TRU Audio RM-12 User manual

User Manual
RM-12
Powered Subwoofer
This powered subwoofer leaves nothing to be
desired. The RM-12 uses a robust, 500 watt, black
anodized aluminum woofer, driven by a powerful
A/B amplifier built exclusively for this cabinet and
driver array.
The RM-12 sounds fantastic with all TruAudio
architectural speakers, making combining different
models in an AV system simple. Additional speak-
ers can be added to a system with the confidence
that the speakers will remain balanced. With over 2
years of engineering and testing, the RM-12 com-
pletes the TruAudio theater package.
The RM-12 includes: Subwoofer cabinet and grill,
power cord, instruction manual and (4) heavy-duty
plastic feet attached to the bottom of the cabinet.
CAUTION: DO NOT OPEN THE SUBWOOFER. THIS
WILL VOID THE WARRANTY.
To reduce the risk of electrical shock and fire, do not
remove the amplifier panel from the back of the
cabinet or the subwoofer from the front of the
cabinet. There are NO fuses or serviceable parts.
All service to this product MUST be done by a
TruAudio Authorized repair center.
Before installing, please read the following
instructions:
• Always turn off the power of your
receiver/preamp and the powered subwoofer
• When turning your amplifier/receiver on, make
sure your volume is turned all the way down
• Never expose the subwoofer to excessive cold,
heat, humidity, or direct sunlight
• This device should never be used in, on or near
water due to risk of fatal shock
• DO NOT attempt to open or dismantle this
subwoofer
• The subwoofer should always have plenty of air
flow to reduce the chance of over heating
RM-12
Contents
Inspect your subwoofer immediately upon opening
for any kind of damage. If for some reason damage
has occurred, please contact your Dealer or TruAu-
dio immediately. We recommend that you retain the
packaging in case a need arises for you to transport
your speaker.
Unpacking and Inspection

Back panel and input/output (I/O) definition
1. Power Mode: Select the either energy-saving or “always-on” power mode
oAuto: Amp goes into standby after no detected signal input for 20 minutes*
oOn: Amp is always on, regardless of input signal status.
* Amp will automatically turn on typically in one second or less once audio signals are resumed.
2. Analog input attenuation: Affects analog balanced and unbalanced inputs only.
oNormal: No attenuation.
oHi: Attenuates input signal by -6dB.
3. USB Control - Service Only
4. Feature Control: Single knob digital actuator with single/double-click enabled with rotary scrolling to
navigate the amp’s extensive feature menu.
5. Standby/On LED:
o Red when amp is in energy saving “stand by” state.
o Green when amp is operating normally.
DSP processing block diagram

WELCOME
MENU
PEQ
VOLUME
0 dB
HIGH PASS
ON/OFF
HIGH PASS
FREQ: 31.5 Hz
HIGH PASS
SLOPE: -12 dB
LOW PASS
ON/OFF
LOW PASS
FREQ: 31.5 Hz
LOW PASS
SLOPE: -12 dB
PHASE DEGREE
120°
HIGH PASS DELAY
7.5 ms
SUBSONIC FILTER
ON/OFF
SUBSONIC FILTER
FREQ: 25 Hz
SUBSONIC FILTER
SLOPE: -12 dB
MENU
VOLUME
FUNCTION FRAME
MENU
HIGH PASS
MENU
LOW PASS
MENU
PHASE DEGREE
MENU
HIGH PASS DELAY
MENU
SUBSONIC FILTER
MENU FRAME
Single clickTurn to adjust volume up/down
Single ordoubleclickto return to MENUFRAME
Turn to EnableorDisable
Double click= MENUFRAME
Turn to selectFREQUENCY
Double click= MENUFRAME
Turn to selectSLOPE
Double click= MENUFRAME
Turn to EnableorDisable
Double click= MENUFRAME
Turn to selectFREQUENCY
Double click= MENUFRAME
Turn to selectFREQUENCY
Double click= MENUFRAME
Turn to selectSLOPE
Double click= MENUFRAME
Turn to selectSLOPE
Double click= MENUFRAME
Turn to selectpreset slot P1 P2 P3
Single clickto save orload
Turn to enable ordisable
Double click= MENUFRAME
Turn to adjust selectsave orload
Double clickto return to MENUFRAME
Double click
to return to
MENUFRAME
Turn to selectFREQUENCY
Double click=
PEQ MENU FRAME
Turn to selectFREQUENCY
Double click=
PEQ MENU FRAME
Turn to selectGAIN
Double click=
PEQ MENU FRAME
Turn to selectGAIN
Double click=
PEQ MENU FRAME
Turn to selectQ
Double click=
PEQ MENU FRAME
Turn to selectQ
Double click=
PEQ MENU FRAME
Double click
to return to
MENUFRAME
Turn to adjustPHASEdegree up/down
Single ordoubleclickto return to MENUFRAME
Turn to adjust HIGH PASS
Single ordoubleclickto return to MENUFRAME
Single click
Single click
Single click
Single click
Single click
Single click
Single clickSingle clickSingle click
Single click
Single click
Single click
Single click
Single click
Single click
PRESET
SAVE LOAD
MENU
PRESET SAVE/LOAD Single clickSELECT PRESET P1 P2 P3
Single click
PEQ1 PEQ1
FREQ: 63 Hz
PEQ1
GAIN: 0.0 dB
PEQ1
Q: 3.6
PEQ2
FREQ: 63 Hz
PEQ2
PEQ2
GAIN: 0.0 dB
PEQ2
Q: 3.6
PEQ1
FREQ: 63 Hz
PEQ1
LEVEL: 0.0 dB
PEQ1
Q: 3.6
PEQ2
FREQ: 63 Hz
PEQ2
GAIN: 0.0 dB
PEQ2
Q: 3.6
VOLUME
HIGH PASS
LOW PASS
PHASE DEGREE
HIGH PASS DELAY
SUBSONIC FILTER
PEQ
PRESET SAVE/LOAD
Turn
Single click
Single click
Single click
Single click
Single click
Turn
Turn
Turn
Turn

NOTES ABOUT HUM
While this amplier has been designed to minimize
the possibility of hum in the subwoofer system, it is
still possible that a hum may occur in rare
circumstances. Safety grounding can create a path
for small amounts of 60 Hz energy to travel through
the line-level audio system. While not
dangerous, this energy can cause difculty with the
subwoofer auto signal sensing circuit, and will
interfere with the quiet enjoyment of your system.
The rst course of action should be trying to make
sure that all of the audio components are connected
to either the same electrical outlet, or at least into
the same circuit branch. Next, cable TV systems are
notoriously the culprit, so be sure to try disconnect-
ing all coaxial feeds that are connected to the
system. If this solves the problem, install a coaxial
line isolator and reconnect the system. Worst case,
a line-level audio isolator/transformer connected to
the line-in of the subwoofer amplier can usually
solve the problem.
Cleaning the Subwoofer
All RM series subwoofers feature lightly textured,
durable paint nish. When needed, we suggest
cleaning with a damp cloth with water only. Do not
use any kind of abrasive cleaners or detergents.
SoundVision Technologies dba TRUAUDIO
SUBWOOFER and ELECTRONIC PRODUCT WARRANTY
All subwoofers and amplifiers have a limited 5 year warranty. This warranty includes 5 year parts and repair labor
on all components. The warranty extends only to the original purchaser of the product and not to any subsequent
owner. TRUAUDIO’s obligation under these warranties is limited to repairing or replacing any component found
defective in material or workmanship under normal conditions of use with an equal and/or current product. These
warranties shall not apply to products which have been abused, modified, or disassembled. Products to be repaired
or returned under this warranty must be returned to the factory through an authorized TruAudio dealer with all
transportation and insurance charges prepaid.
It is the policy of TRUAUDIO to continuously incorporate improvements into our products. All specifications are subject to
change without notice. If you have any questions regarding this or any other TRUAUDIO products, please visit
www.TruAudio.com or contact us:
Office: 1-888-858-1555, Monday-Friday 7 am - 6 pm MST.
Email: [email protected]
TruAudio
198 N Old Highway 91
Hurricane, UT 84737 USA
Specifications
RM-12
Speaker Type:
Enclosure Design:
Driver:
Power, class D:
Frequency Range:
Inputs:
Outputs:
Amplier Protection:
Cabinet:
Cabinet Dimensions:
Grill:
Available Colors:
High-end Powered Subwoofer
Front ring, ported cabinet, internally
braced
12” black anodized aluminum cone,
cast basket, long excursion, 2.5”
2-layer voice coil.
500 watt into 4 ohms with internal
amplier
25-125 Hz (+/-3 dB)
Line level RCA, balanced inputs
Line level RCA, balanced outputs
Short circuit thermal protection
Real wood veneer, Built in St. George, UT
17.7” High (including feet)
17.0” Wide
16.2” Deep
Frame wrapped in black speaker cloth
Black in stock. Other colors available with
3 week lead time.
