TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual
1
Please read and understand before
operating machine.
1. Pre-check all nuts, bolts, grub screws for tightness
prior to operating machine.
2. Understand the operating procedures and the controls
before operating.
3. Use the machine to roll 18-36 greens then check that
all nuts, bolts etc. are tight. If loose and the Loctite seal
has been broken, treat item as per Loctite instructions,
reseal, then tighten securely.
4. Loose transmission and drive roller sprockets will
cause damage to shafts and keyways. Ensure they
are correctly tightened at all times.
5. Change the transmission oil after 50 hours of
operation, then as per the servicing schedule.
We use and recommend Penrite Synthetic 5 SAE 5W-60.
Available through our dealer network.
U.S.A. customers contact your dealer or visit
www.truturf.com to nd your nearest dealer or
email us direct at [e-mail]
Australian customers call 07 5594 7199.
International customers contact your dealer or visit
www.truturf.com to nd your nearest dealer.
Important

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual 2
Machine Information
Model. RS48-11C Roll ‘n’ Spike Golf Green Roller
Serial No.
Engine No.
Transmission No.
Purchase Date No.
Congratulations on your investment in the RS48-11C Roll
‘n’ Spike Golf Green Roller and your move to smoother,
faster, more consistent putting Greens. The following
operation and maintenance manual has been prepared
for use with the RS48-11C Roll ‘n’ Spike Golf Green Roller.
It is intended as a guide and supplemental updates to
the manual may take place at a future date, without prior
notice.
This machine is engineered to be simple to operate and
easy to maintain. If you have any questions or concerns
that this manual does not address, please feel free to
contact your distributor.
Distributor Information
Name:
Address:
Telephone:
Fax:
Email:
Machine Information Record

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual
3
Safety Information
Safety is of the utmost importance when operating
turf equipment.
To ensure safe operation of the RS48-11C RS48-11C
Roll ‘n’ Spike Golf Green Roller, please follow the
following safety guidelines.
• Always make a pre-operation inspection before you
start the engine. If this procedure is not carried out
damage to property or personnel may occur.
• Keep children, pets and inexperienced personnel
away from the machine. This machine should only be
operated by trained and skilled personnel - check with
your supervisor if you are unsure.
• Know how to stop the engine when in motion. Read
and understand engine manufacturers manual, as
supplied.
• Never permit inexperienced operators to use the
machine. This machine requires certain knowledge
and expertise to operate it; you must be a trained
person to use this machine. Unskilled persons can
harm themselves and others if they operate this
machine.
• Do not use in enclosed areas unless well ventilated.
Carbon monoxide gases are dangerous if inhaled, it
can cause death; use the machine outdoors.
• When transporting the roller, make sure the trailer
lock down mechanism is secure to prevent premature
release of the catch. If the trailer catch is not correctly
engaged while towing and releases accidentally, the
front of the roller can drop and dig into the ground,
causing the machine to move dangerously in any
direction causing bodily injury. When carrying out
maintenance ensure the catch is engaged correctly;
if it is not the trailer arm could y up making contact
with a person(s) causing serious injury.
• When engine is running, always keep hands and
loose clothing away from rotating shafts, chains and
sprockets in the transmission area. If hair, clothing or
loose objects become entangled on a rotating shaft
serious bodily injury could occur. Stop engine before
opening safety cover tted to the transmission area.
• Never ride on the machine or have the engine running
when machine is being towed.
Operator, remember it is your responsibility to be
aware of your surroundings. To avoid accidents, think
safe and operate safe.
Safety Information

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual 4
Warranty
Universal Conditions:
Tru-Turf Pty. Ltd. will either repair or replace any item
or part of a Tru-Turf Pty. Ltd. Golf Greens Roller that is
defective in workmanship or material for a period of
thirty six (36) months from the date of delivery of the
new product to the original end user. These items will be
repaired or replaced free of charge and freight free.
Products Protected By This Warranty:
This Warranty relates to the following products
manufactured by Tru-Turf Pty. Ltd. :-
GR11000C; RS48-11C; RS48-11D; R52-11T, R52-11TC and
R52-ELT Golf Greens Rollers.
TR66 Triplex roll ‘n’ spike mower attachment heads and
brackets; SR72 Sports ground roller.
MT5000-1, MT5000-2 and MT5000-3 Totes are covered for
a period of twelve (12) months.
Parts Warranted By Suppliers To Tru-Turf:
Specic component parts supplied to Tru-Turf Pty. Ltd. are
covered by that supplier’s Warranty. These parts include
Eaton Transmission, Honda Engines and Kohler Engines.
Only Tru-Turf Pty. Ltd. manufactured parts qualify for the
the Thirty Six month warranty.
Normal Wear and Tear:
Tru-Turf Pty. Ltd. will not repair or replace parts subject to
normal maintenance routines as specied in the products
Operator’s Manual nor to parts subject to wear and tear
during the correct operation of the product. These parts
include, but are not limited to, oils, lters, tyres, shafts,
bearings, blades, spikers, slicers, brakes, belts, hoses, spark
plugs, drive chains, sprockets, drive rollers & smoothing
rollers.
Other Items Not Covered By This Warranty:
Tru-Turf Pty. Ltd. will not repair or replace free-of-charge
any item that has been damaged by accident, lack
of reasonable care and protection or lack of suitable
storage. We will not cover parts that have been altered
or modied by anyone other than Tru-Turf Pty. Ltd. nor
will we cover used parts that are installed in place of
failed parts. We will not cover parts that have not been
installed correctly by the end user or its agents nor will
we cover parts that have not been maintained as per the
Operator’s Manual. Service calls and overtime-labour
rates will not be covered. We will not cover freight costs
related to the return of the faulty product to Tru-Turf
Pty. Ltd. or its agents. Tru-Turf Pty. Ltd. will not be liable
for any consequential loss or damage or costs caused
by or incidental to the failure of any new part supplied
with the original purchase or any new part supplied as a
replacement for any failed part.
Lodging Warranty Claims:
The nal purchaser of the new Tru-Turf Pty. Ltd.product
must lodge a Warranty Claim with Tru-Turf Pty. Ltd. or
its agents. The original purchaser must provide written
evidence detailing the product’s delivery date to that
purchaser and the reasons why the purchaser believes
that the product or its part is defective in the categories
of faulty material or workmanship. The purchaser is to
deliver the faulty product or part to Tru-Turf Pty. Ltd.
or its agents at the purchaser’s expense. Acceptance or
rejection of the Warranty Claim is entirely at the discretion
of Tru-Turf Pty. Ltd. or their Suppliers who warrant their
own part/s.
Visit www.truturf.com. Fill out the warranty form and return
it to [e-mail]
No person or organisation has the authority to modify the
terms or conditions or limitations of this Warranty without
the written consent of Tru-Turf Pty. Ltd.

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual
5
Initial Assembly
When you receive the crate, the machine will be broken
down into components ready for assembly. If you run into
any problems during assembly, please feel free to call
your local distributor or agent.
List of Components
QTY Description
1 Operation, Maintenance and Parts Manual
1MachineFrame/Body
1DriversSeat
2Armrests
4 /” x ³/” UNC Bolts (Seat)
2 Tires mounted on Wheel Rim
1 Steering Joystick
1 Dampener Strut (attached to main body end)
1 Left-side Trailer Arm
1 Right-side Trailer Arm
2 25mm External Circlips
1 Drawbar Coupling Assembly
2 2¹/” x 3/8” UNF Hex Head Bolts (Drawbar)
2 ³/” UNF Nyloc Nuts (Drawbar)
Assembly

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual 6
Assembly Procedure
Step 1: Mounting the seat to the seat base.
• Use the four /” x ³/” UNC bolts to fasten the seat to
the seat base.
• Remove armrest screws from the seat, position left
and right side armrest, fasten and tighten.
Step 2: Mount the steering joystick to the steering
shaft.
• Select the steering joystick.
• Remove the two bolts in the top of the steering shaft.
• Slide the joystick into the slot on the top of the
steering shaft, already installed in the steering
column directly in front of the foot pedal controls,
insert the ³/” bolt into the bottom bolt hole, select
a comfortable operating position, joystick forward
for extra operating room or back for less, once
determined insert the other ³/” bolt into the upper
hole and tighten both bolts securely.
Step 3: Attaching the left-hand trailer arm to machine
body.
• Locate the trailer arm support axle 25mm in diameter
(1”) which extends out on the left side of the machine,
remove the circlip from the support axle. Oil machined
portion. Slide the left hand side trailer arm, onto the
axle, replace the circlip, ensuring the circlip is located
in the groove correctly.
Step 4: Attaching dampener strut and right hand
trailer arm.
• Locate the trailer arm support axle 25mm in diameter
(1”) which extends out on the right side of the
machine, remove the circlip from the axle. Hold the
right side trailer arm in the vertical position and slide it
part way onto the axle. Locate dampener strut, remove
packing from the unattached end.
• Apply thread lock “Loctite” to the M10 bolt attached to
the dampener strut. Screw the M10 bolt into the strut
support on the trailer arm.
• If necessary use a soft headed hammer and tap the
trailer arm onto the axle until the circlip groove is
revealed, t the circlip, ensuring it is located in the
groove correctly.
Step 5: Attaching draw bar to trailer arms.
• Locate the draw bar assembly.
• Gather the ends of the right and left trailer arms.
• Place the draw bar assembly between the trailer arms
and align the holes, ensure the bend is upwards.
• Place one 2/” x /” bolt through each hole, t /”
Nyloc nut to each bolt and tighten securely.
• Test to ensure the trailer catch is correctly locking the
trailer arms in the down position and the catch locking
pin ts correctly when transporting the roller, for
safety.
Step 6: Attaching wheels to trailer arms.
• Locate the two wheels for the left and right side trailer
arms.
Assembly

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual
7
• Check tires for the correct air pressure, approximately
18psi. Do not exceed this pressure. The tires act as the
suspension, hence the low P.S.I.
• Remove wheel nuts from both hubs, slide wheels onto
hub with air valves facing outwards. Replace wheel
nuts and tighten securely.
• Ensure the taper on the nuts, mate into the wheel
tapers correctly.
Step 7: Correct dampener strut operation
• When the roller is in the trailing position carefully
hold the draw bar assembly, release the locking catch,
gently with a rm grip begin to raise the draw bar,
when it has travelled suciently the dampener strut
will take over and prevent the trailer arms rapidly
rotating on it’s axle, allowing the roller to lower to the
surface gently. This prevents the operator from being
injured. When the roller is resting on the ground push
the trailer arms back gently, (do not use excessive
force) until the trailer arms will travel no further. The
dampener strut is designed to hold the trailer arms
back behind the operator with the wheels o the
ground.
Step 8: Replace engine oil
• A tag is placed on the engine’s On/O switch
indicating you must ll the machine with oil prior
to operation. Low oil level will cause the engine to
stop on steep hills, the engine cut o safety switch is
designed this way to protect the engine from damage
if low in oil.
• The oil in the engine upon delivery (if not pre-
delivered) is to prevent the inside of the engine from corroding,
replace it with the correct engine oil, as per the manufacturers
specications.
Step 9: Transmission oil tank breather.
• Unscrew the plastic plug from the top of the tank if tted and
replace it with the anti-splash breather supplied. Seal damage
and oil leakage will occur if the breather is not installed. If this is
not done damage to the seals in the transmission will occur.
Step 10: Lubricate smoothing head pivot bearings.
• There is a grease nipple or zirk located on both smoothing head
centre ball joint swivels. Apply grease to lubricate ttings.
• When rolling of the green is completed, move the roller onto
the fringe, stop the engine, lock the trailer into the trailing
position, connect it to the towing vehicle then move o to the
next green to be rolled. Do not put the trailer down into the
towing position on the green; damage may occur to the green
from the roller tires and body. Remember turn o the fuel cock
whilst towing the roller
Assembly

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual 8
Operation procedures
Pre-operation checks
• Check engine as per Honda manual.
• Ensure steering joystick has no looseness.
• Check that foot pedal depresses under normal foot
pressure in both directions and returns to the neutral
position. (Similar resistance to a motor vehicle clutch).
If this action is not smooth, check the yoke and
transmission struts for correct operation.
• Ensure that the draw bar locking catch mechanism is
securely locked to the main draw bar and the safety
pin is tted when trailing the roller.
• Check and tighten grub screws tted to the end
bearing lock rings on the rubber coated drive roller
and the spiker shaft bearings & pivot bearings on each
smoothing head.
• Grease lightly bearings tted to drive roller, spiker
shaft and Smoothing Head pivot bearings. Replace
plastic caps if tted.
• Grease rod ends, sparingly.
• Check tire pressure for proper operating pressure
(18psi). Do not over inate.
• Check for oil and fuel leaks - rectify before using
machine.
• Lubricate the drive chain with a suitable chain
lubricant.
Standard operation procedures
• Inspect and check that the roller is serviceable prior to
departing from workshop.
• Use a suitable towing vehicle to move roller from
green to green.
• Maximum recommended towing speed would be
equal to a motorized golf buggy. Approximately
4mph/7kph. Towing at excess speed or across rough
terrain may cause damage to the machine and trailer.
• When approaching the green do not tow the roller
onto the green to set up, put the roller on the fringe
of the green. Put trailer in the up position, start up the
roller and drive it onto the green.
• Greens can be rolled in any direction; take care to
ensure there are no crease lines produced on the
surface.
• It is recommended that you place the smoothing head
rollers on the high side of the green when rolling.
This increases the weight on the rubber drive roller
and gives better traction, it also reduces slipping or
spinning of the drive roller on the green, depending
also on the operators ability. Whilst becoming familiar
with the roller, set the throttle at about ¹/ - ³/ speed.
Press the left or right foot pedal down gently but not
suddenly. Be smooth with your action, hold in this
position until nearing the edge of the green, then take
your foot gently o the pedal, the roller will come to a
stop. Rest your other foot on the opposite pedal and
gently apply the pressure to the pedal. It then starts to
move the roller in the opposite direction. Once again
be gentle with the pedal, but not sudden. By using the
left and right pedal in this manner, will ensure there is
no damage to the green and less wear and tear on the
equipment and operator.
Operation procedures

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual
9
Points to remember
• Make sure the roller is serviceable before rolling.
• Start rolling from the fringe of the green.
• Smooth operation on the foot pedals.
• Pick a point on the other side of the green to roll to.
• Do not look at the green close to the roller; it makes it
dicult to steer the roller straight; look well ahead.
• Use 1/2 throttle until you are procient at operating
the roller.
• Once you choose your rolling line hold the joystick
steady, correcting direction gently as required.
• Move the steering joystick a little at a time to change
direction; excessive movement of the joystick makes it
dicult to maintain a straight line.
• Roll in straight lines.
• Do not leave the engine running with the roller parked
on the green; the engine vibration will cause roller
depression marks on the green.
• Move o the green when rolling is complete before
putting the trailer in the down position.
• When rolling steep greens and the engine stops, check
engine oil level. The engine is tted with a safety
switch; when the engine oil level is low the engine will
stop.
• The correct procedure for rolling the green is:
(a) Select the correct direction to roll the green,
remember this roller can roll the greens in all
directions.
(b) Start on one side of the green and work your
way across the green in a zigzag fashion, slightly
overlapping each lap you roll: this makes sure you
miss no part of the green and all of the green is
rolled. Avoid coming back across the green to roll
missed areas if possible. You should be able to
complete the rolling of 18 greens in the same time
or quicker than by mowing using a triplex mower.
• When rolling of the green is completed, move the
roller onto the fringe, stop the engine, lock the trailer
into the trailing position, connect it to the towing
vehicle then move o to the next green to be rolled.
Do not put the trailer down into the towing position
on the green; damage may occur to the green from
the roller tires and body.
• Remember turn o the fuel cock whilst towing the
roller.
Emergency and Park brake
• To engage, push parking lever forward until it will
travel no further, the lever operates on a over cam
principal, when it is fully engaged the lever will remain
in this position with the brake applied. To dis-engage
the park brake, pull the lever up and back. The lever
will remain in the o position until re-applied. Do not
operate the roller with the emergency brake engaged,
damage to the drive roller rubber coating will occur.
• Ensure the park brake is released prior to operating
the roller, if not irreparable damage to the rubber on
the drive roller will occur.
Operation procedures

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual 10
Maintenance
• Stop engine before performing any maintenance.
• Service the Honda engine according to the
manufacturers maintenance schedule.
Transmission (pump, Eaton 11)
• Initially, change the oil at 50 hours running time, then;
• Change oil every 500 hours or annually, whichever
occurs rst.
• Change hydraulic oil lter every 500 hours or annually,
whichever occurs rst.
• Only use the manufacturer’s recommended
replacement oil lter .
• When tting the lter, follow the instructions supplied
with the lter. This will ensure that the lter remains
tight and that no leaks occur.
• Check all hard line oil pipes for rubbing, excessive
vibration, leaks and tightness on a regular basis.
• Check transmission oil level on oil tank sight glass. Oil
level should remain at a minimum of 25mm (1”) and at
a maximum of 40mm (1.5”) from the top of the tank.
• Oil Capacity including lter is 6 liters or 5.3 U.S. quarts.
For the ultimate performance we use and recommend
the Penrite synthetic 5 SAE 5W-60 transmission oil.
(Part No. R5226)
Storing
• It is important to store this roller in the towing
position. This ensures the trailer strut is in the
closed position, protecting the shaft from
corrosion, then failure and also the weight is
taken o the roller bearings.
Service of the drive chain system
• Replacement - Some chains look a like, but
they are not, use only the chain and sprockets
recommended as per the correct spare parts
number. Wrong pitch drive chain tted will
cause excessive sprocket wear and possible
drive failure.
• Tensioning the drive chain - No adjustment
is required; the chain tension is automatically
adjusted.
Lubrication
• Lubricate Drive Chain with Chain Oil, WD40
or equivalent (CRC; Penetrene etc.) each time
prior to rolling of the Greens.
Maintenance

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual
11
Service of smoothing roller bearings
• Whilst the Roller is suspended by the Trailer, check
operational smoothness of the bearings tted to each
smoothing roller by rotating the rollers by hand. If
bearing tightness, roughness or excessive looseness is
detected, replace the faulty rollers.
• Remove roller shaft bolts from end plates, remove
rollers from the heads.
• Replace faulty rollers.
• Replace rollers into the heads, lubricate shaft bolts
with an anti seize compound before installing them.
Tighten securely and ensure rollers rotate freely when
fully tightened.
• If the connecting rod is are removed or length altered
ensure it is correctly adjusted so that the two heads
are parallel to each other when in the straight ahead
position. Adjust if necessary.
Changing engine oil
• Change oil and service as per the manufacturers
Servicing Schedule enclosed as a separate insert to
this manual.
Changing transmission oil
• See page 12 and 14.
Description Pre-Delivery Pre-Operating 12 Monthly
Check Engine oil √√
Check Transmission Oil Level √√
Beware of contaminants entering the transmission √√
Lubricate drive chain with WD40 or equivalent √√
Check Tires Max 18 P.S.I. √√
Check Gas √√
Check Smoothing Roller Bearing √√
Check Drive Roller Bearings √√
Check for loose Nuts and Bolts √√
Renew Engine Oil as per manufacturers Handbook
Renew Transmission Oil - See page 1 for correct oil every 500hrs or... √
Renew Transmission Oil Filter *√
Renew Smoothing Roller Bearings *√
Renew Drive Roller Bearings *√
Renew Chain Tensioner Sprocket Bearings *√
Renew Drive Chain *√
Replace Foot Pedal Struts *
Replace Trailer Strut *
Lubricating transmission yoke slides
• Lubricate slide were transmission strut attaches to the
yoke, use a general purpose grease. If this is not done
sticking of components in this area may occur, this will
cause roller spin on the takeo or foot pedal jamming.
If tted with nylon washers this is not necessary.
Ongoing Maintenance, Lubricant and Replacement
Schedule (below)
Note. Areas indicated with a *need to be changed
when defective or as required. This may be before the
recommended replacement schedule. Please replace all
parts as necessary.
Maintenance

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual 12
Fault Finding
Roller will not move one or either way, check
• Chain is okay.
• Sprockets are not worn or slipping on the shaft.
• Foot control is operating - check all arms are secure.
• For Sheared Sprocket Keys.
Roller will not steer, check
• Woodru Key is in place and not sheared.
• Rod ends are connected to smoothing roller head and
the steering arm.
• Centre swivel bearing on top centre of each smoothing
roller head has not seized.
• Connecting rod are in place and serviceable.
• Roller shaft bolts in the head centre have not worked
loose and are locking.
Roller has excessive vibration, check
• Ensure the engine shaft is correctly aligned with the
transmission shaft and or remove shims if too high or
low - Align left or right.
• Disconnect engine-to-transmission and isolate the
drive chain to determine whether the problem is in the
engine or in the transmissions.
• If engine is at fault contact your nearest engine agent
for rectication.
• If the transmission is at fault, repair or replace as
necessary, or seek professional advice from a local
Eaton Service Center.
• Check drive sprockets for wear. If worn excessive it will
cause erratic slip between sprocket and chain.
Smoothing rollers seized, check
• Bearings have not seized.
• Accumulated dry debris is not locking the
smoothing rollers.
Rubber drive roller will not rotate, check
• Roller shaft end bearings have not seized.
• Broken chain.
• Slipping sprockets.
• The Park Brake is not locked on.
Fault Finding

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual
13
Rolling Position
Operating Positions
R6019
R6056
Towing Position
R8024
R5009 R8026
R6015
R5016
R8274
R8025
R8007
R5239

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual 14
Bottom view, foot pedal & top view
R9012
R6013
R5014
R6006
R5013
R5066
R5012
R5012
R5075
R5071
R5061
R6054
R5142
R5159
R9002
R5075
R5156
R6013
R8060
R8005
R8001
Bottom View
Foot Control
Top View
R5113
R5112
R8000
R8060
The /” size for the steer & smoothing head connecting rods applies from
serial number R10923 onwards.
R8299

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual
15
Engine
R5277
R5013
R5132
R5014
R5129
R5147
R6006
R8011
R8013
R5145
Top View
Chain TensionerOil Line Fittings
Top Rear View
R5232
R5234
R5144
R5148
R5233
R6054
R5197
R6015
R5143
R5230
R5234
R5231

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual 16
Oil lines
R5228
R5233
R5154
R5152
R5233
R5178
R5227
R5153
Oil Lines
Oil Lines
R5233
R5277
R5239
R5152
R5233
R5229
R5016
R5153
R5178
R5228
R5153
R5154

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual
17
Transmission & yoke
R5133
R5131
R5033
R5089
R5139
R5031
R5140
R8005
R8060
R5156
R5108
R9028
R8218
R5173
R5156
R5046
R5118A
R5184
R5118A
R5171
R8047
R8256
R5173
R8210

TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual 18
Transmission & chain tensioner
R5131
R5133
/ Set screw
R9003
R9004
R8055
R5132
R9005
R9007
R5094
R5095
/ x / UNC bolt
R5099
R5132
R9007
R5156
