Tru-Test EziWeigh User manual

www.tru-test.com
EZIWEIGH USER MANUAL
WORLD LEADERS IN WEIGHING p 1
IMPORTANT: Follow the instructions below before using EziWeigh.
Power connector for connecting
12 V vehicle battery (red clip to
positive terminal) or Tru-Test power
adaptor. To connect power adaptor,
pull battery clips off indicator lead
and plug lead into power adaptor
lead (red to red). The power cable
is permanently connected to non-
battery indicators.
Dust caps screw together to keep out dirt and moisture when cables are connected
to indicator. Screw back on indicator/cables when cables removed.
Installation
1. Install load bars under the platform on a firm,
level surface (see Load Bar User Manual).
2. Mount indicator bracket in a convenient
place where animals cannot knock the
indicator off or chew the cables. The
bracket mounts onto flat surfaces (timber
rails, concrete) or pipe-work with the
supplied U-bolt.
3. Connect load bar cables to the indicator.
Connect dust caps as shown. The indicator
automatically calibrates to Tru-Test load bars.
4. Connect power cable (if needed).
Load cell
connectors
Start Up
Instructions for setting user language on EziWeigh 1 and 2 indicators: (See diagram below for position of hidden keys)
1. Connect the indicator to a power supply.
2. Press to turn on the indicator.
3. When the display window shows , press and together.
4. Press repeatedly to scroll through the menu until you reach .
5. Press repeatedly to scroll through the menu to find your language:
6. Press to save.
Instructions for setting weighing units on EziWeigh 1 and 2 indicators:
1. Press to turn on the indicator.
2. When the display window shows ,press and together.
The word should display on the screen.
3. Press to change between (pounds) and (kilograms).
4. Press to save.
GB
ENGLISH p1
F
FRENCH p5
D
GERMAN p9
S
SPANISH p13
P
PORTUGUESE p17
WARNING:
Do NOT change any
other settings within
these menus. Changing
other settings may
cause your EziWeigh
indicator to malfunction.
English →French →Spanish →German →Portuguese ↩
↪

p 2
FUNCTIoNS
BRACKET
INSTAllATIoN
Install on a horizontal or vertical pipe as shown, or attach to the wall using screws supplied.
Stable light shows weight is stable.
Shows displayed weight
has been locked using
key.
Turns indicator on.
Returns indicator to live weight
display. Press to re-weigh if animal
is not fully on the platform when
stable light shows.
Sets automatic zeroing on/off.
The indicator will zero on power
up or when there is no load on the
platform. This zeroes the platform
to compensate for any build up
of dirt (up to 3 kg/6 lb) during
weighing. In some situations this
feature should be turned off.
Two common examples are:
1. To avoid accidental zeroing of
the user’s hand pressure on the
entry gate.
2. To avoid zeroing a bale left in
a wool press when the indicator
is turned off and then on again
later.
Sets fine weighing on/off.
Not available for some load cells.
Turns indicator off.
Press to manually
zero the scale.
Pipe (maximum 55 mm diameter).
Bracket
Locks weight until
next animal is
weighed, or
is pressed.
HOLD annunciator is
on when weight is
locked.

BASIC
WEIghINg
1. Press and wait for display.
2. Move animal onto platform.
3. Wait for stable light .
4. Release animal and repeat from step 2.
holD WEIghT 1. Press and wait for display.
2. Move animal onto platform.
3. Wait for stable light .
4. Press to lock display until next animal.
5. Release animal.
6. Note down animal weight.
DISPlAY
mESSAgES Load cell type not recognised. Contact TRU-TEST.
Recharge battery. About 10 minutes till flat.
Battery is charging. Indicator can be used normally.
Charge level. Battery is low.
Charge level. Battery is fully charged. It is safe to leave on charge.
External power supply too high. Check power supply.
External power supply too low. Voltage too low to charge.
Function is off.
Function is on.
Overload. Weight on scale is greater than capacity. If fine mode is on, clear stats
and turn fine mode off.
Under load. Negative load or faulty load cell/wiring.
Indicator is zeroing.
Scale needs service. Note the error number and contact TRU-TEST.
oPERATINg
NoTES
During weighing, check that animals are fully on the platform.
Ensure that the underside of the platform or crate is kept clear of dirt and stones.
Do not leave the indicator or load bars in water. Store the indicator in a cool dry place.
The indicator automatically turns off after 15 minutes of no activity, to limit discharge of the
internal battery.
p 3

Tru-Test Limited, New Zealand www.tru-test.com An ISO 9001 Quality Registered Company
FCC Notice
This Tru-Test model EziWeigh has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is used in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case users will be required to correct
the interference at their own expense.
INTERNAl
BATTERY
oPTIoN
SPECIFICATIoNS
The internal battery charger operates from either the recommended Tru-Test power adaptor or a 12 volt
vehicle battery. Damage to the indicator caused by other charging supplies, including automotive
battery chargers, is not covered by the warranty.
The indicator displays about 10 minutes before flat, if the battery was fully charged within
the last 2 weeks. Charge the indicator for 12 hours before using it for the first time.
To maximise battery life, observe the following simple guidelines:
• Preferably recharge the battery overnight.
• Never charge the indicator in direct sunlight.
• Store the indicator in a cool dry place.
The internal battery charger ensures maximum life of the battery, while giving the fastest charging
rate possible. The battery is protected from overcharging. Charging a flat battery takes 6 hours at
temperatures of 10 to 35 ºC (50 to 95 ºF).
You can safely leave the indicator on charge all the time. The scale can be used while charging. You do
not need to charge before storage.
Charging at low or high temperatures could extend the charging time to 12 hours. At extreme
temperatures the indicator will not charge.
Fully charge the indicator after storage.
Cleaning:
Clean only with warm water and soap, other cleaners may damage the case.
Note: product specifications may change without prior notice.
Total Capacity 2000 or 3000 kg (4400 or 6600 lb) depending on load bars used.
Resolution Set to 0.5 kg (fine mode 0.1 kg) or 1 lb (fine mode 0.2 lb).
Accuracy ±1 % or 2 resolutions (whichever is greater) with Tru-Test load bars
connected.
Power supply 12 V DC (power adaptor or vehicle battery).
Operating temperature -10 to +40 ºC (+14 to +104 ºF).
Storage temperature -20 to +35 ºC (-4 to +95 ºF).
Internal battery run time 8 hours with 2 load bars connected.
Environmental IP67 (immersion in 1 m of water).
Service Information:
For repair or service information, contact the supplier of your EziWeigh or visit our website at
www.tru-test.com.
For online registration of warranties go to www.tru-test.com.
p 4
