Tronix 140-017 User manual

View instructions and
technical data also on
our website
Read these instructions & save for future use
Article number
Brand
140-017
Tronix Lighting
Type Ground spots
Contents of this product 1x 24V ground spot 8,5W 3000K
Technical datasheet Digitally available
on our webshop
Ground spot | 24V | 106mm | 36° |
SS-316 | 8,5W | 3000K

140-017
Description
This 24V ground spotlight features a high-quality aluminum cover ring,
which protects the CREE LEDs present. Ideal for installation in the front and
backyard, in front of a facade or around the driveway.
Features
• IK08 and IP67 rated;
• 24V connection, excluding power supply;
• Extra long power cord (3m) for easy connection.
Installation
1. Turn off the power, remove the product and accompanying parts from the packaging. Then cut a hole to size to insert
the ground spotlight later;
2. Check the wiring and then put it through the outer sleeve of the ground spotlight;
3. Connect the cables and place the spotlight itself in the sleeve and secure it where necessary;
4. Check the complete installation after the ground spotlight is installed. Should it be in order, the mains power can be
reactivated.

Before getting started with this product, it is advisable to check the order completeness and any damage. If this is the
case, please contact Tronix Lighting.
Off
On

140-017
Safety
Safety is a top priority at Tronix Lighting. Therefore, we heartily recommend that you follow the following steps closely:
• Keep this manual carefully for future reference;
•Choose a qualified electrician while installing, maintaining or inspecting this product;
• Never look directly into a light source to avoid possible damage to the eye;
• Always ensure that the relevant power group is on non-active when the product is connected;
• Use only recommended combinations (LED drivers, controllers or dimmers) to avoid injury or damage to the product.
The CE mark indicates that this product complies with EU regulations on safety, health and environmental
protection;
The WEEE symbol stands for "Waste Electrical and Electronic Equipment Regulation," a directive on the
collection, recycling and recovery of electronic waste;
The Class III symbol indicates that this product features an "extra-low voltage (SELV) input and therefore
does not require additional protection.
Terms and symbols (as relevant to product)
• This product has an IP67 rating. This means that the housing is touch-safe, provides full protection against dust and
can withstand immersion (30 min at 1m).
Technical problems and repair
Should a product not work properly after installation, or if the product exhibits
problems over time, it is advisable to check the following elements:
• Check the wiring and installation of your product;
• Check for the presence of interfering elements such as dust, water or other
electronics;
• If possible, try disconnecting the product and testing it in another location to
rule out a problem at the location;
• Should you be dealing with a WIFI-based product, check and reset your
router's settings.
Should the product still not work after testing, it is recommended to send it in for
inspection and/or repair. To do so, please contact Tronix Lighting using nearby
details and proof of purchase (packing slip).
Supplier:
Tronix Lighting B.V
Vluchtoord 41
5406 XP Uden, Netherlands
[phone]
[email protected]
