True GDM-23F User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • Fax [phone] • [phone] • Intl Fax# [phone]
Parts Dept. (800)424-TRUE • Parts Dept. Fax# [phone] • www.truemfg.com
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS: AVAILABLE AT:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
.S.A.
TM
U.S.A.
GDM-23F
GDM-23F
Model Doors
Capacity
(Cu. Ft.)
(liters) Shelves
Cabinet Dimensions
(inches)
(mm)
LD
†HHP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
GDM-23F 1 23
652
427
686
297/8
759
785/8
1998
3/4
3/4
115/60/1
230-240/50
13.0
4.7
5-20P
▲
9
2.74
430
196
†Depth does not include 11/8
" (29 mm) for door handle. ▲Plug type varies by country.
6/07
R
The world’s #1 manufacturer of glass
door merchandisers.
Designed using the highest quality
materials and components to provide
the user with an attractive, point of
purchase merchandiser that brilliantly
displays frozen food and ice cream,
resulting in high impulse sales.
Oversized, factory balanced,
refrigeration system holds -10°F
(-23.3°C). Ideal for ice cream and
frozen food products.
Exterior - non-peel or chip white
laminated vinyl; durable and
permanent.
Interior - attractive, NSF approved,
white aluminum interior liner with
300 series stainless steel floor.
Self closing door. Positive seal,
torsion type closure system.
Triple pane thermal insulated
glass door assembly with extruded
aluminum frame.
Patented integrated door light (IDL)
system for brighter, shadow free
illumination.
Entire cabinet structure is foamed-
in-place using high density, CFC free,
polyurethane insulation.
Bottom mounted units feature:
”No stoop” lower shelf to maximize
product visibility.
Easily accessible condenser coil for
cleaning.
Glass Door Merchandiser:
Swing Door Freezer
®

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • Fax [phone] • [phone] • Intl. Fax# [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
& labor and an additional 4 year
warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
GDM-23F TFAZ03E TFAY03S TFAZ03P TFAZ033
GDM-23F
DESIGN
• True’s glass door freezers are designed
with enduring quality that protects your
long term investment.
• True’s commitment to using the
highest quality materials and oversized
refrigeration systems provides the user
with colder product temperatures,
and lower utility costs in an attractive
merchandiser that brilliantly displays
frozen food and ice cream.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free) R404A
refrigerant.
• Extra large evaporator coil balanced
with higher horsepower compressor and
large condenser; maintains -10°F (-23.3°C).
• Sealed, cast iron, self-lubricating
evaporator fan motor(s) and larger fan
blades give True merchandisers a more
efficient low velocity, high volume airflow
design. This unique design ensures
colder standard temperatures and faster
recovery in high use situations.
• Bottom mounted condensing unit
positioned for easy maintenance. “No
stoop” lower shelf maximizes visibility
by raising merchandised product to
higher level.
• Automatic defrost system time-initiated,
temperature-terminated. Saves energy
consumption and provides shortest
possible defrost cycle.
CABINET CONSTRUCTION
• Exterior - non-peel or chip white
laminated vinyl; durable and permanent.
• Interior - attractive, NSF approved, white
aluminum liner with 300 series stainless
steel floor.
• Insulation - entire cabinet structure is
foamed-in-place using high density, CFC
free, polyurethane insulation.
• Welded, heavy duty galvanized frame rail
dipped in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fitted with leg levelers.
• Illuminated exterior sign panel. Variety
of sign options available.
DOOR
• Triple pane thermal glass door assembly
with extruded aluminum frame.
• Door fitted with 12" (305 mm) extruded
handle.
• Self closing door. Positive seal, torsion
type closure system.
• Magnetic door gasket of one piece
construction, removable without tools for
ease of cleaning.
SHELVING
• Four (4) adjustable, heavy duty PVC
coated wire shelves 227/8"L x 211/4"D
(582 mm x 540 mm). Four (4) chrome
plated shelf clips included per shelf.
• Shelf support pilasters made of same
material as cabinet interior; shelves are
adjustable on 1/2" (13 mm) increments.
LIGHTING
• Safety shielded fluorescent interior
lighting. Door utilizes full-length,
patented, integrated door light (IDL)
system.
• Cabinet lighting utilizes electronic ballast
and T-8 bulbs for brighter illumination,
longer bulb life and increased energy
efficiency.
MODEL FEATURES
• Evaporator is epoxy coated to eliminate
the potential of corrosion.
• See our website www.truemfg.com for
latest color and sign offerings.
• Backguard and floor rack ensures
optimum airflow.
• Listed under NSF-7 for the storage and/or
display of packaged or bottled product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1
phase - 20 amp dedicated outlet. Cord
and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and leads times may apply.
❒230 - 240V / 50 Hz.
❒Black exterior.
❒Rosewood exterior.
❒Stainless steel exterior.
❒Black aluminum interior liner with black
shelving.
❒Stainless steel interior liner.
❒6" (153 mm) standard legs.
❒6" (153 mm) seismic/flanged legs.
❒21/2" (64 mm) diameter castors.
❒4" (102 mm) diameter castors.
❒11/4" (32 mm) pricing strips.
❒Novelty baskets.
❒ Remote cabinets and condensing
units, consult factory technical service
department for BTU information. System
comes standard with 404A expansion
valve and requires R404A refrigerant.
ELEVATION PLAN VIEW
115/60/1
NEMA-5-20R
Glass Door Merchandiser:
Swing Door Freezer
785/8"
(1998 mm)
5/16"
(8 mm)
7615/16"
(1955 mm)
13/8"
(35 mm)
27"
(686 mm)
3029/32"
(786 mm)
2913/16"
(758 mm)
13/32"
(28 mm)
543/4"
(1391 mm)
2415/16"
(634 mm)
