Tronic TLA 18 A1 User manual

IN-CAR CHARGER
Operating instructions
KFZ-LADEADAPTER
Bedienungsanleitung
IAN 383705_2110
IN-CAR CHARGER TLA 18 A1

GB│IE│NI│1 ■TLA 18 A1
Contents
Introduction................. 3
Information about these operating
instructions .......................3
Notes on trademarks ...............4
Proper use .......................5
Warnings and symbols used .........6
Safety ..................... 9
Basic safety instructions .............9
Description of components ... 12
Use....................... 13
Check package contents ...........13
Using the device..................14
Troubleshooting ............ 17
Cleaning .................. 18
Storage when not in use ..... 18
Disposal................... 19
Disposal of the device .............19
Disposal of the packaging ..........20
IB_383705_TLA18A1_LB6.indb 1IB_383705_TLA18A1_LB6.indb 1 17.02.2022 09:02:5117.02.2022 09:02:51

■ 2 │GB│IE│NI TLA 18 A1
Attachment ................ 21
Technical specifications ............21
Notes on the EU Declaration of
Conformity ......................22
Kompernass Handels GmbH warranty 22
Service .........................27
Importer ........................28
IB_383705_TLA18A1_LB6.indb 2IB_383705_TLA18A1_LB6.indb 2 17.02.2022 09:02:5117.02.2022 09:02:51

GB│IE│NI│3 ■TLA 18 A1
Introduction
Information about these
operating instructions
Congratulations on the purchase of your
new device.
You have selected a high-quality product.
The operating instructions are part of this
product. They contain important information
about safety, usage and disposal. Before
using the product, please familiarise your-
self with all the operating and safety instruc-
tions. Use the product only as described
and for the range of applications specified.
Keep these operating instructions as a
reference and store them near the product.
Please pass on all documentation incl. these
operating instructions to any future owner(s)
if you sell this product or give it away.
IB_383705_TLA18A1_LB6.indb 3IB_383705_TLA18A1_LB6.indb 3 17.02.2022 09:02:5117.02.2022 09:02:51

■ 4 │GB│IE│NI TLA 18 A1
Notes on trademarks
■ Qualcomm®Quick ChargeTM is a product
of Qualcomm Technologies, Inc. and/or
its subsidiaries.
Qualcomm®is a trademark of Qualcomm
Incorporated, registered in the United
States and other countries.
Quick ChargeTM is a trademark of
Qualcomm Incorporated.
■ USB®is a registered trademark of USB
Implementers Forum, Inc.
All other names and products may be
trademarks or registered trademarks of
their respective owner.
IB_383705_TLA18A1_LB6.indb 4IB_383705_TLA18A1_LB6.indb 4 17.02.2022 09:02:5117.02.2022 09:02:51

GB│IE│NI│5 ■TLA 18 A1
Proper use
The in-car charger is a car accessory
that is compatible with the vehicle socket
(cigarette lighter) and is designed solely
for charging and operating devices with a
USB port. The car charger adapter is suitable
only for vehicles in which the negative
terminal of the battery is connected to the
bodywork.
The device is not intended for any other
purpose nor for use beyond the scope de-
scribed. The device is not intended for use
in commercial or industrial environments.
Claims of any type due to damage from
improper use are excluded. The operator
bears sole liability.
IB_383705_TLA18A1_LB6.indb 5IB_383705_TLA18A1_LB6.indb 5 17.02.2022 09:02:5117.02.2022 09:02:51

■ 6 │GB│IE│NI TLA 18 A1
Warnings and symbols used
The following warnings are used in these
operating instructions (where applicable):
DANGER
A warning at this hazard level
indicates a hazardous situation.
Failure to avoid this hazardous situation
will result in serious injuries or death.
► Follow the instructions on this warning
label to avoid the risk of death or
serious injury.
WARNING
A warning at this hazard level
indicates a potentially hazardous
situation.
Failure to avoid this hazardous situation
could result in serious injuries or death.
► Follow the instructions on this warning
label to avoid the risk of death or
serious injury.
IB_383705_TLA18A1_LB6.indb 6IB_383705_TLA18A1_LB6.indb 6 17.02.2022 09:02:5417.02.2022 09:02:54

GB│IE│NI│7 ■TLA 18 A1
CAUTION
A warning at this hazard level
indicates a potentially hazardous
situation.
Failure to avoid this hazardous situation
could result in injuries.
► Follow the instructions in this warning
notice to prevent injuries.
CAUTION
A warning at this hazard level
indicates a risk of property
damage.
Failure to avoid this situation could result
in property damage.
► Follow the instructions in this warning
to prevent property damage.
NOTE
► A note provides additional information
that makes handling the device easier
for you.
IB_383705_TLA18A1_LB6.indb 7IB_383705_TLA18A1_LB6.indb 7 17.02.2022 09:02:5417.02.2022 09:02:54

■ 8 │GB│IE│NI TLA 18 A1
The e-Mark is a certification mark
for the labelling of components
requiring approval in motor
vehicles and states that the necessary tests
have been carried out and that an ECE
component approval has been issued. The
letters “xx” are placeholders and stand for
the country where the licence was issued.
The Qualcomm®Quick ChargeTM
3.0 technology symbol indicates
that the technology used enables
a reduced charging time for compatible
devices connected to the green USB port of
the in-car charger. Compatible connected
devices are automatically detected and
provided with the appropriate output volt-
age and output current from the in-car
charger.
IB_383705_TLA18A1_LB6.indb 8IB_383705_TLA18A1_LB6.indb 8 17.02.2022 09:02:5517.02.2022 09:02:55

GB│IE│NI│9 ■TLA 18 A1
Safety
This section contains important safety
instructions for handling the device. This
device complies with the statutory safety
regulations. Improper use may result in
personal injury and property damage.
Basic safety instructions
To ensure safe operation of the device,
follow the safety guidelines set out below:
■ Check the device for visible external
damage before use. Do not operate
a device that has been damaged or
dropped.
■ This device may be used by children
aged 8 years and above and by persons
with limited physical, sensory or mental
capabilities, or lack of experience and
knowledge, provided that they are under
supervision or have been told how to use
the device safely and are aware of the
potential risks.
IB_383705_TLA18A1_LB6.indb 9IB_383705_TLA18A1_LB6.indb 9 17.02.2022 09:02:5517.02.2022 09:02:55

■ 10 │GB│IE│NI TLA 18 A1
Do not allow children to play with the
device. Cleaning and user maintenance
tasks may not be carried out by children
unless they are supervised.
■ DANGER! Do not allow children
to play with the packaging material!
Keep all packaging materials away from
children. There is a risk of suffocation!
■ Never subject the device to extreme heat
or humidity. This particularly applies to
storage in a car. Extreme temperatures
can occur in car interiors and glove
compartments during long periods of
immobilisation. Remove any electrical
and electronic devices from the vehicle.
■ Do not operate the device whilst steering
a car or any other vehicle. This is hazard-
ous to other road users.
IB_383705_TLA18A1_LB6.indb 10IB_383705_TLA18A1_LB6.indb 10 17.02.2022 09:02:5517.02.2022 09:02:55

GB│IE│NI│11 ■TLA 18 A1
■ WARNING! When using the in-car
charger (incl. any connected devices),
ensure that it does not interfere with the
steering, braking or the operation of
other vehicle systems (such as airbags)
and does not restrict your field of view
when driving.
■ Do not allow any liquids or moisture to
get into the device.
■ The device must always be supervised
during use.
■ WARNING! Unplug the device from
the vehicle socket immediately if you
notice unusual noises, a burnt smell or
smoke. Have the device checked by a
qualified specialist before using it again.
IB_383705_TLA18A1_LB6.indb 11IB_383705_TLA18A1_LB6.indb 11 17.02.2022 09:02:5517.02.2022 09:02:55

■ 12 │GB│IE│NI TLA 18 A1
■ Never open the device housing. There
are no parts inside the device which
can be maintained. All repairs must
be carried out by authorised specialist
companies or by the Customer Service
department. Improper repairs may put
the user at risk. It will also invalidate any
warranty claims.
Description of components
(See fold-out page for illustrations)
1USB type A socket featuring
Qualcomm®Quick ChargeTM 3.0
2Operating LED
IB_383705_TLA18A1_LB6.indb 12IB_383705_TLA18A1_LB6.indb 12 17.02.2022 09:02:5517.02.2022 09:02:55

GB│IE│NI│13 ■TLA 18 A1
Use
Check package contents
(See fold-out page for illustrations)
The following components are included
in delivery:
▯ In-car charger
▯ These operating instructions
♦ Remove all parts of the device from the
packaging and remove all packaging
materials.
NOTE
► Check the package for completeness
and signs of visible damage.
► If the delivery is incomplete or damage
has occurred as a result of defective
packaging or during transport, contact
the service hotline (see section Service).
IB_383705_TLA18A1_LB6.indb 13IB_383705_TLA18A1_LB6.indb 13 17.02.2022 09:02:5517.02.2022 09:02:55

■ 14 │GB│IE│NI TLA 18 A1
Using the device
CAUTION
► Make sure that the power consumption
of your device is not higher than 3 A
when you are using the USB socket 1.
Refer to the instruction manual of your
device for more information.
► The maximum power output of the
USB socket 1is 3A.
NOTE
► The USB socket 1supports Qualcomm
®
Quick Charge
TM
3.0 (compatible
with Quick Charge
TM
2.0 and Quick
Charge
TM
1.0). If the connected device is
compatible with this charging standard,
it will automatically be detected by the
in-car charger. The in-car charger sup-
plies the appropriate output voltage or
output current so that the device can be
charged more quickly. Devices without
this charging standard can be charged
normally using the USB socket 1.
IB_383705_TLA18A1_LB6.indb 14IB_383705_TLA18A1_LB6.indb 14 17.02.2022 09:02:5517.02.2022 09:02:55

GB│IE│NI│15 ■TLA 18 A1
♦ Insert the car charger adapter into the
12/24V connection of your car. This
is usually the vehicle socket (cigarette
lighter) on the dashboard of your vehicle.
Many vehicles have a second socket
by the rear seats or in the boot. 24 volt
batteries are often used in lorries or on
boats.
♦ The operating LED 2lights up white to
signal that the in-car charger is being
supplied with power. The operating LED 2
also lights up if no device is
connected. Depending on the vehicle
type, it is possible that the ignition has
to be switched on first.
♦ Connect your device to the car charger
adapter. Use the original USB cable
supplied with your device to optimise
the charging process.
♦ If required, you can switch your connected
device on for further use.
IB_383705_TLA18A1_LB6.indb 15IB_383705_TLA18A1_LB6.indb 15 17.02.2022 09:02:5517.02.2022 09:02:55

■ 16 │GB│IE│NI TLA 18 A1
NOTE
► Observe the charging status on your
connected device.
♦ Disconnect your connected device from
the car charger adapter once the device
has completed charging.
♦ Unplug the car charger adapter from
the vehicle power outlet when you are
finished using it.
CAUTION
► Never connect the in-car charger
unless you are charging a device. The
car charger adapter also consumes
power in standby mode and therefore
must be disconnected from the vehicle
socket after use! Otherwise the battery
will discharge when the engine is not
running.
IB_383705_TLA18A1_LB6.indb 16IB_383705_TLA18A1_LB6.indb 16 17.02.2022 09:02:5517.02.2022 09:02:55

GB│IE│NI│17 ■TLA 18 A1
Troubleshooting
A connected device does not charge
(the operating LED 2does not light
up white)
♦ No connection to the vehicle socket.
Check the connection.
♦ Depending on the vehicle type, it is pos-
sible that the ignition has to be switched
on first.
The operating LED 2goes out after
a device has been connected.
♦ The car charger adapter is overloaded
and will no longer charge the connected
device. The internal overcurrent protec-
tion has been triggered. Disconnect the
connected device from the in-car charg-
er. The white operating LED 2lights
up immediately and the in-car chargeris
ready for use again.
IB_383705_TLA18A1_LB6.indb 17IB_383705_TLA18A1_LB6.indb 17 17.02.2022 09:02:5517.02.2022 09:02:55

■ 18 │GB│IE│NI TLA 18 A1
Cleaning
CAUTION
► Disconnect the device from the 12/24V
on-board socket before cleaning.
► Do not use caustic, abrasive or
solvent-based cleaning materials. They
can damage the surfaces of the device.
♦ Clean the surfaces of the device with a
soft, dry cloth.
Storage when not in use
CAUTION
► Disconnect the device from the 12/24V
on-board socket when not in use.
► The temperatures inside the vehicle
can reach extreme values in summer
and winter. Consequently, to avoid
damage to the device, you should
not store it in the vehicle.
♦ Store the device in a location that is clean,
dry, dust-free and out of direct sunlight.
IB_383705_TLA18A1_LB6.indb 18IB_383705_TLA18A1_LB6.indb 18 17.02.2022 09:02:5517.02.2022 09:02:55

GB│IE│NI│19 ■TLA 18 A1
Disposal
Disposal of the device
The adjacent symbol of a
crossed-out dustbin means that
this device is subject to Directive
2012/19/EU. This directive
states that this device may not be disposed
of in the normal household waste at the end
of its useful life, but must be handed over
to specially set-up collection locations,
recycling depots or disposal companies.
This disposal is free of charge for the
user. Protect the environment and
dispose of this device properly.
Your local community or munici-
pal authorities can provide
information on how to dispose
of the worn-out product.
IB_383705_TLA18A1_LB6.indb 19IB_383705_TLA18A1_LB6.indb 19 17.02.2022 09:02:5817.02.2022 09:02:58
