True TS-72FG User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • FAX [phone] • [phone] • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# [phone]
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
TM
TS-72FG
TS-72FG
Model Doors
Capacity
(Cu. Ft.)
(liters)
# of
Shelves
Cabinet Dimensions
(inches)
(mm)
LD†H* HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TS-72FG 3 72
2039
978
1/8
1985
293/4
756
791/8
2010
1.5 115/208-230/1 14.1 14-20P 9
2.74
N/A
N/A
† Depth does not inclide 13/8" (35 mm) for door handles.
* Height does not include 5" (127 mm) for castors or 6" (153 mm) for optional legs.
5/05
TS Series:
Reach-In All Stainless Steel Glass Door Freezer
Designed using the highest quality
materials and components to
provide the user with colder product
temperatures, lower utility costs,
exceptional food safety and the
best value in today’s food service
marketplace.
Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser; maintains
-10°F (-23.3°C) cabinet temperatures.
Ideally suited for both frozen foods
and ice cream.
300 series stainless steel front and
sides. The finest stainless with higher
tensile strength for fewer dents and
scratches.
Triple pane thermal glass door.
Adjustable, heavy duty PVC coated
shelves.
Positive seal self-closing doors.
Lifetime guaranteed door hinges and
torsion type closure system.
Automatic defrost system time-
initiated, temperature-terminated.
Saves energy consumption and
provides shortest possible defrost
cycle.
Bottom mounted units feature:
”No stoop” lower shelf.
Storage on top of cabinet.
Compressor performs in coolest, most
grease free area of kitchen.
Easily accessible condenser coil for
cleaning.
®
R

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • FAX [phone] • [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
TS-72FG
TS-72FG
DESIGN
• True’s glass door reach-in’s are designed
with enduring quality that protects your
long term investment.
• True’s commitment to using the
highest quality materials and oversized
refrigeration systems provides the user
with colder product temperatures, lower
utility costs, exceptional food safety and
the best value in today’s food service
marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free)
R404A refrigerant.
• Extra large evaporator coil balanced with
higher horsepower compressor
and large condenser; maintains -10°F
(-23.3°C). Ideal for both frozen foods and
ice cream.
• Sealed, cast iron, self-lubricating
evaporator fan motors and larger fan
blades give True reach-in’s a more
efficient, low velocity, high volume
airflow design. This unique design
ensures faster temperature recovery and
shorter run times in the busiest of food
service environments.
• Bottom mounted condensing unit
positioned for easy maintenance.
Compressor runs in coolest and most
grease free area of the kitchen. Allows
for storage area on top of unit.
• Automatic defrost system time-initiated,
temperature-terminated. Saves energy
consumption and provides shortest
possible defrost cycle.
CABINET CONSTRUCTION
• Exterior - 300 series stainless front and
sides. Matching aluminum back.
• Interior - 300 series stainless steel liner
and floor.
• Insulation - entire cabinet structure is
foamed-in-place using high density, CFC
free, polyurethane insulation.
• Welded, heavy duty galvanized frame rail
dipped in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fitted with 4
" (102 mm)
diameter stem castors - locks provided
on front set.
DOORS
• Triple pane thermal glass.
• Door locks standard.
• Positive seal self-closing doors. Lifetime
guaranteed door hinges and torsion type
closure system.
• Each door fitted with 15
" (381 mm) long
extruded aluminum handle.
• Magnetic door gaskets of one piece
construction, removable without tools
for ease of cleaning.
SHELVING
• Nine (9) adjustable, heavy duty PVC
coated wire shelves 241/8"L x 223/8"D
(613 mm x 591 mm). Four (4) chrome
plated shelf clips included per shelf.
• Shelf support pilasters made of same
material as cabinet interior; shelves are
adjustable on 1/2" (13 mm) increments.
LIGHTING
• Fluorescent interior lighting. Each door
utilizes full-length, patented, integrated
door light (IDL) system. Safety shielded.
MODEL FEATURES
• Evaporator is epoxy coated to eliminate
the potential of corrosion.
• Exterior mounted temperature monitor.
• Rear airflow guards prevent product
from blocking optimal airflow.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/208-
230/60Hz, single phase, 3 pole, 4 wire -20
amp dedicated outlet. Cord and plug set
included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒6" (153 mm) standard legs.
❒6" (153 mm) seismic/flanged legs.
❒Alternate door hinging (factory
installed).
❒Additional shelves.
❒Half door bun tray racks. Holds up to
eleven 18"L x 26"D (458 mm x 661 mm)
sheet pans (sold separately) (airflow
guards need to be removed).
❒Full door bun tray racks. Holds up to
twenty-two 18"L x 26"D (458 mm x
661 mm) sheet pans (sold separately)
(airflow guards need to be removed).
❒Remote cabinets (condensing unit
supplied by others), consult factory
technical service department for BTU
information.
115/208-230/1
NEMA-14-20R
TS Series:
Reach-In All Stainless Steel
Glass Door Freezer
841/16 "
(2136 mm)
ELEVATION PLAN VIEW
7615/16 "
(1955 mm)
5 "
(127 mm)
791/16 "
(2009 mm)
21/8 "
(54 mm)
2923/32 "
(755 mm)
313/32 "
(790 mm) 537/8
"
(1369 mm)
243/8 "
(620 mm)
781/8 "
(1985 mm)
13/8 "
(35 mm)
