TRU Audio BP-SUB-12 User manual

User Manual
BP-SUB-12
Description
In the Box
Install Method 1 - Straps
The TruAudio BP-SUB-12 was designed to be
used in most any room you want deep sounding
bass in a very discreet way. The BP-SUB-12 can
be used in a TV home theater application or
throughout the home to add great sounding bass
to your distributed audio system.
NOTE: The BP-SUB-12 Is a passive subwoofer
which must be paired with the TruAudio
TRU-S500DSP subwoofer amplifier.
The BP-SUB-12 is a custom product which can be
mounted many ways as per your application. Here
are two ways we recommend, but all applications
are different and need to be taken into account.
Attach the two mounting straps between two
rafters and place the subwoofer on the straps.
Ensure that the subwoofer is not touching the
ceiling sheet rock. Next fit the tube with the baffle
attached through the hole in the sheetrock from
below and attach the tube to the subwoofer port.
Be sure to tighten the custom tube clamp over the
tube on both ends. Now attach the baffle to the
ceiling.
NOTE: dry fit the baffle and tube from the
subwoofer box to the ceiling where you will cut the
hole to make sure it fits.
Install Method 2 - Wall Mount
Attach the short wall bracket to the subwoofer box
using 1” wood screws (Put a drop of silicone
around the screw to prevent a possible air leak. If
you put any holes in the subwoofer box in the
wrong location by accident you must fill the
hole(s) with silicone).
Attach the longer bracket to a stud using 2” wood
screws. Attach the subwoofer to the stud mount
and make sure it is secure. Next fit the tube with
the baffle attached through the sheetrock from
below and attach the tube to the subwoofer port.
Be sure to tighten the custom tube clamp over the
tube on both ends. Now attach the baffle to the
ceiling.
NOTE: dry fit the baffle and tube from the sub-
woofer box to the ceiling where you will cut the
hole to make sure it fits.
Subwoofer
30” sound tube with 2 tube clamps
In wall/ceiling baffle
Cut out template
Paintable Grill
Mounting straps (2)
Mounting brackets (2)
•
•
•
•
•
•
•

BP-SUB-12
It is the policy of TRUAUDIO to continuously incorporate improvements into our products. All specifications are subject to
change without notice. If you have any questions regarding this or any other TRUAUDIO products, please visit
www.TruAudio.com or contact us:
Office: 1-888-858-1555, Monday-Friday 7 am - 6 pm MST.
Fax: [phone]
Email: [email protected]
TruAudio
198 N Old Highway 91
Hurricane, UT 84737 USA
Optional Equipment - Toe Kick
Speaker Type:
Woofer:
Power:
Impedance:
Freq Response:
Sensitivity:
Grill Type:
Cabinet Dims:
Family:
Bandpass subwoofer
12” Aluminum
350 watts
4 Ω
35 - 120 Hz
88 dB
Ghost style, frameless
17” (432mm) H,
17” (432mm) W,
11” (279mm) D
13.625”
ATTACH TO SUBWOOFER
ATTACH TO STUD
2.75” 5.25”
9.75”
