True TUC-60-32F User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • Fax [phone] • [phone] • Intl Fax# [phone]
Parts Dept. (800)424-TRUE • Parts Dept. Fax# [phone] • www.truemfg.com
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS: AVAILABLE AT:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
.S.A.
TM
U.S.A.
TUC-60-32F
TUC-60-32F
Model Doors
Capacity
(Cu. Ft.)
(liters) Shelves
Cabinet Dimensions
(inches)
(mm)
LD
†H*HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TUC-60-32F 2 15.9
451
460
1/4
1531
321/4
820
293/4
756
1/2115/60/1 10.4 5-15P 7
2.13
385
175
†Depth does not include 1
" (26 mm) for rear bumpers or 1/4 " (7 mm) for front bumper.
*Height does not include 61/4
" (159 mm) for castors or 6 " (153 mm) for optional legs.
7/07
R
True’s deep undercounter units
feature the combined advantage
of undercounter placement with
deeper refrigerated storage.
True’s deep undercounter units are
designed with enduring quality
that protects your long term
investment.
Designed using the highest
quality materials and components
to provide the user with colder
product temperatures, lower utility
costs, exceptional food safety and
the best value in today’s food
service marketplace.
Extra large evaporator coil
balanced with higher horsepower
compressor and large condenser
maintains -10°F (-23.3°C). Ideally
suited for both frozen foods and
ice cream.
All stainless steel front, top and
cabinet ends. Matching aluminum
finished back.
NSF approved, white aluminum
interior liner. 300 series stainless
steel floor with coved corners.
Foamed-in-place, high density
polyurethane insulation (CFC free).
Heavy duty PVC coated wire
shelves.
Automatic defrost system time-
initiated, time-terminated.
Deep Undercounter:
Solid Door Freezer
®

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • Fax [phone] • [phone] • Intl. Fax# [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
25/8"
(67 mm)
123/4"
(324 mm)
81/4"
(210 mm)
TUC-60-32F TFPY42E TFPY42S TFPY42P TFPY423
TUC-60-32F
DESIGN
• True’s commitment to using the highest
quality materials and oversized refrigeration
systems provides the user with colder product
temperatures, lower utility costs, exceptional
food safety and the best value in today’s food
service marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self-contained, capillary
tube system using environmentally friendly
(CFC free) R404A refrigerant.
• Oversized, factory balanced refrigeration
system with guided airflow to provide
uniform product temperatures.
• Extra large evaporator coil balanced with
higher horsepower compressor and large
condenser; maintains -10°F (-23.3°C). Ideally
suited for both frozen foods and ice cream.
• Sealed, cast iron, self-lubricating evaporator
fan motor(s) and larger fan blades give True
undercounter units a more efficient low
velocity, high volume airflow design. This
unique design ensures faster temperature
recovery and shorter run times in the busiest
of food service environments.
• Condensing unit is accessed from behind
front grill; slides out for easy maintenance.
• Automatic defrost system time-initiated,
time-terminated.
CABINET CONSTRUCTION
• Exterior - stainless steel front, top and
cabinet ends. Matching aluminum finished
back.
• Interior - attractive, NSF approved, white
aluminum liner. 300 series stainless floor with
coved corners.
• Insulation - entire cabinet structure and solid
doors are foamed-in-place using high density,
CFC free, polyurethane insulation.
• 5" (127 mm) diameter stem castors - locks
provided on front set.
• 36" (915 mm) work surface height.
DOORS
• Stainless steel exterior with white aluminum
liner to match cabinet interior.
• Each door fitted with 12" (305 mm) long
recessed handle that is foamed-in-place with
a sheet metal interlock to ensure permanent
attachment.
• Positive seal doors swing within cabinet
dimensions.
• Magnetic door gaskets of one piece
construction, removable without tools for
ease of cleaning.
SHELVING
• Four (4) adjustable, heavy duty PVC coated
wire shelves. Two (2) right door shelf
dimensions are 255/8"L x 28"D (601 mm x
712 mm). Two (2) left door shelf dimensions
are 171/4"L x 28"D (439 mm x 712 mm). Four
(4) chrome plated shelf clips included per
shelf.
• Shelf support pilasters made of same material
as cabinet interior; shelves are adjustable on
1/2" (13 mm) increments.
MODEL FEATURES
• Evaporator is epoxy coated to eliminate the
potential of corrosion.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1
phase, 15 amp dedicated outlet. Cord and
plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒6" (153 mm) standard legs.
❒6" (153 mm) seismic/flanged legs.
❒ 21/2" (64 mm) diameter castors.
❒ 3" (77 mm) diameter castors.
❒ Single utility shelf.
❒ Double utility shelf.
❒ 321/8" (816 mm) deep, 1/2" (13 mm) thick,
white polyethylene cutting board. Requires
“L” brackets.
❒ 321/8" (816 mm) deep, 1/2" (13 mm) thick,
composite cutting board. Requires “L”
brackets.
❒ Half bun tray racks (excludes left door).
Holds up to eleven 18"L x 26"D (458 mm x
661 mm) sheet pans (sold separately).
❒ Heavy duty 16 gauge tops.
❒ Heavy duty package (16 gauge tops,
20 gauge door, sides and back with stainless
interior).
❒ Exterior round digital temperature display
(factory installed).
❒ Remote cabinets (condensing unit supplied
by others; system comes standard with
404A expansion valve and requires R404A
refrigerant). Consult factory technical service
department for BTU information.
115/60/1
NEMA-5-15R
Deep Undercounter:
Solid Door Freezer
1/4"
(7 mm)
ELEVATION SIDE VIEW
601/4"
(1531 mm)
63/16"
(158 mm)
293/4"
(756 mm)
3515/16"
(913 mm)
2511/32"
(644 mm)
187/16"
(469 mm)
5817/32"
(1487 mm)
323/16"
(818 mm)
1"
(26 mm)
39/16"
(91 mm)
