True TS-23F User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • Fax [phone] • [phone] • Intl Fax# [phone]
Parts Dept. (800)424-TRUE • Parts Dept. Fax# [phone] • www.truemfg.com
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS: AVAILABLE AT:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
.S.A.
TM
U.S.A.
TS-23F
TS-23F
Model Doors
Capacity
(Cu. Ft.)
(liters) Shelves
Cabinet Dimensions
(inches)
(mm)
LDH
*HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TS-23F 1 23
652
327
686
291/2
750
783/8
1991
1/2
1/2
115/60/1
230-240/50/1
10.4
5.5
5-15P
▲
9
2.74
315
143
*Height does not include 5
" (127 mm) for castors or 6 " (153 mm) for optional legs. ▲Plug type varies by country.
True’s TS series is the choice for the
exclusive 300 series stainless steel
commercial application.
Designed using the highest quality
materials and components to
provide the user with colder product
temperatures, lower utility costs,
exceptional food safety and the
best value in today’s food service
marketplace.
Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser; maintains
-10°F (-23.3°C) cabinet temperatures.
Ideally suited for both frozen food and
ice cream.
300 series stainless steel exterior and
interior. The finest stainless available;
higher tensile strength for fewer dents
and scratches.
Adjustable, heavy duty PVC coated
shelves.
Positive seal self-closing door. Lifetime
guaranteed door hinges and torsion
type closure system.
Automatic defrost system time-
initiated, temperature-terminated.
Saves energy consumption and
provides shortest possible defrost cycle.
Bottom mounted units feature:
“No stoop” lower shelf.
Storage on top of cabinet.
Compressor performs in coolest, most
grease free area of kitchen.
Easily accessible condenser coil for
cleaning.
6/07
R
TS Series:
Reach-In 300 Series Stainless Steel Solid Door Freezer
®

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • Fax [phone] • [phone] • Intl. Fax# [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
& labor and an additional 4 year
warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
PLAN VIEW
Model Elevation Right Plan 3D
KCL
TS-23F TFEY03E TFEY03S TFEY03P TFEY033
TS-23F
DESIGN
• True’s solid door reach-in’s are designed
with enduring quality that protects your
long term investment.
• True’s commitment to using the
highest quality materials and oversized
refrigeration systems provides the user
with colder product temperatures, lower
utility costs, exceptional food safety and
the best value in today’s food service
marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using environmentally
friendly (CFC free) R404A refrigerant.
• Extra large evaporator coil balanced with
higher horsepower compressor and large
condenser maintains -10°F (-23.3°C). Ideal
for both frozen food and ice cream.
• Sealed, cast iron, self-lubricating
evaporator fan motor(s) and larger
fan blades give True reach-in’s a more
efficient, low velocity, high volume airflow
design. This unique design ensures
faster temperature recovery and shorter
run times in the busiest of food service
environments.
• Bottom mounted condensing unit
positioned for easy maintenance.
Compressor runs in coolest and most
grease free area of the kitchen. Allows for
storage area on top of unit.
• Automatic defrost system time-initiated,
temperature-terminated. Saves energy
consumption and provides shortest possible
defrost cycle.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel door,
front, and sides. Matching aluminum
back.
• Interior - 300 series stainless steel liner and
floor.
• Insulation - entire cabinet structure and
solid door are foamed-in-place using high
density, CFC free, polyurethane insulation.
• Welded, heavy duty galvanized frame rail
dipped in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fitted with 4" (102 mm)
diameter stem castors - locks provided
on front set.
DOOR
• 300 series stainless steel exterior and liner.
Door extends full width of cabinet shell.
Door lock standard.
• Lifetime guaranteed recessed door handle.
Door fitted with 12" (305 mm) long
recessed handle that is foamed-in-place
with a sheet metal interlock to ensure
permanent attachment.
• Positive seal self-closing door. Lifetime
guaranteed door hinges and torsion type
closure system.
• Magnetic door gasket of one piece
construction, removable without tools for
ease of cleaning.
SHELVING
• Three (3) adjustable, heavy duty PVC
coated wire shelves 227/8"L x 231/4"D
(582 mm x 591 mm). Four (4) chrome
plated shelf clips included per shelf.
• Aluminum shelf support pilasters. Shelves
are adjustable on 1/2" (13 mm) increments.
LIGHTING
• Incandescent interior lighting - safety
shielded. Lights activated by rocker switch
mounted above door.
MODEL FEATURES
• Evaporator is epoxy coated to eliminate
the potential of corrosion.
• Exterior solar, digital temperature display.
• Rear airflow guards prevent product from
blocking optimal airflow.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1
phase - 15 amp dedicated outlet. Cord and
plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead time may apply.
❒230 - 240V/50 Hz.
❒6" (153 mm) standard legs.
❒6" (153 mm) seismic/flanged legs.
❒Alternate door hinging (factory installed).
❒Novelty baskets.
❒Additional shelves.
❒Half door bun tray racks. Each holds up
to eleven 18"L x 26"D (458 mm x 661 mm)
sheet pans (sold separately) (airflow guards
need to be removed).
❒Full door bun tray rack. Holds up to
twenty-two 18"L x 26"D (458 mm x
661 mm) sheet pans (sold separately)
(airflow guards need to be removed).
❒Remote cabinets (condensing units
supplied by others; system comes standard
with 404A expansion valve and requires
R404A refrigerant). Consult factory
technical service department for BTU
information.
115/60/1
NEMA-5-15R
TS Series:
Reach-In 300 Series Stainless Steel Solid Door Freezer
835/16"
(2117 mm)
ELEVATION PLAN VIEW
27"
(686 mm)
785/16"
(1990 mm)
5 "
(127 mm)
551/32"
(1398 mm)
2517/32"
(649 mm)
291/2"
(750 mm)
7615/16"
(1955 mm)
13/8"
(35 mm)
4"
(102 mm)
