TRIVIEW TLM-0841C User manual

Close Circuit TV Monitor
TLM-0841C
Tatung Company of America
2850 El Presidio, Long Beach, CA 90810
Tel: [phone] Ext.112 (Western Region), 125 (Southeast Region), 377 (Northeast Wegion)) Fax: [phone] WWW.TATUNGUSA.COM
MODEL TLM-0841C
LCD Panel
Screen Size 8.4 inch
Viewable size 170.4mm (H) x 127.8mm(V)
Dot Pitch 0.213mm x 0.213mm
View angle H/V -60°, +60°/-40°, +60°
Contrast ratio 500:1
Brightness 450 cd/m2
Resolution 800 x 600
Response Time 35ms (tr:10ms, tf:25ms)
Display Color 262K
-------------------------------------------------------------------------------------------------------------------
Control key define -, +, Menu, Power
-------------------------------------------------------------------------------------------------------------------
Power Supply
Input-Voltage 12VDC Power (Power adaptor)
Consumption <24W
-------------------------------------------------------------------------------------------------------------------
Video
Input Composite video, connector: 1 BNC
Level: 1.0Vp-p / 75Ω
Output 1 BNC connector for CVBS loop-through output,
OSD Contrast, Brightness, Color, Tint, Language,
OSD setting, Color Temperature select,
Volume, PIP, Recall, Exit
System
Compatibility Scanning Frequency
NTSC : 15750Hz ± 500Hz / 60Hz,
PAL : 15625Hz ± 500Hz / 50Hz
-------------------------------------------------------------------------------------------------------------------
Audio
Input Connector: 1 x RCA jack (L+R)
Level: 1.0Vp-p / 1 Khz
Output N/A
Speaker 1W x 1 embedded
------------------------------------------------------------------------------------------------------------------
Dimensions 8.63” (w) x 7.0” (h) x 2.5” (d) (w/o base)
8.63” (w) x 7.5” (h) x 3.63 (d) (w/ base)
Additional benefits 2D comb filter /2-D de-interlace
4:3 aspect ratio
Life Time counter
RoHS compliant
Note: The preliminary specification are subject to change without notice.
