CD with soft copy user manual
1
9
MyScript Stylus - Software CD
1
10
RM Easiteach - Software DVD
1
11
Installation components set
1

DUAL Touch Series
TRIUMPH BOARD a.s. Page 15 of 27
5) Wall mount Installation
1
Anchors 12
6
Drape
2
Hook
7
Square
3
Anchors 10
8
Stand
4
Screw 5x50
9
Screw 4x16
5
Screw M5x12
10
Hotkeys
DUAL Touch 89“
1. attach suspender (6) by screwing to board
2. measure the position of top hooks for hanging (2)
3. install dowels (1) and hooks (2)
4. install shelf (8) on board
5. measure and install dowels (3) and holders (7)
6. hang board
Step 4 Hang the board onto the wall mount, Ensure the board is
Securely in place before releasing

DUAL Touch Series
TRIUMPH BOARD a.s. Page 16 of 27
1
Anchors 12
6
Drape
2
Hook
7
Square
3
Anchors 10
8
Stand
4
Screw 5x50
9
Screw 4x16
5
Screw M5x12
10
Hotkeys
DUAL Touch 96”

DUAL Touch Series
TRIUMPH BOARD a.s. Page 17 of 27
1
Anchors 12
6
Drape
2
Hook
7
Square
3
Anchors 10
8
Stand
4
Screw 5x50
9
Screw 4x16
5
Screw M5x12
10
Hotkeys
- At least two qualified service technicians should perform the installation procedure. Serious personal
injury and / or damage can result from dropping this product.

DUAL Touch Series
TRIUMPH BOARD a.s. Page 18 of 27
- BEFORE the installation, please make sure both wall material and wall strength are suitable
Otherwise, the board might fall which may cause injury and/or damage. Please consult your dealer
for details.
- Use only the designated wall mount.
- Follow all installation instructions carefully.
- Make sure the mounting screws are properly sized to handle the weight of the board.
-Make sure the wall mount is firmly and securely anchored to a solid structure.
- Make sure the board is fastened firmly and securely to the wall mount before using it.
Do not install this product in location where it may be exposed to direct sunlight, near heating
equipment, or near air-conditioning vents.
Do not install this product in strong sunlight or strong lighting location.
Do not install this product in location where the temperature may change suddenly.
Avoid to install two or more this product in the same room or adjacent to each other. Please consult
your dealer for details.

DUAL Touch Series
TRIUMPH BOARD a.s. Page 19 of 27
6) Software Installation
Install TB Comenius DUAL Touch software
a) To run the Installation Program, double-click file
“DUAL Touch install.exe” then click “Next”
to install the software
b) Choose destination location and click “Next” to continue.
c) Click Install
d) Click “Finish” to exit upon the DUAL Touch software
has been successfully installed.

DUAL Touch Series
TRIUMPH BOARD a.s. Page 20 of 27
e) Connect your PC / laptop with the DUAL Touch by using
USB cable (provided).
f) DUAL Touch - USB or DUAL Touch - Wireless Receiver has
been detected and ready to use upon the following dialogue
shown.
7) HW Installation
a) Connection
User must have PC, projector, DUAL Touch - USB or DUAL Touch - Wireless Receiver and connect them as shown in
the figure below.
DUAL Touch – USB/ Wireless ready - Model Connection Diagram
