Trotec VA5-2 User manual

www.troteclaser.com
Operatinginstruction
Atmos pre-filter VA5
#version 1.5
English
Original manual

2 / 40 #version 1.5
www.troteclaser.com
Trotec Laser GmbH
Linzer Straße 156
A –4600 Wels
AUSTRIA
Trotec Laser GmbH
Freilingerstraße 99
A –4614 Marchtrenk
AUSTRIA
Tel.: [phone]
[email protected]
www.troteclaser.com
Technical
Changes
Technical specifications are subject to change without notice.
Trotec Laser GmbH reserves the right to improve or modify any of the
product without prior notice.
Copyright
This documentation with all illustrations is intellectual property of
Trotec Laser GmbH. The entire documentation is given to the user for per-
sonal use only. Reproduction, translation or any distribution to third parties is
not permitted without the prior consent of Trotec Laser GmbH. Any breach of
law will be prosecuted.

Content
#version 1.5 3 / 40
www.troteclaser.com
Content
1Introduction....................................................................................................................................... 5
1.1 Service and Guarantee............................................................................................................... 5
2Safety................................................................................................................................................. 6
2.1 Duty of Information ..................................................................................................................... 6
2.2 Intended Use .............................................................................................................................. 7
2.3 Residual Risk.............................................................................................................................. 8
2.4 Notes for the Operator................................................................................................................ 8
2.5Instruction and Training.............................................................................................................. 9
2.6 Safety References for the Operation of the Atmos pre-filter ...................................................... 9
2.7 Safety References to the Maintenance .................................................................................... 10
3Referring to Special Kinds of Danger .......................................................................................... 11
3.1 Electrical power of the Atmos pre-filter VA5-2 and VA5-2/ADD............................................... 11
3.2 Types of dust and chemical Substances.................................................................................. 11
3.3 Crushing hazard at the changeover damper............................................................................ 12
4Technical Data................................................................................................................................ 13
5Functional description of the Atmos pre-filter............................................................................ 15
6Transport, Storage and Starting Up ............................................................................................. 17
6.1 Transport on an INKA-palette................................................................................................... 17
6.2 Storage ..................................................................................................................................... 17
6.3 Unpack and Setup.................................................................................................................... 18
6.4 Scope of supply / Packing List.................................................................................................. 19
6.5 Start-up protocol ....................................................................................................................... 19
7Connection of the Atmos pre-filter............................................................................................... 22
8Operation......................................................................................................................................... 23
8.1 Filter-Cartridge with mechanical wipe....................................................................................... 23
8.2 Manually Operated Change Over............................................................................................. 23
9Maintenance.................................................................................................................................... 24
9.1 Operating Condition.................................................................................................................. 24
9.2 Care and Visual Inspection....................................................................................................... 25
9.3 Visual Control ........................................................................................................................... 25
9.4 Maintenance ............................................................................................................................. 25
9.4.1 Exchange of the Filter Cartridges................................................................................... 26
9.4.2 Exchange of the Dust bin ............................................................................................... 27
10 Option.............................................................................................................................................. 29
10.1Automatic Filter Cleaning VA 5-2 ............................................................................................. 29
10.2Automatic Operated Change-Over VA 5-2............................................................................... 29
10.3Dust bin with additive media FilterSave.................................................................................... 29
10.4Automatic Control ..................................................................................................................... 30
11 Activation of the Programs ........................................................................................................... 31
11.1In General................................................................................................................................. 31
11.2Operation of the Control ........................................................................................................... 31
11.3Standard Announcement –Menu Normal Operation............................................................... 31
11.4Setup Announcement, Adjustment........................................................................................... 32

Operatinginstruction
Content
4 / 40 #version 1.5
www.troteclaser.com
11.5Function of the Programs and Adjustments for the Servicing personnal ................................. 33
11.6Manual Carrying out of the Programs....................................................................................... 35
11.6.1Filter Cleaning ................................................................................................................ 36
11.6.2Change-Over.................................................................................................................. 36
11.6.3Additive Dosing............................................................................................................... 36
12 Error Tracing and Brake down search......................................................................................... 39
13 Disposal........................................................................................................................................... 40
13.1Environmental Protection.......................................................................................................... 40
13.2Filter and Types of Filter Dust .................................................................................................. 40
13.3Final putting out of Operation ................................................................................................... 40

Operatinginstruction
Introduction
#version 1.5 5 / 40
www.troteclaser.com
1 Introduction
This operating instruction is a substantial assistance for the successful and safe operation of the At-
mos pre-filter VA 5-1, VA 5-2/110V, VA 5-2/230V and VA 5-2 ADD.
The operating instructions must be constantly available at the Atmos pre-filter and must be read and
used from each person who work with / and on the Atmos pre-filter e.g.:
Operation, disturbance recovery in the work routine, disposal of operating and auxiliary materials,
Maintenance (maintenance, care, repair) and/or
Transport
is assigned.
1.1 Service and Guarantee
The Trotec Laser GmbH is endeavoured to work on your questions and orders as fast as possible. We
ask you to indicate your name and address before each inquiry.
The guarantee of the Trotec Laser GmbH for the Atmos pre-filter extends within the guarantee period
to damage, which can be proved on construction –to lead back material or production defects.
The guarantee period amounts to 24 months. It begins with the delivery / or start up of the Atmos pre-
filter.
A guarantee is transferred only in its entirety if:
The distribution inspection, the delivery and the instructions are implemented correctly,
The Atmos pre-filter must be used like intended,
The maintenance and servicing instructions have to be obeyed strictly.
In the case of guarantee the manufacturing firm transfers the material costs, which results directly from
the remedy at the Atmos pre-filter.
Only the spare part prices and the fee of the current price list are valid.
We refer to the regulations as well as the general trading conditions of the Trotec Laser GmbH.

Safety
6 / 40 #version 1.5
www.troteclaser.com
2 Safety
2.1 Duty of Information
For your security!
As operator of the filter system please, consider absolutely the data given in the CE manufacturer ex-
plana-tion, CE - declaration of conformity, the data and information in the user manual and in particu-
lar the operat-ing and safety instructions.
Residual Risk
Filter systems and suction units contain inflammable construction parts (filter materials, seals, plastic
parts, etc.). Consider in your work place evaluation after the law for employee protection (AschG) the
residual risk of a case of fire. It is important to have the approval of us with changes in the use of the
filter system in writing.
CE –Declaration of Conformity
As a rule we deliver the filter system with a CE - declaration of conformity. When assembled with other
parts it becomes a higher - ranking filter system for which you, as operator, have the duty to make a
danger analysis and you must provide a CE - declaration of conformity for the whole filter system.
Duty of Information
Sparks, cigarette stubs or similar may not be sucked into the filtering device.
Our plants may be used only as described in the operating manual and as intended. Changes in the
use require our expressly written permission.
Each use going beyond it is not considered as intended, the manufacturer / supplier can not be made
liable for developing damages which result from it. The risk carries the operator.
Intended use of the Atmos pre-filters
It is not allowed sucking off dust, smoke, gases and media which do not correspond with this
operating instruction, take notice of chapter 2.4. The media exhausted may be classified in no
dust explosion class (St-Class).
Start-up, Maintenance and Service
Refer to maintenance and safety instructions in the operating manual.
All repair and maintenance work may only be carried out with complete stand still of the machine/plant
(separate all connected machines or switching off from the mains, pull the plug out of the socket). Only
trained and authorised personnel may operate, make maintenance work service at the machine/plant.
Work within the electrical range may be implemented by authorised specialists only!
In Austria: The Atmos pre-filter must at least 1x be examined per § 32 1-4 GKV annually.

Operatinginstruction
Safety
#version 1.5 7 / 40
www.troteclaser.com
2.2 Intended Use
The Atmos pre-filter of the Trotec Laser GmbH exclusively serves for sucking off dust, gases and
smoke with pollutants, which develop in the following range of production:
Stamp production
Marker/sign production, and engraving procedure
No statement can be made for other fields of activity regarding the endangerment of humans and envi-
ron-ment. If loaded gases and smoke pollutants in other than here mentioned purposes are to be
sucked off, no overall statement can be made.
In this case the Trotec Laser GmbH are to be addressed, otherwise any warranty claim is void.
Also consider while handling dangerous materials the rules for prevention of accidents and here in
particular the safety rules for extractor equipment for air pollution control on the job, ZH 1/140.
The Atmos pre-filter may be operated only with accessory / with the equipment which are intended
from the Trotec Laser GmbH.
The Atmos pre-filter may not be used:
for damp liquids or vaporous materials
sticky dusts
outdoors,
with explosive or inflammable gas/material/material air mixtures,
with incandescent or burning substances.
Alone the operator of the Atmos pre-filter is responsible for damage resulting from not intended use.
This implies changes in the construction of the Atmos pre-filter without the permission (in writing!) too.
Exchange damaged construction units / spare parts immediately! Use original spare parts only. In par-
ticular with non original filter cartridges it is not ensured that they filter the pollutants from the extracted
gas / smoke completely!
Keeping the references also belongs to the intended use:
for safety,
for the operation and
to maintenance / servicing,
which are described in these operating instructions.

Safety
8 / 40 #version 1.5
www.troteclaser.com
2.3 Residual Risk
With attention of all safety regulations a residual risk remains with the operation of the Atmos pre-filter.
All persons, who work on / with the Atmos pre-filter, must know these residual risks and obey the in-
structions, which prevent that these residual risks lead to accidents or damage.
CAUTION!
By the inhalation of poisonous gases and types of poisoning dust damage can occur. Likewise long
term damage can occur to internal organs by repeated inhalation, sips and contact with gases and
dust contained in the filter cartridges and suction hoses itself.
Before all work on the inside of the Atmos pre-filter, in particular at the filter cartridge as well as on the
dust extrac-tion hose and dust collection bin the personal protection equipment is to put on.
In addition belongs:
1. Protection gloves (one-way gloves from polyethylene, long version),
2. Protection mask (purifying dust respirator with particle filter with examination of the protection
stage 3),
3. Eye protector.
2.4 Notes for the Operator
The operating instructions are a substantial component of the Atmos pre-filter. The operator ensures
that the operation personnel take these guidelines to the knowledge.
Since the operating instructions are exposed presumably to a strong demand at the place of work, it is
in-cumbent on the operator:
to keep the original safe,
to make sure that a copy of the operating instructions are constantly available at the Atmos pre-
filter,
that each user reads and considers the operating instruction attentively.
The operating instructions are to be supplemented by the operator around operating instructions due
to the existing national regulations for accident prevention (BGV D27) and to the environmental pro-
tection, includ-ing the information of the duty to supervision and obligations to register for regarding
working particularity relating to the work sequences and assigned personnel.
Beside the operating instructions and the in the user country valid regulations for accident prevention
are to be considered and the recognised specialised technical rules for security and professional work-
ing as well.
The operator / user must not make changes at the Atmos pre-filter, which could impair security, with-
out the permission of the manufacturing firm! This applies in particular to the installation and the atti-
tude of safety devices.

Operatinginstruction
Safety
#version 1.5 9 / 40
www.troteclaser.com
Spare parts must correspond to the technical requirements specified by the manufacturing firm. This is
always ensured with original spare parts.
Only trained or instructed personnel may work on / with the Atmos pre-filter. Specify the competencies
of the personnel for servicing, controlling and repairing clearly!
Untrained personnel or persons in training may work on / with the Atmos pre-filter under constant su-
pervision of an experienced person only!
2.5 Instruction and Training
As operator of the Atmos pre-filter you are obligated to inform and/or to instruct the operating/mainte-
nance stuff about existing right and safety rules for the prevention of accidents as well as about exist-
ing safety devices on and around the Atmos pre-filter. Different technical qualifications of the person-
nel are to be considered.
The operating / maintenance stuff must have understood the instructions and it must be guaranteed
that the instructions are considered and obeyed.
As operator make each member confirm the participation in the instructions and training in writing.
2.6 Safety References for the Operation of the Atmos pre-filter
With all works, this implies:
the operating,
the inspection,
the maintenance and
the repairing
consider the turn on and turn off processes in accordance with the operating instruction and the refer-
ences to the maintenance!
Operate the Atmos pre-filter only, if all protection and safety devices e.g. solvable protection devices,
housing bolts etc. are in place and functional!
Before starting up, the personnel have to make itself familiar with and around the Atmos pre-filter.
At least once a shift the Atmos pre-filter must be examined for outwardly recognisable damage, if
there is a dust container fixed and the filling level.
Stop and secure immediately with malfunctions at the Atmos pre-filter. Disturbances are to be elimi-
nated immediately through trained specialists.

Safety
10 / 40 #version 1.5
www.troteclaser.com
2.7 Safety References to the Maintenance
Before beginning inform the operating personnel about execution of special- and maintenance work.
Make sure that the in this operating instructions prescribed inspections are made in time.
Illuminate maintenance area if necessary with hand or stand lamps.
Switch off the connected suction unit (Atmos, Atmos Compact) and the laser for servicing and
maintenance work at the Atmos pre-filter.
The turbine(s) (of the Atmos, Atmos Compact) must stand still before you begin with the service and
mainte-nance work at the Atmos pre-filter.
Exchange the filter cartridge if necessary and in time, even there are no safety relevant defects!
With prepare-, assembly or maintenance works tighten loosened screwed connections always again!
If the disassembly of protection device is necessary for maintenance, the reattachment and the exami-
nation of the protection device has to take place immediately after conclusion of the servicing and
maintenance work!
Clean the Atmos pre-filter at the beginning of service / maintenance work and in particular connections
and bolts from dust and other impurity by wiping off with a damp cloth.
With the selection of the cleaning agent make it certain that no surfaces, keyboards, plastics or seals
are attacked.

Operatinginstruction
Referring to Special Kinds of Danger
#version 1.5 11 / 40
www.troteclaser.com
3 Referring to Special Kinds of Danger
3.1 Electrical power of the Atmos pre-filter VA5-2 and VA5-2/ADD
The work on the electrical equipment of the Atmos pre-filter VA5-2 and VA5-2/ADD may be made only
by an electri-cal specialist or personnel instructed by/under line and supervision of an electrical spe-
cialist, in accordance with the electrical rules!
It must be waited always five minutes after switching off, so that the inserted condenser in the control
board can unload themselves. Opening of the housing is only permissible at the end of this time.
Use only original safety devices with prescribed amperages!
Never accomplish work on live parts!
With repairs pay attention to the fact that constructional characteristics are not to be safety reducing
changed in particular: allowed air creeping and air clearance as well as distances are not to be made
smaller by isolations.
The perfect grounding of the electrical system must be ensured by a protective grounding system.
Program modifications at the control system may be made only in consultation with Trotec Laser
GmbH or directly with the manufacturing firm.
With disturbances at the electrical power-supply separate immediately the Atmos pre-filter from the
net, by:
switching off the Atmos pre-filter at the On/Off key and thereafter
disconnecting the plug from the mains.
3.2 Types of dust and chemical Substances
With the Atmos pre-filter partial toxic types of dust from contaminated air are filtered. Depending upon
the kind of the assigned material these types of dust can be health-endangering and / or carcinogenic.
While handling toxic types of dust special caution is required.
Consider and observe valid regulations and safety data sheets of the manufacturers concerning stor-
age, handling, employment and disposal!
With eye or skin contact with the dust in the filters or the suction hose, the part concerned must be
rinsed immediately with much water. Suitable mechanisms (eye wash bottle) must be at hand!
By cleansing agent and disinfectants loaded skin should be maintained. Irritation can be avoided by
the preventing use of skin protection means and suitable skin care. The preservative agent which can
be used is to be selected depending of the pollution impact and the individual condition of the skin.
Containing fat preservative agents are predominantly applicable.
Eating, drinking, smoking and keeping food in areas in which chemicals are, is forbidden!
Keep dangerous materials never in containers for food. Mark always clearly for the respective material
use certified containers.

Referring to Special Kinds of Danger
12 / 40 #version 1.5
www.troteclaser.com
Depending upon pollution impact particle and gas filters are subjects to special regulations and are ac-
cordingly to dispose.
The inappropriate exchange of the pollutant-loaded filter cartridge represents a health risk for the im-
plementing persons and their environment. Absolutely consider therefore with the exchange of the fil-
ter cartridge the section “Exchange of the filter cartridge”.
3.3 Crushing hazard at the changeover damper
Dont reach into the openings
there is the risk of crushing your
finger!!!

Operatinginstruction
Technical Data
#version 1.5 13 / 40
www.troteclaser.com
4 Technical Data
Atmos pre-filter manual cleaning
Type
VA5-1
Width x height x depth
435 x 1.270 x 520 mm
Atmos pre-filter automatic cleaning
Type
VA5-2/115V
Width x height x depth
435 x 1.270 x 408 mm
Connection voltage
115 V
Control voltage
24 V
Type of protection
IP 30
Type of current
1PH+N+PE
Rated current
4,4 A
Frequency
50/60 Hz
Atmos pre-filter automatic cleaning
Type
VA5-2/230V
Width x height x depth
435 x 1.270 x 408 mm
Connection voltage
230 V
Control voltage
24 V
Type of protection
IP 30
Type of current
1PH+N+PE
Rated current
2,2 A
Frequency
50/60 Hz
Atmos pre-filter automatic cleaning &
additiv
Type
VA5-2/115V ADD
Width x height x depth
435 x 1.270 x 408 mm
Connection voltage
115 V
Control voltage
24 V
Type of protection
IP 30
Type of current
1PH+N+PE
Rated current
4,4 A
Frequency
50/60 Hz

Technical Data
14 / 40 #version 1.5
www.troteclaser.com
Atmos pre-filter automatic cleaning &
additiv
Type
VA5-2/230V ADD
Width x height x depth
435 x 1.270 x 408 mm
Connection voltage
230 V
Control voltage
24 V
Type of protection
IP 30
Type of current
1PH+N+PE
Rated current
2,2 A
Frequency
50/60 Hz
Dust class
M der DIN Norm EN-60335-2-
69

Operatinginstruction
Functional description of the Atmos pre-filter
#version 1.5 15 / 40
www.troteclaser.com
5 Functional description of the Atmos pre-filter
The Atmos pre-filter serves for pre extraction of gases and smoke loaded with pollutants. The Atmos
pre-filter must be operated with a suction unit (e. g. Atmos, Atmos Compact).
The gases / smoke are sucked in through the suction hose into the Atmos pre-filter with the inserted
filter cartridge.
Underneath the filter unit is the dust bin wherein the dust of the filter cartridge is cleaned.
1.
6.
3.
7
2.
Fig 1

Functional description of the Atmos pre-filter
16 / 40 #version 1.5
www.troteclaser.com
5.
4.
Fig 2 (manual Atmos pre-filter)
Pos. 1
Exhaust manifold (OUT)
Pos. 5
T-handle, manually operated change-
over
Pos. 2
Intake manifold (IN)
Pos. 6
Connections for laser and Atmos
Fuse and power
Pos. 3
Cleaning rubber wipe / rubber plate con-
nector
Pos. 7
Connection part for vacuum table
Pos. 4
Crank for mechanical wipe

Operatinginstruction
Transport, Storage and Starting Up
#version 1.5 17 / 40
www.troteclaser.com
6 Transport, Storage and Starting Up
6.1 Transport on an INKA-palette
The Atmos pre-filter will be delivered horizontal on an INKA palette. For the transport the following cor-
ridor promoting vehicles are permissible:
Fork lift and
Fork truck.
Hard impacts of the Atmos pre-filter when setting off (e.g. on the loading area of the transport vehicle)
must be avoided.
Secure the INKA palette with the Atmos pre-filter against sliding and tilting in the case of transport.
Consider the valid accident prevention and industrial safety regulations.
Consider absolutely references on the packing!
DANGER!
Mortal danger by falling down of the Atmos pre-filter!
By inappropriate attachment on the INKA palette the Atmos pre-filter can fall over and cause heaviest
injuries or death.
Use only suitable lifting tools and means of mounting!
The driver must be entitled for leading a transport car / a fork truck.
Drive with the fork lift between the horizontal span members of the INKA pallet.
The contact between the Atmos pre-filter and stroke rack of the corridor promotion vehicle is to be pre-
vented:
Wedge in a distance wood between the packing of the Atmos pre-filter and the stroke rack.
Avoid hard impacts when setting off the Atmos pre-filter.
Before rising up the Atmos pre-filter, all persons must depart from the work area of the corridor pro-
moting vehicle
6.2 Storage
The Atmos pre-filter must be stored at a vibration less, dry and as dust free place as possible. It may
not be stored outside of buildings.
The range of air temperature must be between + 5 °C and + 35 °C.
The condensation of air humidity on the surface of the Atmos pre-filter must absolutely be avoided.

Transport, Storage and Starting Up
18 / 40 #version 1.5
www.troteclaser.com
6.3 Unpack and Setup
Information!
Unpack the Atmos pre-filter only at the place of assembly.
Do not set up the Atmos pre-filter in direct proximity to heating / heating elements.
When setting up, respect for sufficient area for the exchange of the filter cartridge. / dust collecting bin.
Proceed when unpacking and setting up the Atmos pre-filter as follows:
Examine the complete supply for outside damage, which may have developed e.g. in the case of
transport.
Place the Atmos pre-filter to even firm ground. Adjust the adjustable leg to the maybe uneven
ground.
Place the Atmos pre-filter in such a way, that connected hoses do not lie in passageways. In gen-
eral no one has to step over connected hoses.
OPTION at ADD: Place the additive container next to the Atmos pre-filter and connect it as shown.
Y-adapter (black)
2,5 m suction hose NW 45 mm
incl. connection tubes

Operatinginstruction
Transport, Storage and Starting Up
#version 1.5 19 / 40
www.troteclaser.com
6.4 Scope of supply / Packing List
Examine in every detail with the delivery of the Atmos pre-filter the scope of supply and announce im-
mediately if parts are missing or be damaged. Later complaints are not accepted.
To the regular scope of supply belongs:
Atmos pre-filter, complete (with built-in filter cartridge);
at automatic VA the matching 115/230V net cable is added in each case
2,5 m suction hose with 2 connection tubes NW 70.
1 reserve-dust bin / with the automatic Atmos pre-filter with ADD is it filled with FilterSave (additive
media) serves as reserve dust bin
Y-Adapter for additive or vacuum table connection (only with ADD)
2,5 m suction hose with 2 connection tubes NW 45
Long hexagon key for tightening and loosening the cartridge fixing
Please note that the scope of supply can deviate in individual cases from this list. In this case the list
in the delivery document is valid.
6.5 Start-up protocol
Control according to the enclosed installation report.

Transport, Storage and Starting Up
20 / 40 #version 1.5
www.troteclaser.com
Start-up- / shortcoming- / protocol
Contracting body:
Order number:
Project:
Object:
Contractor:
Project number:
final inspection list of defects
Notes / defects:
The item has been tested and the plaque attached on .
The audit showed that the object is
approved.
approved excluded the listed deficiencies.
not approved.
Documentation delivered on
Next system verification:
City, Date:
_______________________________
customer
