TRIVIEW TSM-1200 User manual

STAND MIXER
MODEL: TSM-1200
220-240V~ 50/60Hz 1200W

Description
1. Speed control switch
2. Release button for multifunction head
3. Cover
4. Removable cover for mincer power outlet
4.1. Release button for Cutter housing
5. Power outlet for mincer
6. Bowl cover
7. Stainless steel bowl
8. Power outlet for blender
9. Release button for Cover 3
10. Multifunction head
11. Whisk
12. Dough hook
13. Mixer blade
14. Fine grinding disc
15. Medium grinding disc
16. Worm shaft
17. Cutter blade
18. Coarse grinding disc
19. Screw ring
20. Pusher
21. Tray
22. Cutter housing
23. Cover for jug
24. Glass jug
25. Blade
26. Blade seat

Safety instructions
1. Carefully read the instructions before using your appliance.
2. Never leave the appliance to run unsupervised, especially when young
children or handicapped persons are present.
3. Check that the voltage rating of the appliance does in fact match
that of your electrical system.
Any connection error will nullify the guarantee.
4. The appliance must be plugged into an earthed electrical socket.
5. If you have to use an electrical extension lead, it must be earthed and
you should make sure that no-one can trip over it.
6. Unplug the appliance as soon as you have finished using it and when you
clean it.
7. Don’t use your appliance if it has been damaged. You should contact an
approved service centre.
8. Any work on the appliance other than normal care and cleaning by the
customer must be carried out by an approved service centre.
9. Do not immerse the appliance, the power cord or the plug in water or in
any other liquid.
10. Do not allow the power cord to hang within the reach of children, to
come close to or into contact with the hot parts of your appliance, any
other source of heat or any sharp edge.
11. If the power cord or the plug are damaged, don’t use your appliance .To
avoid any risk, these must be replaced by an approved service centre.
12. Do not put any accessories containing metal in a microwave oven.
13. Switch off the appliance and disconnected from supply before
changing accessories or approaching parts which move in use.
14. Do not touch the whisk, mixer blade or kneading hook while
the appliance is in operation.
15. Only use one accessory at a time.
16. This appliance is not intended for use by children or other

persons without assistance or supervision if their physical,
sensory or mental capabilities prevent them form using it safely.
17. Children should be supervised to ensure that they do not play
with the appliance.
Using your appliance
ADJUSTING THE HEIGHT OF YOUR ACCESSORIES.
(See figure A).
Your accessories are equipped with a system for adjusting the height
above the bottom of the bowl for optimum results.
1. Press the release button (2).lift the multifunction head and
insert the mixer blade, Hook or whisk.
2. Hold it in position.
3. Lower the head of the appliance (10) with the button (2) press
until a click is heard.
4. Adjust the height by turning the shaft: adjust the accessories to
the ideal position.
5. Lift the head (10) of the appliance again, hold the Mixer blade,Hook or
whisk in position.
6. Before using for the first time, clean all parts of the accessories with
soapy water .rinse and dry.
7. Place the appliance on a flat, clean and dry surface and then plug in your
appliance.
MIXING/KNEADING/BEATING/EMULSIFYING/WHIS
KING
(See figure B).
Depending on the nature of the ingredients, the bowl (7) with its
cover can be used to prepare up to 2.3 kg of dough.
1. Press button (2) to the release the multifunction head (10) and raise it to
a vertical position.
2. Fit the bowl(7) onto the appliance by turning until it locks in position

and place the ingredients in it ,weighting them as indicated under the
weighing function (see figure B).
3. Position the cover on the head with the filling opening at the front of the
appliance (see figure B).
4. Fit the desired accessory(11,12,13) in the power outlet ,pushing the shaft
of the accessory home and turn it a quarter turn towards you to lock it in
position(see figure B).
5. Lower the multifunction head of the appliance to horizontal position and
press button again (a click should be heard ).
6. During preparation, you can add ingredients through the opening the
cover.
7. To stop the appliance, turn the knob (1) back to 0.
HOMOGENISING /MIXING/BLENDING
(See figure C).
Depending on the nature of the ingredients, the blender can be used
to prepare up to 1.25L of mixture.
Assembling and fitting the attachment.
1. Assemble the blade assembly to the seal and lock it with a quarter turn
clockwise into the bottom of the jug (the jug must be upright).
2. Lower the multifunction heard of the appliance (10) to a horizontal
position and press button (2) again (a click should be heard).
3. Press button (9) to open the cover (3).
4. Ensure that the appliance is at a standstill before latching on the
assembled blender.
5. Fit the assembled blender and lock it in position by turning it
anticlockwise.
6. Place the ingredients in the blender jug, weighing them as indicated
under the weighing function and then fit the cover with the measuring
plug.
Caution:
7. Do not run the blender empty for more than 1 minute.

8. Never fill the mixing jug with boiling fluids, you could allow
these to cool down to a room temperature. Otherwise, the
appliance could overheat and the glass of the mixing jug
could crack.
9. When you use the jug operate ice, you could select nine ices
each time and the every ice size is 40MM * 40MM * 20MM.
MEAT GRINDER (ACCORDING TO MODEL D)
(See figure D).
Assembling and fitting the attachment.
1. Take the body (Cutter housing 22) by the feed tube with the largest
opening upwards.
2. Insert the worm shaft 16 (drive pins first ) in the cutter housing
22 .
Fit the cutter blade 17 on the shaft with the cutting edges
upwards.
3. Place the selected hole-plate over the blades ensuring that the
two lugs fit in the two cut-outs in the body (see the figure D).
4. Screw ring (19) the cap nut fully home on the body.
5. Check the assembly .the shaft should have no play nor be able
to turn on itself.
6. Play the multifunction head in the horizontal position (a click
should be heard ).
7. Offer up the assembled mincer attachment, titled towards you, to the
outlet and engage it fully .return the feed tube to a vertical position by
turning to the rear until it stops.
8. Place the removable tray on the feed tube.
Caution:
1). When you dissembled the body (Cutter housing 22), you must press
the button (Release button for Cutter housing, see the arrow of
figure D).
2). Insert the pieces of meat in the feed tube piece by piece using the

pusher, never push the meat with the finger or any other utensil.
Cleaning
1. Unplug the appliance.
2. Never immerse the motor until in water or put it under running water
wipe it with a soft dry or slight damp cloth.
3. For easier cleaning, quickly rinse the accessories after use. Completely
dismantle the mixer attachment .handle the blades with care, as some
have sharp cutting edges.
4. Wash , rinse and wipe the accessories or the can be put in the dishwasher,
except for the metal components of the mincer attachment body Fine
grinding disc(14),Medium grinding disc(15),Worm shaft(16),
Cutter blade (17),
Coarse grinding disc (18) and Screw ring (19).
5. The grinding disc and the blade must be kept lubricated. Wipe
them over with cooking oil after each use.

6. If your accessories are discoloured by food (carrots, oranges etc), rub
them gently with kitchen towel dipped in cooking oil and then clean in
the usual way.
7. Blender assembly: pour hot water with a few drops of washing up liquid
into the blender jug. Close the cover. Fit it on the appliance and give a
few pulses. Remove the blender, rinse the jug under running water and
leave it upside down to dry .for cleaning more difficult residues,
especially with thicker preparations. The blade nut assembly can be
detached from the bottom of the jug, to do this, place the empty blender
upside down on a flat surface, release the blade /nut assembly with a
quarter turn and lift out the seal with care.

Processing Guide
Accessory Food Maximum
Operation time Speeds Preparation
Cream(includ
e 38%fat)
250ml 10minutes 5-6 /
whisk
Egg white 12pcs 3minutes 5-6 /
Flour 1700g
Salt 20g
Yeast 10g
Sugar 10g
Water 1100g
Dough hook
Lard 20g
10minutes 5-6 /
Flour 100g
Castor sugar 100g
Margarine 100g
Mixer blade
Egg 2pcs
5minutes 1-4 /
Carrot 560g 15×15×15 mm
Blender
Water 840g
3minutes P/6
/
Beef 2000g 3minute
Meat
Grinder Pork 2000g 3minute
3-6 20×20×60 mm
